FCC ID 2AFIB-YAS1817
YI 4K+ Action Camera
by Yi Technology Co.,Ltd.
Grantee Code: 2AFIB Product Code: YAS1817
Latest application date: 2017-04-11
Device Images
FCC ID Device Details
| FCC ID | 2AFIB-YAS1817 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AFIB |
| Product Code | YAS1817 |
| Applicant Business | Yi Technology Co.,Ltd. 🇨🇳 |
| Related Domains |  xiaoyi.com  ccsrf.com |
| Equipment Class | YI 4K+ Action Camera |
| Test Firm | Compliance Certification Services (KunShan) Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2017-04-11 |
| 2402-2480 MHz | Original Equipment | 2017-04-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2017-04-11 | PDF 1.9 MB |
| Internal Photos | Internal Photos | 2017-04-11 | PDF 1.2 MB |
| External Photos | External Photos | 2017-04-11 | PDF 861.7 KB |
| ID Label | ID Label/Location Info | 2017-04-11 | PDF 385.2 KB |
| Label Location | ID Label/Location Info | 2017-04-11 | PDF 491.7 KB |
| Test Setup Photos for SAR | Test Setup Photos | 2017-04-11 | PDF 153.8 KB |
| Test Setup photos | Test Setup Photos | 2017-04-11 | PDF 361.6 KB |
| SAR Test Report | RF Exposure Info | 2017-04-11 | PDF 693.1 KB |
| Test Report for BLE | Test Report | 2017-04-11 | PDF 559.4 KB |
| Test Report for WLAN | Test Report | 2017-04-11 | PDF 1.1 MB |
| Test Report-1 | Test Report | 2017-04-11 | PDF 546.3 KB |
| Test Report-2 | Test Report | 2017-04-11 | PDF 587.8 KB |
| Confidentiality | Cover Letter(s) | 2017-04-11 | PDF 55.9 KB |
| Declaration of Conformity (FCC subpart 15B) | Cover Letter(s) | 2017-04-11 | PDF 35.5 KB |
| Declaration of authorization | Cover Letter(s) | 2017-04-11 | PDF 35.3 KB |
| Appendix C DASY Calibration Certificate | RF Exposure Info | 2017-04-11 | PDF 4 MB |
| Appendix D Plots of SAR Test Result | RF Exposure Info | 2017-04-11 | PDF 358.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 112.9 KB | |
| Schematics Metadata only | Schematics | PDF 685.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 80.4 KB | |
| Software Security for UNII Metadata only | Operational Description | PDF 212.7 KB |
Application Information
| Application ID | zJPtF1XwnfuA0uqgMRHCqA== |
|---|---|
| Final Action Date | 2017-04-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024782096 |
| Model | YAS1817 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | YI 4K+ Action Camera |
| Responsible Party | wenyun xiao, xiao.wenyun@xiaoyi.com , +86-21-61656722 |
| Technical Contact | Jeff Fang, Compliance Certification Services( Kunshan) Inc., jeff.fang@ccsrf.com , 86-512-57355888 |
| Non-Technical Contact | Mandy Liu, Compliance Certification Services( Kunshan) Inc., Mandy.liu@ccsrf.com , 86-512-57355888 |
| Test Firm | Kurt Chen, Compliance Certification Services (KunShan) Inc., kurt.chen@tw.ccsemc.com  , 88633240332 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. This is a portable device. The SAR data in this filing is applicable to demonstrate compliance for body operating conditions and is limited to the specific configuration tested for this filling. SAR has been evaluated at 0 mm. End-users must be informed regarding RF exposure compliance. The highest reported Body SAR value is 1.13 W/kg. This device has a 20MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| zJPtF1XwnfuA0uqgMRHCqA== | 2017-04-11 | Original Equipment |
| qiscrlGcJW39Tii4N1Dc3g== | 2017-04-11 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application zJPtF1XwnfuA0uqgMRHCqA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 04/11/2017 Application Dated: 04/10/2017 |
| Yi Technology Co.,Ltd. |
| No.366 Shangke Road, No.18 Lane 55 Chuanhe Road, |
| China (Shanghai) Pilot Free Trade Zone |
| Shanghai, 201203 China |
| Attention: wenyun xiao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFIB-YAS1817 |
| Name of Grantee: | Yi Technology Co.,Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | YI 4K+ Action Camera |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.01 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.0095 |
| Output power listed is conducted. This is a portable device. The SAR data in this filing is applicable to demonstrate compliance for body operating conditions and is limited to the specific configuration tested for this filling. SAR has been evaluated at 0 mm. End-users must be informed regarding RF exposure compliance. The highest reported Body SAR value is 1.13 W/kg. This device has a 20MHz bandwidth mode. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application zJPtF1XwnfuA0uqgMRHCqA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Yi Technology Co.,Ltd. No.366 Shangke Road, No.18 Lane 55 Chuanhe Road, China (Shanghai) Pilot Free Trade Zone Shanghai, 201203 China |
Date of Grant: 04/11/2017 Application Dated: 04/10/2017 |
| Attention: wenyun xiao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFIB-YAS1817 |
| Name of Grantee: | Yi Technology Co.,Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | YI 4K+ Action Camera |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.01 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.0095 |
| Output power listed is conducted. This is a portable device. The SAR data in this filing is applicable to demonstrate compliance for body operating conditions and is limited to the specific configuration tested for this filling. SAR has been evaluated at 0 mm. End-users must be informed regarding RF exposure compliance. The highest reported Body SAR value is 1.13 W/kg. This device has a 20MHz bandwidth mode. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 04/11/2017 Application Dated: 04/10/2017 |
| Yi Technology Co.,Ltd. |
| No.366 Shangke Road, No.18 Lane 55 Chuanhe Road, |
| China (Shanghai) Pilot Free Trade Zone |
| Shanghai, 201203 China |
| Attention: wenyun xiao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFIB-YAS1817 |
| Name of Grantee: | Yi Technology Co.,Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | YI 4K+ Action Camera |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.02 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0031 |
| Output power listed is conducted. This is a portable device. The SAR data in this filing is applicable to demonstrate compliance for body operating conditions and is limited to the specific configuration tested for this filling. SAR has been evaluated at 0 mm. End-users must be informed regarding RF exposure compliance. The highest reported Body SAR value is 1.06 W/kg. This device has a 20MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application qiscrlGcJW39Tii4N1Dc3g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Yi Technology Co.,Ltd. No.366 Shangke Road, No.18 Lane 55 Chuanhe Road, China (Shanghai) Pilot Free Trade Zone Shanghai, 201203 China |
Date of Grant: 04/11/2017 Application Dated: 04/10/2017 |
| Attention: wenyun xiao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFIB-YAS1817 |
| Name of Grantee: | Yi Technology Co.,Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | YI 4K+ Action Camera |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.02 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0031 |
| Output power listed is conducted. This is a portable device. The SAR data in this filing is applicable to demonstrate compliance for body operating conditions and is limited to the specific configuration tested for this filling. SAR has been evaluated at 0 mm. End-users must be informed regarding RF exposure compliance. The highest reported Body SAR value is 1.06 W/kg. This device has a 20MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
