FCC ID 2AGP4-PCDTN500
4G LTE Router support band 4 and 42
by Quality One Wireless LLC
Grantee Code: 2AGP4 Product Code: PCDTN500
Latest application date: 2016-01-18
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-01-18 |
| 1715-1750 MHz | Original Equipment | 2016-01-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-01-18 | PDF 1,005.2 KB |
| Internal photos | Internal Photos | 2016-01-18 | PDF 655.3 KB |
| External photos | External Photos | 2016-01-18 | PDF 682.8 KB |
| Label | ID Label/Location Info | 2016-01-18 | PDF 440.4 KB |
| Test setup | Test Setup Photos | 2016-01-18 | PDF 218.8 KB |
| Test setup | Test Setup Photos | 2016-01-18 | PDF 47.7 KB |
| Test report part 1 | Test Report | 2016-01-18 | PDF 3.4 MB |
| Test report part 1 | Test Report | 2016-01-18 | PDF 5.4 MB |
| Test report part 2 | Test Report | 2016-01-18 | PDF 5.2 MB |
| Test report part 2 | Test Report | 2016-01-18 | PDF 4.1 MB |
| Test report part 3 | Test Report | 2016-01-18 | PDF 4.6 MB |
| Test report part 3 | Test Report | 2016-01-18 | PDF 4.1 MB |
| Cover letter | Cover Letter(s) | 2016-01-18 | PDF 20 KB |
| RF Exposure | RF Exposure Info | 2016-01-18 | PDF 30 KB |
| RF Exposure | RF Exposure Info | 2016-01-18 | PDF 30 KB |
| Block Diagram Metadata only | Block Diagram | PDF 41.9 KB | |
| Schematics Metadata only | Schematics | PDF 406.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 297.5 KB | |
| Tune up Metadata only | Parts List/Tune Up Info | PDF 32.6 KB |
Application Information
| Application ID | xvtr3LEeMHZwx+L0bJ+zwg== |
|---|---|
| Final Action Date | 2016-01-18 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025092131 |
| Model | PCDTN500 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 4G LTE Router support band 4 and 42 |
| Responsible Party | Dave Alberico, dave.alberico@q1w.net  , 407-856-2631 |
| Test Firm | Tracy Qi, Shenzhen CTL Testing Technology Co., Ltd., qihui@ctl-lab.com  , 86-755-89486194 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is aggregate conducted output power. This device has a 20 MHz and 40 MHz bandwidth mode, and operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| xvtr3LEeMHZwx+L0bJ+zwg== | 2016-01-18 | Original Equipment |
| D04hWBdgoskKVSHc7ayTNw== | 2016-01-18 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application xvtr3LEeMHZwx+L0bJ+zwg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 01/18/2016 Application Dated: 01/18/2016 |
| Quality One Wireless LLC |
| 1500 Tradeport Drive |
| ORLANDO, FL 32824 |
| Attention: Dave Alberico |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AGP4-PCDTN500 |
| Name of Grantee: | Quality One Wireless LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | 4G LTE Router support band 4 and 42 |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.242 |
| Power listed is aggregate conducted output power. This device has a 20 MHz and 40 MHz bandwidth mode, and operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
