PHT280 TPMS Teardown Internal Photos - FCC ID 2AFH7PHT280
FCC ID 2AFH7PHT280
Internal Photos
TPMS
Document preview loads when visible.
Document Details
| FCC ID | 2AFH7PHT280 |
|---|---|
| Document ID | 8483990 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | Measurement Report |
| Applicant | HAMATON AUTOMOTIVE TECHNOLOGY CO., LTD |
| Equipment Class | TPMS |
| Product Code | PHT280 |
| Application ID | UJm1mma3Oivb2ad7OCIJsQ== |
| Application Purpose | Original Equipment |
| Application Date | 2025-07-17 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0024780280 |
| Test Firm | SHENZHEN STS TEST SERVICES CO.,LTD. |
| Certified By | BOVEY YANG |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2025-07-17 |
| Available | 2025-07-17 |
| Created | 2025-07-03 |
| Modified | 2025-07-03 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 1294205 |
| File SHA-256 | c9ffbc528b5b102ac2a6c40a065e8142bfbbbd743dc3dd438bc8f74d864be7b8 |
| PDF Metadata Author | Kent |
| PDF Metadata Producer | Microsoft® Word 2019 Kent |
| FCC.gov Sources | FCC.gov 8483990 |
