FCC ID 2AGFX-STACK002
ZigBee Module
by Stack Labs, Inc.
Grantee Code: 2AGFX Product Code: STACK002
Latest application date: 2016-08-11
Device Images
FCC ID Device Details
| FCC ID | 2AGFX-STACK002 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AGFX |
| Product Code | STACK002 |
| Applicant Business | Stack Labs, Inc. 🇺🇸 |
| Related Domains |  stacklighting.com |
| Equipment Class | ZigBee Module |
| Test Firm | ATLAS Compliance & Engineering, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2016-08-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-08-11 | PDF 92.9 KB |
| Internal Photos | Internal Photos | 2016-08-11 | PDF 50.3 KB |
| External Photos | External Photos | 2016-08-11 | PDF 75.6 KB |
| ID Label | ID Label/Location Info | 2016-08-11 | PDF 507.3 KB |
| ID Label Placement | ID Label/Location Info | 2016-08-11 | PDF 75.6 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-11 | PDF 141.2 KB |
| Test Report | Test Report | 2016-08-11 | PDF 939.6 KB |
| Confidentiality Request | Cover Letter(s) | 2016-08-11 | PDF 65.1 KB |
| Modular Approval Letter | Cover Letter(s) | 2016-08-11 | PDF 206.6 KB |
| RF Exposure Info | RF Exposure Info | 2016-08-11 | PDF 89.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 67.3 KB | |
| Schematics Metadata only | Schematics | PDF 512.4 KB | |
| Operational Description 1 Metadata only | Operational Description | PDF 102.8 KB | |
| Operational Description 2 Metadata only | Operational Description | PDF 263.8 KB | |
| Operational Description 3 Metadata only | Operational Description | PDF 46.6 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 48.3 KB |
Application Information
| Application ID | LdI8wFESbxx6wGs//ipBcQ== |
|---|---|
| Final Action Date | 2016-08-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025031949 |
| Model | STACK002 |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | ZigBee Module |
| Responsible Party | Kent Whiting, Regulatory, kwhiting@stacklighting.com , 4086070614 |
| Test Firm | Bruce Smith, ATLAS Compliance & Engineering, Inc., bruces@atlasce.com  , 4089719743 |
| TCB Email | tcbinfo@ckc.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is Conducted. Approved for installation into mobile RF exposure configurations with antenna to user separation distance >20cm; configurations with antenna to user separation distance <20cm may require separate assessment and approval. Approved for use with antenna(s) as listed in this filing |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| LdI8wFESbxx6wGs//ipBcQ== | 2016-08-11 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2405-2480 MHz | 0.0080000 | 15C |
Grants
TCB Grant - Application LdI8wFESbxx6wGs//ipBcQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
CKC Certification Services, LLC 5046 Sierra Pines Mariposa, CA 95338 |
Date of Grant: 08/11/2016 Application Dated: 08/11/2016 |
| Stack Labs, Inc. |
| 10054 Pasadena Avenue |
| Cupertino, CA 95014 |
| Attention: Kent Whiting , Regulatory |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGFX-STACK002 |
| Name of Grantee: | Stack Labs, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | ZigBee Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.008 |
| Power Output listed is Conducted. Approved for installation into mobile RF exposure configurations with antenna to user separation distance >20cm; configurations with antenna to user separation distance <20cm may require separate assessment and approval. Approved for use with antenna(s) as listed in this filing |
EAS Grant - Application LdI8wFESbxx6wGs//ipBcQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Stack Labs, Inc. 10054 Pasadena Avenue Cupertino, CA 95014 United States |
Date of Grant: 08/11/2016 Application Dated: 08/11/2016 |
| Attention: Kent Whiting , Regulatory |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGFX-STACK002 |
| Name of Grantee: | Stack Labs, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | ZigBee Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.008 |
| Power Output listed is Conducted. Approved for installation into mobile RF exposure configurations with antenna to user separation distance >20cm; configurations with antenna to user separation distance <20cm may require separate assessment and approval. Approved for use with antenna(s) as listed in this filing |
