PXNP30S GamePad For Mobile Phone Test... - FCC ID 2AFGFPXN-P30S

FCC ID 2AFGFPXN-P30S

Test Setup Photos

GamePad For Mobile Phone

by Shen Zhen PXN Electronics Technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AFGFPXN-P30S
Document ID4717107
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantShen Zhen PXN Electronics Technology Co., Ltd.
Equipment ClassGamePad For Mobile Phone
Product CodePXNP30S
Application IDbzlrbyAnD+RM0oVcgz6odA==
Application PurposeOriginal Equipment
Application Date2020-05-09
Frequency Range2402-2480 MHz
FRN0024767402
Test FirmShenzhen LCS Compliance Testing Laboratory Ltd.
Certified ByGavin Liang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2020-05-09
Available2020-05-09
Created2020-05-08
Modified2020-05-08
Pages2
File TypeAdobe Acrobat PDF
File Size303714
File SHA-256469a3a7ff3bbbdb544e9643d64c8226ccb6a789901847935e34e1d8513918cf4
PDF Metadata AuthorTian
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 4717107
