1337R CHIP Pro Teardown Internal Photos - FCC ID 2AF9F-1337R

FCC ID 2AF9F-1337R

Internal Photos

CHIP Pro

by Next Thing Co.

Document preview loads when visible.

Document Details

FCC ID2AF9F-1337R
Document ID3390207
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantNext Thing Co.
Equipment ClassCHIP Pro
Product Code1337R
Application IDOhgOEvQPLGBYObHLWoCcTg==
Application PurposeOriginal Equipment
Application Date2017-05-15
Frequency Range2402-2480 MHz
FRN0024985319
Test FirmDongguan Precise Testing Service Co., Ltd.
Certified ByBen El-Baz VP
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2017-05-15
Available2017-05-15
Created2017-04-26
Modified2017-04-26
Pages1
File TypeAdobe Acrobat PDF
File Size209031
File SHA-2560fc9f9fbac92b446cc2a2d15197f43c83a4f373af71a9cf68d2ff08e3ec9bc72
PDF Metadata AuthorAdministrator
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 3390207, FCC.gov 3390193
