MHCWB4PIB 2.4 GHz Wi-Fi+BLE Dual-mode... - FCC ID 2AFZZMHCWB4P-IB

FCC ID 2AFZZMHCWB4P-IB

Int Photos

2.4 GHz Wi-Fi+BLE Dual-mode Module

by Xiaomi Communications Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AFZZMHCWB4P-IB
Document ID4724534
Document TypeInternal Photos
DescriptionInt Photos
ApplicantXiaomi Communications Co., Ltd.
Equipment Class2.4 GHz Wi-Fi+BLE Dual-mode Module
Product CodeMHCWB4PIB
Application IDDkllmUIKmf1+ryKSw5mi2w==
Application PurposeOriginal Equipment
Application Date2020-05-14
Frequency Range2402-2480 MHz
FRN0024904948
Test FirmBay Area Compliance Laboratories Corp.(Linkou Lab)
Certified ByXiaogang Jiao
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2020-05-14
Available2020-05-14
Created2020-04-27
Modified2020-04-27
Pages1
File TypeAdobe Acrobat PDF
File Size414717
File SHA-256bc49c2cf7146727b7dde6466ecbdebfaa218c5fa59796f2de2d310daf86a8d47
PDF Metadata AuthorTW211
PDF Metadata ProducerTW211 Microsoft® Word 2013
FCC.gov SourcesFCC.gov 4724534
