FCC ID 2AG5B-WD03
WiFi hotspot + Power bank
by Shenzhen Unitone Electronics co.,Ltd
Grantee Code: 2AG5B Product Code: WD03
Latest application date: 2016-03-03
Device Images
FCC ID Device Details
| FCC ID | 2AG5B-WD03 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AG5B |
| Product Code | WD03 |
| Applicant Business | Shenzhen Unitone Electronics co.,Ltd 🇨🇳 |
| Related Domains |  unitone.com.cn |
| Equipment Class | WiFi hotspot + Power bank |
| Test Firm | Shenzhen Tongce Testing Lab |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-03-03 |
| 824.2-848.8 MHz | Original Equipment | 2016-03-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-03-03 | PDF 899.5 KB |
| Internal Photos | Internal Photos | 2016-03-03 | PDF 804.6 KB |
| External Photos | External Photos | 2016-03-03 | PDF 665.9 KB |
| FCC ID Label and Location | ID Label/Location Info | 2016-03-03 | PDF 101.7 KB |
| Test Setup Photos | Test Setup Photos | 2016-03-03 | PDF 1.5 MB |
| Test Setup Photos | Test Setup Photos | 2016-03-03 | PDF 152.3 KB |
| Test Setup Photos for PCB | Test Setup Photos | 2016-03-03 | PDF 119.8 KB |
| Test Report for DTS | Test Report | 2016-03-03 | PDF 5.9 MB |
| Test Report for JBP | Test Report | 2016-03-03 | PDF 1.2 MB |
| Test Report for PCB-1 | Test Report | 2016-03-03 | PDF 5 MB |
| Test Report for PCB-2 | Test Report | 2016-03-03 | PDF 4.3 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-03-03 | PDF 51 KB |
| Declaration Letter for Ad Hoc | Cover Letter(s) | 2016-03-03 | PDF 35.4 KB |
| POA | Cover Letter(s) | 2016-03-03 | PDF 77 KB |
| SAR Report-1 | RF Exposure Info | 2016-03-03 | PDF 5.1 MB |
| SAR Report-2 | RF Exposure Info | 2016-03-03 | PDF 5.4 MB |
| Block Diagram Metadata only | Block Diagram | PDF 168.6 KB | |
| Schematics Metadata only | Schematics | PDF 250.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 873.4 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 67.3 KB | |
| Tune Up Information Metadata only | Parts List/Tune Up Info | PDF 30.3 KB |
Application Information
| Application ID | ZA+YPvwYaebrTuqU6bp7dA== |
|---|---|
| Final Action Date | 2016-03-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025163171 |
| Model | WD03 |
| Equipment Class | JBP - Part 15 Class B Computing Device Peripheral |
| Device Description | WiFi hotspot + Power bank |
| Responsible Party | Ejun Qiu, Sales, qiuyuzhu@unitone.com.cn , 0755-22236666 |
| Test Firm | Charlle Lai, Shenzhen Tongce Testing Lab, 184199833@qq.com  , 15112400427 |
| TCB Email | bentje.holger@phoenix-testlab.de  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| ZA+YPvwYaebrTuqU6bp7dA== | 2016-03-03 | Original Equipment |
| UrMvg6goZWXJGHwISwyvBQ== | 2016-03-03 | Original Equipment |
| QY6eypjP5A1t75s5m8zrVQ== | 2016-03-03 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 15B | CC | ||||
| 824.2-848.8 MHz | 1.189 | 0.026ppm | 246KGXW | 22H | CC |
| 824.2-848.8 MHz | 0.275 | 0.024ppm | 243KG7W | 22H | CC |
| 826.4-846.6 MHz | 0.153 | 0.019ppm | 4M10F9W | 22H | CC |
| 1850.2-1909.8 MHz | 0.513 | 0.023ppm | 247KGXW | 24E | CC |
| 1850.2-1909.8 MHz | 0.325 | 0.02ppm | 247KG7W | 24E | CC |
| 1852.4-1907.6 MHz | 0.171 | 0.022ppm | 4M13F9W | 24E | CC |
| 2412-2462 MHz | 0.0256000 | 15C | CC |
Grants
TCB Grant - Application ZA+YPvwYaebrTuqU6bp7dA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 03/03/2016 Application Dated: 03/03/2016 |
| Shenzhen Unitone Electronics co.,Ltd |
| 13-14 Floor, Pengji Bussiness Mansion, |
| No.50, Bagua 1 Road, Futian District |
| Shenzhen, China |
| Attention: Ejun Qiu , Sales |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AG5B-WD03 |
| Name of Grantee: | Shenzhen Unitone Electronics co.,Ltd |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | WiFi hotspot + Power bank |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15B | - |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
