00249453138ZP7 DxPatch Teardown... - FCC ID 2AF6P00249453138ZP7

FCC ID 2AF6P00249453138ZP7

Internal Photos

DxPatch

by ApoDx Technology, Inc.

Document preview loads when visible.

Document Details

FCC ID2AF6P00249453138ZP7
Document ID2847801
Document TypeInternal Photos
DescriptionInternal Photos
Document Titleinternal Phts _2AF6P00249453138ZP7
ApplicantApoDx Technology, Inc.
Equipment ClassDxPatch
Product Code00249453138ZP7
Application ID1UTFEVhunJbMZY6fY0aMNA==
Application PurposeOriginal Equipment
Application Date2016-01-04
Frequency Range2402 MHz
FRN0024945313
Test FirmTUV Rheinland Taiwan Ltd.
Certified ByJay Yang GM
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2015-12-21
Available2016-01-04
Created2015-11-11
Modified2015-11-11
Pages3
File TypeAdobe Acrobat PDF
File Size1686778
File SHA-256f2b9452bb6e3cfdf0cf3f83a254d404920efdcedf264bc9eff8c3e511f3139c1
PDF Metadata Authorchartonr
PDF Metadata ProducerAFPL Ghostscript 8.53 FreePDF 4.02 - http://shbox.de
FCC.gov SourcesFCC.gov 2847801
