MDX240958B EVO Max Test Setup Photos - FCC ID 2AGNTMDX240958B

FCC ID 2AGNTMDX240958B

Test Setup Photos

EVO Max

by Autel Robotics Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AGNTMDX240958B
Document ID7986953
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleTest Setup Photos NII
ApplicantAutel Robotics Co., Ltd.
Equipment ClassEVO Max
Product CodeMDX240958B
Application IDFL3C2LauQ30bVLMzx9RfKg==
Application PurposeOriginal Equipment
Application Date2025-01-16
Frequency Range5154-5246 MHz
FRN0025070863
Test FirmBay Area Compliance Laboratories Corp. (Dongguan)
Certified ByXiangxi Pan
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/15/2025
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2025-01-16
Available2025-07-15
Created2024-07-31
Modified2024-07-31
Pages4
File TypeAdobe Acrobat PDF
File Size565182
File SHA-256ffef6beaa3a6462013166accd69362aa4ad4f4db13e951723208ea6d2405e804
PDF Metadata AuthorCNAS07
PDF Metadata ProducerAcrobat Distiller 11.0 (Windows) CNAS07
FCC.gov SourcesFCC.gov 7986953
