WMIOT601V10 WiFi Module Teardown... - FCC ID 2AGQ7WMIOT601V10
FCC ID 2AGQ7WMIOT601V10
Internal Photos
WiFi Module
Document preview loads when visible.
Document Details
| FCC ID | 2AGQ7WMIOT601V10 |
|---|---|
| Document ID | 3918296 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | Beijing Winner Microelectronics Co., Ltd. |
| Equipment Class | WiFi Module |
| Product Code | WMIOT601V10 |
| Application ID | oTUG2Xw10Xo9QqobtAIgWQ== |
| Application Purpose | Original Equipment |
| Application Date | 2018-07-10 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0025099763 |
| Test Firm | Shenzhen BCTC Testing Co., Ltd. |
| Certified By | Xiao feng Hou |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2018-07-10 |
| Available | 2018-07-10 |
| Created | 2018-06-25 |
| Modified | 2018-07-03 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 239446 |
| File SHA-256 | a1918dc19882c90ec684d7c05fd91e56e8e27a05bbcd06f7d3dd08ede8e7335d |
| PDF Metadata Author | bctcfy11 |
| PDF Metadata Producer | bctcfy11 Adobe PDF Library 9.0 |
| FCC.gov Sources | FCC.gov 3918296 |
