FCC ID 2AF6B-RAK41X
Wi-Fi Module
by Shenzhen RAKwireless Technology Co.,Ltd.
Grantee Code: 2AF6B Product Code: RAK41X
Latest application date: 2015-11-01
Device Images
FCC ID Device Details
| FCC ID | 2AF6B-RAK41X |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AF6B |
| Product Code | RAK41X |
| Applicant Business | Shenzhen RAKwireless Technology Co.,Ltd. 🇨🇳 |
| Related Domains |  rakwireless.com |
| Equipment Class | Wi-Fi Module |
| Test Firm | Shenzhen Anbotek Compliance Laboratory Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2015-11-01 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2015-11-01 | PDF 678.8 KB |
| Internal Photos | Internal Photos | 2015-11-01 | PDF 717.1 KB |
| External Photos | External Photos | 2015-11-01 | PDF 1 MB |
| Label | ID Label/Location Info | 2015-11-01 | PDF 5.6 KB |
| Label Location | ID Label/Location Info | 2015-11-01 | PDF 393.2 KB |
| RF Test Set-Up Photos | Test Setup Photos | 2015-11-01 | PDF 404 KB |
| RF Test Report-1 | Test Report | 2015-11-01 | PDF 3.8 MB |
| RF Test Report-2 | Test Report | 2015-11-01 | PDF 3 MB |
| Authorization Letter | Cover Letter(s) | 2015-11-01 | PDF 20.9 KB |
| DTS 12-13 ch Declaration Letter | Cover Letter(s) | 2015-11-01 | PDF 12.9 KB |
| Family Model Letter | Cover Letter(s) | 2015-11-01 | PDF 13.8 KB |
| LTC Letter | Cover Letter(s) | 2015-11-01 | PDF 23.5 KB |
| Modular Approval Request Letter | Cover Letter(s) | 2015-11-01 | PDF 47.1 KB |
| RF Exposure Report | RF Exposure Info | 2015-11-01 | PDF 34.9 KB |
| Block Diagram Metadata only | Block Diagram | PDF 17.8 KB | |
| Schematics Metadata only | Schematics | PDF 175.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 92.5 KB |
Application Information
| Application ID | cQCJbzG+Iw2GFUk2f8I5cw== |
|---|---|
| Final Action Date | 2015-11-01 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024961310 |
| Model | RAK41X |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wi-Fi Module |
| Responsible Party | Vivian Xu, Engineer, shasha.xu@rakwireless.com , 19926584202 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval for mobile host platform. Power listed is the maximum conducted output power. Device is 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| cQCJbzG+Iw2GFUk2f8I5cw== | 2015-11-01 | Original Equipment |
Grants
TCB Grant - Application cQCJbzG+Iw2GFUk2f8I5cw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 11/01/2015 Application Dated: 11/01/2015 |
| Shenzhen RAKwireless Technology Co.,Ltd. |
| Room 506, Building B, New Compark, Pingshan First |
| Road, Taoyuan Street, Nanshan District, |
| Shenzhen, China |
| Attention: Vivian Xu , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF6B-RAK41X |
| Name of Grantee: | Shenzhen RAKwireless Technology Co.,Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wi-Fi Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.0427 |
| Single Modular Approval for mobile host platform. Power listed is the maximum conducted output power. Device is 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application cQCJbzG+Iw2GFUk2f8I5cw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shenzhen RAKwireless Technology Co.,Ltd. Room 506, Building B, New Compark, Pingshan First Road, Taoyuan Street, Nanshan District, Shenzhen, China |
Date of Grant: 11/01/2015 Application Dated: 11/01/2015 |
| Attention: Vivian Xu , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF6B-RAK41X |
| Name of Grantee: | Shenzhen RAKwireless Technology Co.,Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wi-Fi Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.0427 |
| Single Modular Approval for mobile host platform. Power listed is the maximum conducted output power. Device is 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
