BFIDM10 RFID Reader Test Setup Photos - FCC ID 2AGZY-BFIDM10

FCC ID 2AGZY-BFIDM10

Test setup photos

RFID Reader

by Balluff GmbH

Document preview loads when visible.

Document Details

FCC ID2AGZY-BFIDM10
Document ID3973255
Document TypeTest Setup Photos
DescriptionTest setup photos
Document TitleDDT-R18011504-1E5 BFIDM10 FCC&IC ID Report
ApplicantBalluff GmbH
Equipment ClassRFID Reader
Product CodeBFIDM10
Application IDMG33SB+Qbcjd/27GyqQwNg==
Application PurposeOriginal Equipment
Application Date2018-08-22
Frequency Range13.56 MHz
FRN0025147513
Test FirmDongguan Dongdian Testing Service Co., Ltd.
Certified ByNorbert Popp Division Manager Identification
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2018-08-22
Available2018-08-22
Created2018-08-09
Modified2018-08-21
Pages1
File TypeAdobe Acrobat PDF
File Size159773
File SHA-256ef6bc8ff77bb94c6a375bb84e353137c736de2742bdee0a5c219ab44bee20bbe
PDF Metadata AuthorSherry
PDF Metadata ProducerSherry Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 3973255
