FCC ID 2AGG6FJZB101
zigbee module
by Wuhan Fenjin intelligent machine Co.,LTD
Grantee Code: 2AGG6 Product Code: FJZB101
Latest application date: 2015-12-16
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2015-12-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual Metadata only | Users Manual | 2015-12-16 | PDF 188.1 KB |
| User manual | Users Manual | 2015-12-16 | PDF 188.1 KB |
| Internal Photos | Internal Photos | 2015-12-16 | PDF 267.8 KB |
| External Photos | External Photos | 2015-12-16 | PDF 267.8 KB |
| Label | ID Label/Location Info | 2015-12-16 | PDF 56.6 KB |
| Test Set Up Photos | Test Setup Photos | 2015-12-16 | PDF 385 KB |
| Test Report | Test Report | 2015-12-16 | PDF 1.8 MB |
| Cover letter | Cover Letter(s) | 2015-12-16 | PDF 119 KB |
| Declaration | Cover Letter(s) | 2015-12-16 | PDF 119 KB |
| Limited Modular Approval Letter | Cover Letter(s) | 2015-12-16 | PDF 239.6 KB |
| Request for Non-disclosure | Cover Letter(s) | 2015-12-16 | PDF 1.2 MB |
| RF Safety | RF Exposure Info | 2015-12-16 | PDF 60.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 80.9 KB | |
| Schematics Metadata only | Schematics | PDF 92.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 53 KB |
Application Information
| Application ID | 8G+MID8Tuek+XexiuXDR9w== |
|---|---|
| Final Action Date | 2015-12-16 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025044702 |
| Model | FJZB101 |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | zigbee module |
| Responsible Party | Hui Huang, VP, huangh@fenjin.com  , 18627106330 |
| Test Firm | Daisy Dai, BTL Inc., daisy.dai@btl.org.cn  , 008676983183000 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Single Modular Approval. Power output listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 8G+MID8Tuek+XexiuXDR9w== | 2015-12-16 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2405-2480 MHz | 0.0190000 | 15C |
Grants
TCB Grant - Application 8G+MID8Tuek+XexiuXDR9w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 12/16/2015 Application Dated: 12/16/2015 |
| Wuhan Fenjin intelligent machine Co.,LTD |
| No.25,Gaoxin 4th,East Lake Hi-Tech |
| Development Zone,Fenjin Industrial |
| Wuhan, 430000 China |
| Attention: Hui Huang , VP |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGG6FJZB101 |
| Name of Grantee: | Wuhan Fenjin intelligent machine Co.,LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | zigbee module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.019 |
| Limited Single Modular Approval. Power output listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
EAS Grant - Application 8G+MID8Tuek+XexiuXDR9w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Wuhan Fenjin intelligent machine Co.,LTD No.25,Gaoxin 4th,East Lake Hi-Tech Development Zone,Fenjin Industrial Wuhan, 430000 China |
Date of Grant: 12/16/2015 Application Dated: 12/16/2015 |
| Attention: Hui Huang , VP |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGG6FJZB101 |
| Name of Grantee: | Wuhan Fenjin intelligent machine Co.,LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | zigbee module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.019 |
| Limited Single Modular Approval. Power output listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
