FCC ID 2AFYS-KLK915IBTSC
LoRa gateway for IoT chain
by KERLINK SA
Grantee Code: 2AFYS Product Code: KLK915IBTSC
Latest application date: 2016-09-06
Device Images
FCC ID Device Details
| FCC ID | 2AFYS-KLK915IBTSC |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AFYS |
| Product Code | KLK915IBTSC |
| Applicant Business | KERLINK SA 🇫🇷 |
| Related Domains |  kerlink.fr |
| Equipment Class | LoRa gateway for IoT chain |
| Test Firm | EMITECH Angers |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 923.3-927.5 MHz | Original Equipment | 2016-09-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-03-05 | PDF 4.9 MB |
| Internal Photos | Internal Photos | 2017-03-05 | PDF 1.3 MB |
| External Photos | External Photos | 2016-09-06 | PDF 1 MB |
| Label Location | ID Label/Location Info | 2016-09-06 | PDF 103.3 KB |
| Label Sample | ID Label/Location Info | 2016-09-06 | PDF 20.5 KB |
| Test Setup Photos | Test Setup Photos | 2016-09-06 | PDF 1.5 MB |
| Test Report | Test Report | 2016-09-06 | PDF 3 MB |
| Agent Authorization Letter | Cover Letter(s) | 2016-09-06 | PDF 436.5 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-09-06 | PDF 781.2 KB |
| Block Diagram Metadata only | Block Diagram | PDF 272.2 KB | |
| Schematics cgs ampli filtrage unitaire v4a Metadata only | Schematics | PDF 405 KB | |
| Schematics cgs carte loraloc v2a Metadata only | Schematics | PDF 1.5 MB | |
| Schematics cgs fdp v3a Metadata only | Schematics | PDF 90.1 KB | |
| Schematics cgs notch v1c Metadata only | Schematics | PDF 58.8 KB | |
| Schematics cgs uc v3b Metadata only | Schematics | PDF 392.2 KB | |
| Schematics cgs wan wlan v3a Metadata only | Schematics | PDF 899.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 2.5 MB | |
| Operational Description ker-915-3-datasheet Metadata only | Operational Description | PDF 301.6 KB | |
| Operational Description ker-915-datasheet Metadata only | Operational Description | PDF 246.3 KB |
Application Information
| Application ID | DByCJ/HiPCi4QlzLkK7+eQ== |
|---|---|
| Final Action Date | 2016-09-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024895823 |
| Model | KLK915IBTSC |
| Frequency Range | 923.3-927.5 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | LoRa gateway for IoT chain |
| Responsible Party | YANNICK DELIBIE, yannick.delibie@kerlink.fr , +33 299 122 900 |
| Test Firm | Mounir El Marzouki, EMITECH Angers, m.elmarzouki@emitech-group.com  , 33-2-41-73-26-27 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 03/05/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| DByCJ/HiPCi4QlzLkK7+eQ== | 2016-09-06 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 923.3-927.5 MHz | 0.4520000 | 15C |
Grants
TCB Grant - Application DByCJ/HiPCi4QlzLkK7+eQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/06/2016 Application Dated: 09/06/2016 |
| KERLINK SA |
| 1 rue Jacqueline Auriol |
| THORIGNE FOUILLARD, 35235 France |
| Attention: YANNICK DELIBIE |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFYS-KLK915IBTSC |
| Name of Grantee: | KERLINK SA |
| Equipment Class: | Digital Transmission System |
| Notes: | LoRa gateway for IoT chain |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 923.3 - 927.5 | 0.452 |
| Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application DByCJ/HiPCi4QlzLkK7+eQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
KERLINK SA 1 rue Jacqueline Auriol THORIGNE FOUILLARD, 35235 France |
Date of Grant: 09/06/2016 Application Dated: 09/06/2016 |
| Attention: YANNICK DELIBIE |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AFYS-KLK915IBTSC |
| Name of Grantee: | KERLINK SA |
| Equipment Class: | Digital Transmission System |
| Notes: | LoRa gateway for IoT chain |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 923.3 - 927.5 | 0.452 |
| Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| Mail To: |
