FCC ID 2AGFX-STACK101
Microwave Sensor
by Stack Labs, Inc.
Grantee Code: 2AGFX Product Code: STACK101
Latest application date: 2016-06-08
Device Images
FCC ID Device Details
| FCC ID | 2AGFX-STACK101 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AGFX |
| Product Code | STACK101 |
| Applicant Business | Stack Labs, Inc. 🇺🇸 |
| Related Domains |  stacklighting.com |
| Equipment Class | Microwave Sensor |
| Test Firm | Dongguan Precise Testing Service Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5792.41 MHz | Original Equipment | 2016-06-08 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-06-08 | PDF 955.8 KB |
| Users Manual | Users Manual | 2016-06-08 | PDF 924.4 KB |
| Internal Photos | Internal Photos | 2016-06-08 | PDF 55.4 KB |
| External photos | External Photos | 2016-06-08 | PDF 369.4 KB |
| Label Location/Info | ID Label/Location Info | 2016-06-08 | PDF 116.4 KB |
| Test Setup Photos | Test Setup Photos | 2016-06-08 | PDF 338.2 KB |
| Test Report | Test Report | 2016-06-08 | PDF 1.9 MB |
| Authorization | Cover Letter(s) | 2016-06-08 | PDF 15.5 KB |
| Confidentiality Request | Cover Letter(s) | 2016-06-08 | PDF 107.5 KB |
| Modular Approval Letter | Cover Letter(s) | 2016-06-08 | PDF 176.1 KB |
| Block Diagram Metadata only | Block Diagram | PDF 40 KB | |
| Schematics Metadata only | Schematics | PDF 76.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 79.7 KB |
Application Information
| Application ID | W79SoKpYsDTLJ9ebB3o2DA== |
|---|---|
| Final Action Date | 2016-06-08 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025031949 |
| Model | STACK101 |
| Frequency Range | 5792.41 MHz |
| Equipment Class | FDS - Part 15 Field Disturbance Sensor |
| Device Description | Microwave Sensor |
| Responsible Party | Kent Whiting, Regulatory, kwhiting@stacklighting.com , 4086070614 |
| Technical Contact | Mark koop, Teleconformity, mark.koop@teleconformity.com  , (31)848395867 |
| Test Firm | Chris Du, Dongguan Precise Testing Service Co., Ltd., chris.du@pts-testing.com  , 86-769-8928-2919 |
| TCB Email | certification@micomlabs.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Modular Approval. Installations are limited to those hosts described in the filing which provide the necessary voltage regulators. OEM integrators must be instructed to ensure that the end-user has no manual instructions to remove or install the device. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| W79SoKpYsDTLJ9ebB3o2DA== | 2016-06-08 | Original Equipment |
Grants
TCB Grant - Application W79SoKpYsDTLJ9ebB3o2DA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
MiCOM Labs 575 Boulder Court Pleasanton, CA 94566 |
Date of Grant: 06/08/2016 Application Dated: 06/08/2016 |
| Stack Labs, Inc. |
| 10054 Pasadena Avenue |
| Cupertino, CA 95014 |
| Attention: Kent Whiting , Regulatory |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGFX-STACK101 |
| Name of Grantee: | Stack Labs, Inc. |
| Equipment Class: | Part 15 Field Disturbance Sensor |
| Notes: | Microwave Sensor |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 20 | 15.245 | 5792.41 - 5792.41 |
| Limited Modular Approval. Installations are limited to those hosts described in the filing which provide the necessary voltage regulators. OEM integrators must be instructed to ensure that the end-user has no manual instructions to remove or install the device. |
| 20: | All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed. |
EAS Grant - Application W79SoKpYsDTLJ9ebB3o2DA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Stack Labs, Inc. 10054 Pasadena Avenue Cupertino, CA 95014 United States |
Date of Grant: 06/08/2016 Application Dated: 06/08/2016 |
| Attention: Kent Whiting , Regulatory |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGFX-STACK101 |
| Name of Grantee: | Stack Labs, Inc. |
| Equipment Class: | Part 15 Field Disturbance Sensor |
| Notes: | Microwave Sensor |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 20 | 15.245 | 5792.41 - 5792.41 |
| Limited Modular Approval. Installations are limited to those hosts described in the filing which provide the necessary voltage regulators. OEM integrators must be instructed to ensure that the end-user has no manual instructions to remove or install the device. |
| 20: | All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed. |
