FCC ID 2AFTXRT880
4G LTE Cat.4 CPE
by OBSERVA Telecom
Grantee Code: 2AFTX Product Code: RT880
Latest application date: 2016-02-03
Device Images
FCC ID Device Details
| FCC ID | 2AFTXRT880 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AFTX |
| Product Code | RT880 |
| Applicant Business | OBSERVA Telecom 🇪🇸 |
| Related Domains |  observatelecom.com |
| Equipment Class | 4G LTE Cat.4 CPE |
| Test Firm | Shenzhen BALUN Technology Co.,Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 824.2-848.8 MHz | Original Equipment | 2016-02-03 |
| 2412-2462 MHz | Original Equipment | 2016-02-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-02-03 | PDF 4.4 MB |
| Internal Photos Part 1 | Internal Photos | 2016-02-03 | PDF 750.9 KB |
| Internal Photos Part 2 | Internal Photos | 2016-02-03 | PDF 3.4 MB |
| External Photos | External Photos | 2016-02-03 | PDF 540.1 KB |
| Label Location | ID Label/Location Info | 2016-02-03 | PDF 88.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-02-03 | PDF 440.9 KB |
| Test Setup Photos JBP | Test Setup Photos | 2016-02-03 | PDF 173.4 KB |
| Test Report DTS | Test Report | 2016-02-03 | PDF 3.9 MB |
| Test Report JBP | Test Report | 2016-02-03 | PDF 1 MB |
| Test Report PCB Part 1 | Test Report | 2016-02-03 | PDF 5.3 MB |
| Test Report PCB Part 2 | Test Report | 2016-02-03 | PDF 1.7 MB |
| Test Report PCB Part 3 | Test Report | 2016-02-03 | PDF 2.6 MB |
| Authorization Letter | Cover Letter(s) | 2016-02-03 | PDF 27.9 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-02-03 | PDF 489.9 KB |
| BOM | Parts List/Tune Up Info | 2016-02-03 | PDF 67.7 KB |
| RF Exposure | RF Exposure Info | 2016-02-03 | PDF 130.4 KB |
| Tune Up Procedure | Parts List/Tune Up Info | 2016-02-03 | PDF 44.4 KB |
| Tune Up Procedures | Parts List/Tune Up Info | 2016-02-03 | PDF 44.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 63.8 KB | |
| Schematics Metadata only | Schematics | PDF 292.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 1.4 MB | |
| Operational Description Antenna Spec Metadata only | Operational Description | PDF 1.1 MB |
Application Information
| Application ID | fLq6PWBT5bViaR3lJpO+bg== |
|---|---|
| Final Action Date | 2016-02-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0021959655 |
| Model | RT880 |
| Frequency Range | 824.2-848.8 MHz |
| Equipment Class | PCB - PCS Licensed Transmitter |
| Device Description | 4G LTE Cat.4 CPE |
| Responsible Party | Leonor Rodriguez, Engineering and Development manager, lrodriguez@observatelecom.com , +34917451708 |
| Test Firm | Xuewen Wu, Shenzhen BALUN Technology Co.,Ltd., xuewen.wu@baluntek.com  , 86-755-66833404 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is EIRP for Part 24 and Part 27, and ERP for Part 22. This device has two main antennas and two diversity antennas. Two diversity antennas only support receiving signal. Two main antennas have only one RF port supporting transmitting and receiving, and can switch. But main antennas can't transmit simultaneously. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 30 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. The antenna installation and operating configurations of this transmitter, including any applicable source-based time-averaging duty factor, antenna gain, and cable loss must satisfy MPE categorical Exclusion Requirements of Part 2.1091. Users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC bureau(s), including antenna co-location requirements of Part 1.1307(b)(3). The antenna gain is less than 2.8dBi in 824-849MHz, less than 5.0dBi in 1850-1910MHz, less than 3.8dBi in 2500-2690MHz |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| fLq6PWBT5bViaR3lJpO+bg== | 2016-02-03 | Original Equipment |
| aw1ir5hrCIVG0Ihi0jkUcw== | 2016-02-03 | Original Equipment |
| FGEpAxg+z+NcD94bWOHIWg== | 2016-02-03 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 15B | CC | ||||
| 824.2-848.8 MHz | 1.72 | 47.12Hz | 243KG7W | 22H | |
| 826.4-846.6 MHz | 0.19 | 49.53Hz | 4M16F9W | 22H | |
| 1850.2-1909.8 MHz | 1.82 | 48.71Hz | 246KGXW | 24E | |
| 1850.2-1909.8 MHz | 1.93 | 48.69Hz | 255KG7W | 24E | |
| 1850.7-1909.3 MHz | 0.55 | 49.95Hz | 13M4W7D | 22H | |
| 1850.7-1909.3 MHz | 0.65 | 46.44Hz | 1M15G7D | 22H | |
| 1850.7-1909.3 MHz | 0.63 | 46.44Hz | 17M8G7D | 22H | |
| 1850.7-1909.3 MHz | 0.5 | 49.95Hz | 17M8W7D | 22H | |
| 1852.4-1907.6 MHz | 0.56 | 49.93Hz | 4M15F9W | 24E | |
| 2412-2462 MHz | 0.0937000 | 15C | CC | ||
| 2502.5-2567.5 MHz | 0.32 | 48.44Hz | 17M8G7D | 27 | |
| 2502.5-2567.5 MHz | 0.33 | 48.44Hz | 4M49G7D | 27 | |
| 2502.5-2567.5 MHz | 0.26 | 46.74Hz | 17M8W7D | 27 | |
| 2502.5-2567.5 MHz | 0.27 | 46.74Hz | 4M49W7D | 27 |
Grants
TCB Grant - Application fLq6PWBT5bViaR3lJpO+bg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 02/03/2016 Application Dated: 02/03/2016 |
| OBSERVA Telecom |
| Monte Esquinza, 28 - 1st floor - Right hand |
| MADRID, 28010 Spain |
| Attention: Leonor Rodriguez , Engineering and Development manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFTXRT880 |
| Name of Grantee: | OBSERVA Telecom |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | 4G LTE Cat.4 CPE |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 824.2 - 848.8 | 3.09 | 49.67 Hz | 246KGXW | |
| 24E | 1850.2 - 1909.8 | 1.82 | 48.71 Hz | 246KGXW | |
| 22H | 824.2 - 848.8 | 1.72 | 47.12 Hz | 243KG7W | |
| 24E | 1850.2 - 1909.8 | 1.93 | 48.69 Hz | 255KG7W | |
| 22H | 826.4 - 846.6 | 0.19 | 49.53 Hz | 4M16F9W | |
| 24E | 1852.4 - 1907.6 | 0.56 | 49.93 Hz | 4M15F9W | |
| 22H | 1850.7 - 1909.3 | 0.65 | 46.44 Hz | 1M15G7D | |
| 22H | 1850.7 - 1909.3 | 0.63 | 46.44 Hz | 17M8G7D | |
| 22H | 1850.7 - 1909.3 | 0.5 | 49.95 Hz | 17M8W7D | |
| 22H | 1850.7 - 1909.3 | 0.55 | 49.95 Hz | 13M4W7D | |
| 27 | 2502.5 - 2567.5 | 0.32 | 48.44 Hz | 17M8G7D | |
| 27 | 2502.5 - 2567.5 | 0.33 | 48.44 Hz | 4M49G7D | |
| 27 | 2502.5 - 2567.5 | 0.26 | 46.74 Hz | 17M8W7D | |
| 27 | 2502.5 - 2567.5 | 0.27 | 46.74 Hz | 4M49W7D |
| Power listed is EIRP for Part 24 and Part 27, and ERP for Part 22. This device has two main antennas and two diversity antennas. Two diversity antennas only support receiving signal. Two main antennas have only one RF port supporting transmitting and receiving, and can switch. But main antennas can't transmit simultaneously. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 30 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. The antenna installation and operating configurations of this transmitter, including any applicable source-based time-averaging duty factor, antenna gain, and cable loss must satisfy MPE categorical Exclusion Requirements of Part 2.1091. Users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC bureau(s), including antenna co-location requirements of Part 1.1307(b)(3). The antenna gain is less than 2.8dBi in 824-849MHz, less than 5.0dBi in 1850-1910MHz, less than 3.8dBi in 2500-2690MHz |
