FCC ID 2AGJ3R-8070-450MHZ
TETRA BASE STATION TRANSCEIVER
by Rohill Engineering B.V.
Grantee Code: 2AGJ3 Product Code: R8070450MHZ
Latest application date: 2016-03-11
Device Images
FCC ID Device Details
| FCC ID | 2AGJ3R-8070-450MHZ |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AGJ3 |
| Product Code | R8070450MHZ |
| Applicant Business | Rohill Engineering B.V. 🇳🇱 |
| Related Domains |  rohill.nl  timcoengr.com |
| Equipment Class | TETRA BASE STATION TRANSCEIVER |
| Test Firm | Timco Engineering, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 450-470 MHz | Original Equipment | 2016-03-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-09-07 | PDF 860.8 KB |
| Internal photos | Internal Photos | 2016-09-07 | PDF 1.5 MB |
| External Photos | External Photos | 2016-09-07 | PDF 387.4 KB |
| Label location | ID Label/Location Info | 2016-03-11 | PDF 127.5 KB |
| Label sample | ID Label/Location Info | 2016-03-11 | PDF 2.7 MB |
| Test Set Up Photos | Test Setup Photos | 2016-03-11 | PDF 2 MB |
| Test Report | Test Report | 2016-03-11 | PDF 3.4 MB |
| Tuning Attestation per 90.203 | Attestation Statements | 2016-03-11 | PDF 158.5 KB |
| Confidentiality request letter | Cover Letter(s) | 2016-03-11 | PDF 332.3 KB |
| Frequency Justification letter | Cover Letter(s) | 2016-03-11 | PDF 233.2 KB |
| RF Exposure Statement | RF Exposure Info | 2016-03-11 | PDF 182.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 1.7 MB | |
| Schematic Metadata only | Schematics | PDF 3.7 MB | |
| Schematic - RX Metadata only | Schematics | PDF 2 MB | |
| Operational Description Metadata only | Operational Description | PDF 744.6 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 3.1 MB | |
| Tuning Procedure Metadata only | Parts List/Tune Up Info | PDF 744.6 KB |
Application Information
| Application ID | GGr8w1zn/zuKg3zJZLX6dw== |
|---|---|
| Final Action Date | 2016-03-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025049347 |
| Model | R-8070-450MHZ |
| Frequency Range | 450-470 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | TETRA BASE STATION TRANSCEIVER |
| Responsible Party | Lenard Molhoek, Product/Production Manager, productmanagement@rohill.nl , 0031528263355 |
| Technical Contact | Cory Leverett, Timco Engineering, Inc., tei@timcoengr.com , 8884272424 |
| Non-Technical Contact | Sharon Hoffman, Timco Engineering, Inc., tei@timcoengr.com , 8884272424 |
| Test Firm | Bruno Clavier, Timco Engineering, Inc., bruno@timcoengr.com , 352-472-5500 |
| TCB Email | tei@timcoengr.com |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 09/07/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted . The antennas used for this transmitter must be fixed-mounted on outdoor permanent structures and installed to provide a separation distance from all persons as documented in this filing. When antennas are co-located with other transmitters or transmit antennas, RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC bureau(s), per 47 CFR § 1.1307(b)(3). End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| GGr8w1zn/zuKg3zJZLX6dw== | 2016-03-11 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application GGr8w1zn/zuKg3zJZLX6dw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 03/11/2016 Application Dated: 03/11/2016 |
| Rohill Engineering B.V. |
| Edisonstraat 12 |
| 373, 7900 AJ Hoogeveen |
| Hoogeveen, 7903 AN Netherlands |
| Attention: Lenard Molhoek , Product/Production Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGJ3R-8070-450MHZ |
| Name of Grantee: | Rohill Engineering B.V. |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | TETRA BASE STATION TRANSCEIVER |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| EF | 90 | 450.0 - 470.0 | 40.0 | 0.46 PM | 22K0G7W |
| Power listed is conducted . The antennas used for this transmitter must be fixed-mounted on outdoor permanent structures and installed to provide a separation distance from all persons as documented in this filing. When antennas are co-located with other transmitters or transmit antennas, RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC bureau(s), per 47 CFR § 1.1307(b)(3). End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| EF: | This device may contain functions that are not operational in U.S Territories except as noted in the filing. This grant has extended frequencies as noted in the filing and Section 2.927(b) applies to this authorization. |
EAS Grant - Application GGr8w1zn/zuKg3zJZLX6dw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Rohill Engineering B.V. Edisonstraat 12 373, 7900 AJ Hoogeveen Hoogeveen, 7903 AN Netherlands |
Date of Grant: 03/11/2016 Application Dated: 03/11/2016 |
| Attention: Lenard Molhoek , Product/Production Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGJ3R-8070-450MHZ |
| Name of Grantee: | Rohill Engineering B.V. |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | TETRA BASE STATION TRANSCEIVER |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| EF | 90 | 450.0 - 470.0 | 40.0 | 0.46 PM | 22K0G7W |
| Power listed is conducted . The antennas used for this transmitter must be fixed-mounted on outdoor permanent structures and installed to provide a separation distance from all persons as documented in this filing. When antennas are co-located with other transmitters or transmit antennas, RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC bureau(s), per 47 CFR § 1.1307(b)(3). End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| EF: | This device may contain functions that are not operational in U.S Territories except as noted in the filing. This grant has extended frequencies as noted in the filing and Section 2.927(b) applies to this authorization. |
