HY33991 Mobile Phone Test Setup Photos - FCC ID 2AFRUHY3-3991

FCC ID 2AFRUHY3-3991

Test setup Photos

Mobile Phone

by Solnik S.A.

Document preview loads when visible.

Document Details

FCC ID2AFRUHY3-3991
Document ID3295088
Document TypeTest Setup Photos
DescriptionTest setup Photos
Document TitleTest Setup Photos part 15B
ApplicantSolnik S.A.
Equipment ClassMobile Phone
Product CodeHY33991
Application IDK9UbQaxesrPAIUBR3kGGSQ==
Application PurposeOriginal Equipment
Application Date2017-02-24
FRN0024854283
Test FirmBay Area Compliance Laboratories Corp.
Certified ByDaniel Brian Piuselli
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date04/10/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-02-24
Available2017-04-10
Created2017-02-21
Modified2017-02-21
Pages3
File TypeAdobe Acrobat PDF
File Size297025
File SHA-256c99d380cbf95eb5c829035f6e765baa2ffad7dbd708b7b4edeb3b7e44d7e9032
PDF Metadata Authorreporter04
PDF Metadata ProducerAcrobat Distiller 7.0.5 (Windows) reporter04
FCC.gov SourcesFCC.gov 3295088
