FCC ID 2AFYU67287
Multi-Protocol Base Transceiver System (MPBTS)
by The KEYW Corporation
Grantee Code: 2AFYU Product Code: 67287
Latest application date: 2017-02-13
Device Images
FCC ID Device Details
| FCC ID | 2AFYU67287 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AFYU |
| Product Code | 67287 |
| Applicant Business | The KEYW Corporation 🇺🇸 |
| Related Domains |  keywcorp.com |
| Equipment Class | Multi-Protocol Base Transceiver System (MPBTS) |
| Test Firm | EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 734-746 MHz | Original Equipment | 2017-02-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Amplifier External Photos | External Photos | 2017-02-13 | PDF 640.4 KB |
| Duplexer External Photos | External Photos | 2017-02-13 | PDF 564.6 KB |
| Radio External Photos | External Photos | 2017-02-13 | PDF 405.1 KB |
| Label | ID Label/Location Info | 2017-02-13 | PDF 39.1 KB |
| Test Setup Photos | Test Setup Photos | 2017-02-13 | PDF 413.3 KB |
| Test Report - CDMA | Test Report | 2017-02-13 | PDF 2.5 MB |
| Test Report - GSM | Test Report | 2017-02-13 | PDF 1.8 MB |
| Test Report - LTE | Test Report | 2017-02-13 | PDF 5 MB |
| Test Report - WCDMA | Test Report | 2017-02-13 | PDF 2.3 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2017-02-13 | PDF 176.1 KB |
| FCC Correspondence | Cover Letter(s) | 2017-02-13 | PDF 16.5 KB |
| Antenna Datasheet - HUBER+SUHNER | RF Exposure Info | 2017-02-13 | PDF 107.2 KB |
| Antenna Datasheet - Laird Datasheet | RF Exposure Info | 2017-02-13 | PDF 1.3 MB |
| MPE | RF Exposure Info | 2017-02-13 | PDF 113.8 KB |
| User Guide Metadata only | Users Manual | PDF 1 MB | |
| Amplifier Internal Photos Metadata only | Internal Photos | PDF 732.5 KB | |
| Duplexer Internal Photos Metadata only | Internal Photos | PDF 649.5 KB | |
| Radio Internal Photos Metadata only | Internal Photos | PDF 713.4 KB | |
| BLOCK DIAGRAM Metadata only | Block Diagram | PDF 104.2 KB | |
| Dual WB Amp Schematic Metadata only | Schematics | PDF 44.5 KB | |
| Duplexer Schematic Metadata only | Schematics | PDF 69.3 KB | |
| Radio Schematic Metadata only | Schematics | PDF 50 KB | |
| Operational Description Metadata only | Operational Description | PDF 607.3 KB | |
| Security Document Metadata only | SDR Software/Security Inf | PDF 444.4 KB | |
| Amplifier BOM Metadata only | Parts List/Tune Up Info | PDF 21.4 KB | |
| Duplexer BOM Metadata only | Parts List/Tune Up Info | PDF 210 KB | |
| Radio BOM Metadata only | Parts List/Tune Up Info | PDF 21.7 KB |
Application Information
| Application ID | Og31upsHeFc5VgqF+XmgNw== |
|---|---|
| Final Action Date | 2017-02-13 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024896946 |
| Model | 67287 |
| Frequency Range | 734-746 MHz |
| Equipment Class | AMP - Amplifier |
| Device Description | Multi-Protocol Base Transceiver System (MPBTS) |
| Responsible Party | Gwen Pal, gpal@keywcorp.com , 4437331803 |
| Test Firm | Greg Kovolenko, EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC, greg.kovolenko@metlabs.com  , 4108444071 |
| TCB Email | tcbinfo@metlabs.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | The output power listed is conducted. RF exposure compliance is address at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of 1.1307(b)(3) |
