242 Smart Aerial ADC242 Label Diagram - FCC ID 2AGRI242
FCC ID 2AGRI242
id label
Smart Aerial ADC242
Document preview loads when visible.
Document Details
| FCC ID | 2AGRI242 |
|---|---|
| Document ID | 2903572 |
| Document Type | ID Label/Location Info |
| Description | id label |
| Applicant | Advanced Diagnostics |
| Equipment Class | Smart Aerial ADC242 |
| Product Code | 242 |
| Application ID | ItIcLs1zSsppa17BhbSuMw== |
| Application Purpose | Original Equipment |
| Application Date | 2016-02-16 |
| Frequency Range | 0.125 MHz |
| FRN | 0025100546 |
| Test Firm | Element Materials Technology Warwick Ltd |
| Certified By | Robert Collier Software Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2016-02-16 |
| Available | 2016-02-16 |
| Created | 2016-01-08 |
| Modified | 2016-01-08 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 45659 |
| File SHA-256 | 6a3eefaa1988e9c2652e0adc20d7d069722b0d7aeec0404e311fd8602977f6bc |
| PDF Metadata Producer | Foxit PhantomPDF Printer Version 6.0.3.0513 |
| FCC.gov Sources | FCC.gov 2903572 |
