FCC ID 2AFTTA5
Wireless Portable Disk
by Shenzhen Damai Technology Co., Ltd
Grantee Code: 2AFTT Product Code: A5
Latest application date: 2015-09-24
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2015-09-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-09-24 | PDF 1.1 MB |
| Internal Photos 1 | Internal Photos | 2015-09-24 | PDF 4.5 MB |
| Internal Photos 2 | Internal Photos | 2015-09-24 | PDF 4.6 MB |
| Internal Photos 3 | Internal Photos | 2015-09-24 | PDF 4.3 MB |
| External Photos 1 | External Photos | 2015-09-24 | PDF 3.8 MB |
| External Photos 2 | External Photos | 2015-09-24 | PDF 4.9 MB |
| Label | ID Label/Location Info | 2015-09-24 | PDF 50.6 KB |
| Test Setup Photos | Test Setup Photos | 2015-09-24 | PDF 1.5 MB |
| Test Report | Test Report | 2015-09-24 | PDF 4.2 MB |
| Authority to Act as Agent | Cover Letter(s) | 2015-09-24 | PDF 84.2 KB |
| Channel Statement | Cover Letter(s) | 2015-09-24 | PDF 55.8 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2015-09-24 | PDF 109.1 KB |
| DOC Statement | Cover Letter(s) | 2015-09-24 | PDF 171.4 KB |
| SAR Report Part 1 | RF Exposure Info | 2015-09-24 | PDF 5.5 MB |
| SAR Report Part 2 | RF Exposure Info | 2015-09-24 | PDF 3.1 MB |
| Tune Up Procedure | Parts List/Tune Up Info | 2015-09-24 | PDF 39.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 26 KB | |
| Schematics Metadata only | Schematics | PDF 143.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 29.2 KB |
Application Information
| Application ID | DxmOysiOyXytErtqTefuoQ== |
|---|---|
| Final Action Date | 2015-09-24 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024871105 |
| Model | A5 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless Portable Disk |
| Responsible Party | Qin min, jacky@dmsys.com  , +86-18665955308 |
| Test Firm | June Zhang, SGS-CSTC Standards Technical Services Co.,Ltd., June.Zhang@sgs.com  , 8675525328598 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. SAR compliance for portable use conditions has been evaluated as described in this filing. The highest reported SAR value is 0.71W/kg. This device has a 20 MHz and 40 MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| DxmOysiOyXytErtqTefuoQ== | 2015-09-24 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.1080000 | 15C |
Grants
TCB Grant - Application DxmOysiOyXytErtqTefuoQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/24/2015 Application Dated: 09/24/2015 |
| Shenzhen Damai Technology Co., Ltd |
| NO.8,Kefa road,High-Tech Park,Shenzhen,China |
| Shenzhen, China |
| Attention: Qin min |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFTTA5 |
| Name of Grantee: | Shenzhen Damai Technology Co., Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Portable Disk |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.108 |
| Power listed is conducted. SAR compliance for portable use conditions has been evaluated as described in this filing. The highest reported SAR value is 0.71W/kg. This device has a 20 MHz and 40 MHz bandwidth mode. |
EAS Grant - Application DxmOysiOyXytErtqTefuoQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shenzhen Damai Technology Co., Ltd NO.8,Kefa road,High-Tech Park,Shenzhen,China Shenzhen, China |
Date of Grant: 09/24/2015 Application Dated: 09/24/2015 |
| Attention: Qin min |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFTTA5 |
| Name of Grantee: | Shenzhen Damai Technology Co., Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Portable Disk |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.108 |
| Power listed is conducted. SAR compliance for portable use conditions has been evaluated as described in this filing. The highest reported SAR value is 0.71W/kg. This device has a 20 MHz and 40 MHz bandwidth mode. |
| Mail To: |
