KX100 Smart Test Device Test Setup Photos - FCC ID 2AFVSKX100

FCC ID 2AFVSKX100

RF Test Set-Up Photos

Smart Test Device

by Shenzhen kexin Communication Technologies Co.,Ltd

Document preview loads when visible.

Document Details

FCC ID2AFVSKX100
Document ID2777538
Document TypeTest Setup Photos
DescriptionRF Test Set-Up Photos
ApplicantShenzhen kexin Communication Technologies Co.,Ltd
Equipment ClassSmart Test Device
Product CodeKX100
Application IDCh9wTmZNts+iV/Kah7Fwtw==
Application PurposeOriginal Equipment
Application Date2015-10-10
Frequency Range1850.2-1909.8 MHz
FRN0024872806
Test FirmShenzhen LCS Compliance Testing Laboratory Ltd.
Certified Byzhang jiang yi
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-10-10
Available2015-10-10
Created2015-09-16
Modified2015-09-16
Pages2
File TypeAdobe Acrobat PDF
File Size235493
File SHA-256ca5a858e4a948a3871d835933f60f9c07ffa9de2c9b2b36ec7af201cbf25d6e5
PDF Metadata AuthorTian
PDF Metadata ProducerMicrosoft® Word 2010 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 2777538
