Shenzhen Huaxia Testing Technology Co., Ltd
1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District,
Shenzhen, China
Telephone:
Fax:
Website:
+86-755-26648640
+86-755-26648637
www.cqa-cert.com
Report Template Version: V03
Report Template Revision Date: Mar.1st, 2017
RF Exposure Evaluation Report
Cover page
Report No. :
CQASZ20180500101E-03
Applicant:
1MORE INC.
Address of Applicant:
Tianliao Building F14 East Block (New Materials Industrial Park), Xueyuan Road,
Nanshan District, Shenzhen, China
Manufacturer:
1MORE Shen Zhen Acoustic Technology Co., Ltd.
Address of
Manufacturer:
Tianliao Building 1403-1411, Zone A Tianliao Industrial Park, Taoyuan Street,
Nanshan District, Shenzhen, P.R. China
Equipment Under Test (EUT):
1MORE Stylish Dual-dynamic Driver BT In-Ear Headphones
Product:
E1024BT
Model No.:
1MORE
Brand Name:
FCC ID:
Standards:
2AF8ZE1024BT
47 CFR Part 1.1307
47 CFR Part 2.1093
KDB447498D01 General RF Exposure Guidance v06
Date of Test:
2018-05-25 to 2018-07-04
Date of Issue:
2018-07-04
PASS*
Test Result :
Tested By:
(Aaron Ma)
Reviewed By:
( Jack Ai)
Approved By:
( Jack Ai)
* In the configuration tested, the EUT complied with the standards specified above.
The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to
the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full.
Shenzhen Huaxia Testing Technology Co., Ltd
Report No.: CQASZ20180500101E-03
Version
Revision History Of Report
Report No.
Version
Description
Issue Date
CQASZ20180500101E-03
Rev.01
Initial report
2018-07-04
Page:2 of 6
Shenzhen Huaxia Testing Technology Co., Ltd
Report No.: CQASZ20180500101E-03
Contents
Page
COVER PAGE .............................................................................................................................................................1
VERSION .....................................................................................................................................................................2
CONTENTS .................................................................................................................................................................3
GENERAL INFORMATION .......................................................................................................................................4
4.1
4.2
CLIENT INFORMATION................................................................................................................................................4
GENERAL DESCRIPTION OF EUT ................................................................................................................................4
SAR EVALUATION ....................................................................................................................................................5
5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ..............................................................................................................5
5.1.1 Standard Requirement .................................................................................................................................5
5.1.2 Limits ..............................................................................................................................................................5
5.1.3 EUT RF Exposure .........................................................................................................................................5
Page:3 of 6
Shenzhen Huaxia Testing Technology Co., Ltd
Report No.: CQASZ20180500101E-03
General Information
4.1 Client Information
Applicant:
1MORE INC.
Address of Applicant:
Tianliao Building F14 East Block (New Materials Industrial Park), Xueyuan
Road, Nanshan District, Shenzhen, China
Manufacturer:
1MORE Shen Zhen Acoustic Technology Co., Ltd.
Address of Manufacturer:
Tianliao Building 1403-1411, Zone A Tianliao Industrial Park, Taoyuan
Street, Nanshan District, Shenzhen, P.R. China
4.2 General Description of EUT
Product Name:
1MORE Stylish Dual-dynamic Driver BT In-Ear Headphones
Model No.:
E1024BT
Trade Mark:
1MORE
Hardware Version:
FW_E1024_BM20L_V0.7
Software Version:
Operation Frequency:
PCB-EM022-V0.3(2018-05-10)
Bluetooth Version:
V4.1
Modulation Technique:
Frequency Hopping Spread Spectrum(FHSS)
BT classic: GFSK, π/4DQPSK, 8DPSK
BLE: GFSK
BT classic:79
BLE:40
Modulation Type:
Number of Channel:
2402MHz~2480MHz
Hopping Channel Type:
Adaptive Frequency Hopping systems
Sample Type:
portable production
Test Software of EUT:
Non Signaling Test Tool (manufacturer declare )
Antenna Type:
Wired antenna
Antenna Gain:
-0.73dBi
Power Supply:
lithium battery:DC3.7V, Charge by DC5.0V
Page:4 of 6
Shenzhen Huaxia Testing Technology Co., Ltd
Report No.: CQASZ20180500101E-03
SAR Evaluation
5.1 RF Exposure Compliance Requirement
5.1.1 Standard Requirement
According to KDB447498D01 General RF Exposure Guidance v06
4.3.1. Standalone SAR test exclusion considerations
Unless specifically required by the published RF exposure KDB procedures, standalone 1-g
head or body and 10-g extremity SAR evaluation for general population exposure conditions, by
measurement or numerical simulation, is not required when the corresponding SAR Exclusion
Threshold condition, listed below, is satisfied.
5.1.2 Limits
The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances
≤ 50 mm are determined by:
[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·
[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where
17
The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and
for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation
distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion
5.1.3 EUT RF Exposure
For BT: Measurement Data
GFSK mode
Test channel
Peak Output Power (dBm)
Lowest
2.420
Middle
2.180
Highest
0.460
π/4DQPSK mode
Test channel
Peak Output Power (dBm)
Lowest
2.290
Middle
2.080
Highest
0.410
8DPSK mode
Test channel
Peak Output Power (dBm)
Lowest
2.320
Middle
2.140
Highest
0.490
Remark: The Conducted Peak Output Power data refer to report Report No.: CQASZ20180500101E-01
Page:5 of 6
Shenzhen Huaxia Testing Technology Co., Ltd
Report No.: CQASZ20180500101E-03
For BLE:
Measurement Data
GFSK mode
Test channel
Peak Output Power (dBm)
Lowest
-5.6
Middle
-5.81
Highest
-5.41
Remark: The Conducted Peak Output Power data refer to report Report No.: CQASZ20180500101E-02
BDR, EDR and BLE can not simultaneous transmitting at same time.
The worst case data: GFSK_lowest channel
The Max Conducted Peak Output Power is 2.42dBm in lowest channel(2.402GHz);
The best case gain of the antenna is -0.73dBi.
EIRP= 2.42dBm – 0.73dBm= 1.69dBm
1.69Bm logarithmic terms convert to numeric result is nearly 1.48mW
According to the formula. calculate the EIRP test result:
[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·
[√f(GHz)]
General RF Exposure = (1.48mW / 5 mm ) x √2.402GHz = 0.46
①
SAR requirement:
②;
S= 3.0
① < ②.
So the SAR report is not required.
