MBS1105 LTE-TDD Base Station Teardown... - FCC ID 2AG32MBS1105

FCC ID 2AG32MBS1105

Internal Photos

LTE-TDD Base Station

by Baicells Technologies Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AG32MBS1105
Document ID3427840
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleHD 271 S1
ApplicantBaicells Technologies Co., Ltd.
Equipment ClassLTE-TDD Base Station
Product CodeMBS1105
Application IDmKKEFUHLCxAXvkxKIIXS2A==
Application PurposeOriginal Equipment
Application Date2017-06-20
Frequency Range3655-3695 MHz
FRN0025156423
Test FirmShenzhen Zhongjian Nanfang Testing Co.,Ltd
Certified ByBruce Zhang EMC Laboratory Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-06-15
Available2017-06-20
Created2017-06-02
Modified2017-06-02
Pages3
File TypeAdobe Acrobat PDF
File Size720384
File SHA-2563cfc9750fee4122e97754cd67d37eccbc4635921a79143d57e1afeb5dd07e000
PDF Metadata AuthorLAB02
PDF Metadata ProducerLAB02 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 3427840
