XD28BT Digital Media Receiver Label Diagram - FCC ID 2AFXA-XD28BT
FCC ID 2AFXA-XD28BT
Label and label location
Digital Media Receiver
Document preview loads when visible.
Document Details
| FCC ID | 2AFXA-XD28BT |
|---|---|
| Document ID | 6285666 |
| Document Type | ID Label/Location Info |
| Description | Label and label location |
| Document Title | C1-2022-226 XD28BT NS-2505E 机面UPC贴纸.cdr |
| Applicant | FengShun Peiying Electro-Acoustic Co., Ltd |
| Equipment Class | Digital Media Receiver |
| Product Code | XD28BT |
| Application ID | YFombMaiVkKvJBLVSLxkTw== |
| Application Purpose | Original Equipment |
| Application Date | 2022-12-19 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0024886582 |
| Test Firm | Dongguan Dongdian Testing Service Co., Ltd. |
| Certified By | Yiu Sang Li |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 06/14/2023 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-12-19 |
| Available | 2022-12-19 |
| Created | 2022-12-02 |
| Modified | 2022-12-02 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 289743 |
| File SHA-256 | 5a77a84e4e95c370066ed83ed87306508115b0198e3477fe232c0d4d3ce324f2 |
| PDF Metadata Author | 苏权姻 |
| PDF Metadata Producer | 苏权姻 Corel PDF Engine Version 14.0.0.701:䨄갸丄戀漀琀琀漀洀ⴀ䜀䠀一 堀开刀堀开䰀开嘀⸀㌀开㈀ ㈀㈀ 㔀㌀ ⸀瀀搀昀 |
| FCC.gov Sources | FCC.gov 6285666, FCC.gov 6285652 |
