FCC ID 2AFJMESS-SSY
Bluetooth Module WKBT0204AR
by Effegibi srl
Grantee Code: 2AFJM Product Code: ESSSSY
Latest application date: 2015-10-09
Device Images
FCC ID Device Details
| FCC ID | 2AFJMESS-SSY |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AFJM |
| Product Code | ESSSSY |
| Applicant Business | Effegibi srl 🇮🇹 |
| Related Domains |  mac-italia.com  effegibi.it |
| Equipment Class | Bluetooth Module WKBT0204AR |
| Test Firm | Istituto Italiano del Marchio di Qualita' S.p.A. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-10-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-10-09 | PDF 1 MB |
| Internal Photos | Internal Photos | 2015-10-09 | PDF 311.6 KB |
| External Photos | External Photos | 2015-10-09 | PDF 311.6 KB |
| Label | ID Label/Location Info | 2015-10-09 | PDF 84.2 KB |
| Test Photos | Test Setup Photos | 2015-10-09 | PDF 314.4 KB |
| Test Report | Test Report | 2015-10-09 | PDF 3.7 MB |
| Agent Authorization | Cover Letter(s) | 2015-10-09 | PDF 248.9 KB |
| Confidentiality Request | Cover Letter(s) | 2015-10-09 | PDF 270.3 KB |
| Modular Approval Letter | Cover Letter(s) | 2015-10-09 | PDF 202.8 KB |
| RF Exposure | RF Exposure Info | 2015-10-09 | PDF 659.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 268.4 KB | |
| Schematics Metadata only | Schematics | PDF 297.3 KB | |
| Operation Description Metadata only | Operational Description | PDF 618.8 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 39 KB |
Application Information
| Application ID | jRU+bUdr/lNuWxTc39kaPA== |
|---|---|
| Final Action Date | 2015-10-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024049397 |
| Model | ESS-SSY |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Bluetooth Module WKBT0204AR |
| Responsible Party | Luca Bedetta, Certification Responsible, bedetta@mac-italia.com , 39 071 7573373 |
| Technical Contact | Luca Bedetta, Mac Italia, bedetta@mac-italia.com |
| Non-Technical Contact | Marco Borghetti, Effegibi, marco.borghetti@effegibi.it |
| Test Firm | Eng. Fulvio Giorgi, Istituto Italiano del Marchio di Qualita' S.p.A., fulvio.giorgi@imq.it  , 0039025073342 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted. This device is certified for mobile or portable applications. Co-location with other transmitters would require the use of FCC multi-transmitter procedures. Users and installers must be provided with installation instructions and operating conditions for satisfying RF exposure compliance. The Grantee is responsible for providing the documentation required for limited modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. Limited to installation into the devices shown in this filing. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| jRU+bUdr/lNuWxTc39kaPA== | 2015-10-09 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0033000 | 15C |
Grants
TCB Grant - Application jRU+bUdr/lNuWxTc39kaPA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 10/09/2015 Application Dated: 10/09/2015 |
| Effegibi srl |
| Via Gallo 769, 47522 Cesena (FC) Italy |
| Cesena, 47522 Italy |
| Attention: Luca Bedetta , Certification Responsible |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFJMESS-SSY |
| Name of Grantee: | Effegibi srl |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Bluetooth Module WKBT0204AR |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0033 |
| Power Output listed is conducted. This device is certified for mobile or portable applications. Co-location with other transmitters would require the use of FCC multi-transmitter procedures. Users and installers must be provided with installation instructions and operating conditions for satisfying RF exposure compliance. The Grantee is responsible for providing the documentation required for limited modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. Limited to installation into the devices shown in this filing. |
EAS Grant - Application jRU+bUdr/lNuWxTc39kaPA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Effegibi srl Via Gallo 769, 47522 Cesena (FC) Italy Cesena, 47522 Italy |
Date of Grant: 10/09/2015 Application Dated: 10/09/2015 |
| Attention: Luca Bedetta , Certification Responsible |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFJMESS-SSY |
| Name of Grantee: | Effegibi srl |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Bluetooth Module WKBT0204AR |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0033 |
| Power Output listed is conducted. This device is certified for mobile or portable applications. Co-location with other transmitters would require the use of FCC multi-transmitter procedures. Users and installers must be provided with installation instructions and operating conditions for satisfying RF exposure compliance. The Grantee is responsible for providing the documentation required for limited modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. Limited to installation into the devices shown in this filing. |
| Mail To: |
