FCC ID 2AFK4-ISNG1

FCC ID 2AFK4-ISNG1 Test-Report, 2AFK4 ISNG1, 2AFK4-ISNG1, 2AFK4-ISNGI, 2AFK4-1SNG1, 2AFK4-I5NG1

C2Ag, LLC FHSS Transmitter module 902-928 MHz ISNG1

An FCC ID is the product ID assigned by the FCC to identify wireless products in the market. The FCC chooses 3 or 5 character "Grantee" codes to identify the business that created the product. For example, the grantee code for FCC ID: 2AFK4-ISNG1 is 2AFK4. The remaining characters of the FCC ID, -ISNG1, are often associated with the product model, but they can be random. These letters are chosen by the applicant. In addition to the application, the FCC also publishes internal images, external images, user manuals, and test results for wireless devices. They can be under the "exhibits" tab below.

Purchase on Amazon: FHSS Transmitter module 902-928 MHz

FCC ID 2AFK4-ISNG1 ID-Label-Location-Info

*Please Check Individual Documents for more images

Application: FHSS Transmitter module 902-928 MHz
Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Short Link: fcc.id/2AFK4-ISNG1
Sources: FCC.gov | FCC.report
Registered By: C2Ag, LLC - 2AFK4 (United States)

App #	Purpose	Date	Unique ID
1	Original Equipment	2016-03-14	+1dqbO+LQQhttuIEIVpQGQ==

Operating Frequencies

Frequency Range	Power Output	Rule Parts	Line Entry
903.1-926.9 MHz	990 mW	15C	1

Exhibits

Document	Type	Submitted Available
Tune Up Procedure	Parts List/Tune Up Info Adobe Acrobat PDF (4 kB)	2016-03-14 2016-03-14
RF Exposure	RF Exposure Info Adobe Acrobat PDF (74 kB)	2016-03-14 2016-03-14
Label Sample	ID Label/Location Info Adobe Acrobat PDF (220 kB)	2016-03-14 2016-03-14
Confidentiality Request Letter	Cover Letter(s) Adobe Acrobat PDF (276 kB)	2016-03-14 2016-03-14
Module Attestation Letter	Cover Letter(s) Adobe Acrobat PDF (156 kB)	2016-03-14 2016-03-14
Test Report	Test Report Adobe Acrobat PDF (2087 kB)	2016-03-14 2016-03-14
Agent Authorization Letter	Cover Letter(s) Adobe Acrobat PDF (342 kB)	2016-03-14 2016-03-14
Users Manual	Users Manual Adobe Acrobat PDF (555 kB)	2016-03-14 2016-04-28
Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (996 kB)	2016-03-14 2016-04-28
Internal Photos	Internal Photos Adobe Acrobat PDF (302 kB)	2016-03-14 2016-04-28
External Photos	External Photos Adobe Acrobat PDF (261 kB)	2016-03-14 2016-04-28
Operational Description	Operational Description Adobe Acrobat PDF (617 kB)	2016-03-14
Schematics	Schematics Adobe Acrobat PDF (205 kB)	2016-03-14
Block Diagram	Block Diagram Adobe Acrobat PDF (92 kB)	2016-03-14

Correspondence

App #	Document	Date
1	[Re-Sent]Short-Term Confidential Expiration Email generated [Apr 20 2016]	2016-04-20 12:07:20
1	[Re-Sent]Short-Term Confidential Expiration Email generated [Apr 20 2016]	2016-04-20 12:08:12

Application Forms

1 (2016-03-14)

Application for Equipment Authorization FCC Form 731 TCB Version

Applicant Information

Applicant's complete, legal business name:	C2Ag, LLC
FCC Registration Number (FRN):	0024804973
Alphanumeric FCC ID:	2AFK4ISNG1
Unique Application Identifier:	+1dqbO+LQQhttuIEIVpQGQ==
Line one:	207 S Main Street
P.O. Box:	315
City:	Archie
State:	Missouri
Country:	United States
Zip Code:	64725

TCB Information

TCB Application Email Address:	TEI@TIMCOENGR.COM
TCB Scope:	A4: UNII devices & low power transmitters using spread spectrum techniques

FCC ID

Grantee Code:	2AFK4
Product Code:	-ISNG1

Person at the applicant's address to receive grant or for contact

Name:	Don Schaefer
Title:	Chief Technology Office

Telephone Number:

816-293-5490

Extension:

Fax Number:	816-293-5231
Email:	dbschaefer@intelliair.com

Long-Term Confidentiality

Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules?: Yes

Short-Term Confidentiality

Does short-term confidentiality apply to this application?: Yes

If so, specify the short-term confidentiality release date (MM/DD/YYYY format): 04/28/2016
Note: If no date is supplied, the release date will be set to 45 calendar days past the date of grant.

Software Defined/Cognitive Radio

Is this application for software defined/cognitive radio authorization? No

Equipment Class

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Description of product as it is marketed: (NOTE: This text will appear below the equipment class on the grant):	FHSS Transmitter module 902-928 MHz

Related OET KnowledgeDataBase Inquiry

Is there a KDB inquiry associated with this application? No

Modular Equipment

Modular Type: Limited Single Modular Approval

Application Purpose

Application is for: Original Equipment

Composite/Related Equipment

Is the equipment in this application a composite device subject to an additional equipment authorization? No

Is the equipment in this application part of a system that operates with, or is marketed with, another device that requires an equipment authorization? No

Test Firm Information

Name of test firm and contact person on file with the FCC:

Firm Name: Rogers Labs, Inc.

First Name: Scot

Last Name: Rogers

Telephone Number:

913-837-3214

Extension:

Fax Number: 913-837-3214

E-mail: rogers@pixius.net

Grant Comments

Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization:
Limited Modular Approval. Power listed is conducted. Approval is limited to OEM installation only and must be professionally installed. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for fixed or mobile applications. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is incorporated into a finished product that meet those devices described within the application filing documents. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antennas used with this device must only be the antennas that were tested in preparation of this application. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. A separation distance of 20 cm must be maintained between the radiating elements and all persons. This device shall only be connected to devices that are covered by either an FCC DoC or are FCC Certified. The module must be oriented in the vertical position once installed in the host device pursuant to the application documents filed when the original certification was issued.

Set the grant of this application to be deferred to a specified date:
No

Equipment Authorization Waiver

Is there an equipment authorization waiver associated with this application? No

If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded?: No

WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503).

SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION:

The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes.

Does the applicant or authorized agent so certify? Yes

Applicant/Agent Certification:

I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements.

Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application.

If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time.

Signature of Authorized Person Filing: Scot D. Rogers

Title of authorized signature: President

Applications are submitted for FCC ID and Grant requests. Click an above application to view details

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Timco Engineering, Inc.
849 NW State Road 45 <BR>P.O. Box 370,
Newberry, FL 32669

Date of Grant: 03/14/2016

Application Dated: 03/14/2016

C2Ag, LLC

207 S Main Street

P.O. Box 315,

Archie, MO 64725

Attention: Don Schaefer , Chief Technology Office

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2AFK4-ISNG1

Name of Grantee:	C2Ag, LLC

Equipment Class:	Part 15 Spread Spectrum Transmitter
Notes:	FHSS Transmitter module 902-928 MHz
Modular Type:	Limited Single Modular

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
	15C	903.1 - 926.9	0.99

Limited Modular Approval. Power listed is conducted. Approval is limited to OEM installation only and must be professionally installed. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for fixed or mobile applications. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is incorporated into a finished product that meet those devices described within the application filing documents. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antennas used with this device must only be the antennas that were tested in preparation of this application. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. A separation distance of 20 cm must be maintained between the radiating elements and all persons. This device shall only be connected to devices that are covered by either an FCC DoC or are FCC Certified. The module must be oriented in the vertical position once installed in the host device pursuant to the application documents filed when the original certification was issued.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

C2Ag, LLC
207 S Main Street P.O. Box 315,
Archie, MO 64725
United States
