AVTEG001 WLAN and BT LE Module Test... - FCC ID 2AF62-AVTEG001
FCC ID 2AF62-AVTEG001
Test Setup photos
WLAN and BT LE Module
by Avnet Inc
Document preview loads when visible.
Document Details
| FCC ID | 2AF62-AVTEG001 |
|---|---|
| Document ID | 3251728 |
| Document Type | Test Setup Photos |
| Description | Test Setup photos |
| Applicant | Avnet Inc |
| Equipment Class | WLAN and BT LE Module |
| Product Code | AVTEG001 |
| Application ID | MjdzYkCCydUYdHdGHoK9BQ== |
| Application Purpose | Original Equipment |
| Application Date | 2017-01-09 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0004937991 |
| Test Firm | Dongguan Precise Testing Service Co., Ltd. |
| Certified By | Tim Barber |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2017-01-09 |
| Available | 2017-01-09 |
| Created | 2016-09-14 |
| Modified | 2016-09-14 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 256372 |
| File SHA-256 | 144232886c8360133b4e03af6b84d2d32ae6aa4c8bf2bbc1d51f9e09ff8df4dc |
| PDF Metadata Author | USER |
| PDF Metadata Producer | Microsoft Office Word 2007 Microsoft Office Word 2007 |
| FCC.gov Sources | FCC.gov 3251728 |
