W1301 POS System Test Setup Photos - FCC ID 2AH25W1301

FCC ID 2AH25W1301

W1301W1303 19 NFC test setup

POS System

by Shanghai Sunmi Technology Co.,Ltd.

Document preview loads when visible.

Document Details

FCC ID2AH25W1301
Document ID3713489
Document TypeTest Setup Photos
DescriptionW1301W1303 19 NFC test setup
Document TitleRXA1711-0369RF02R1 POS FCC CYZ 11.22Part15C-NFC
ApplicantShanghai Sunmi Technology Co.,Ltd.
Equipment ClassPOS System
Product CodeW1301
Application IDl19pKvwulynjXxDoP6YLeg==
Application PurposeOriginal Equipment
Application Date2018-01-16
Frequency Range13.56 MHz
FRN0025501644
Test FirmIndustrial Internet Innovation Center (Shanghai)
Certified ByZhang Wentang Certification Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2018-01-15
Available2018-01-16
Created2018-01-10
Modified2018-01-10
Pages2
File TypeAdobe Acrobat PDF
File Size295828
File SHA-256c8e82b3c5a4ea8d3ee156b3e2f0fc4e83ab0d9a1af7aa9e3bb04f17a839abc7c
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 3713489
