FCC ID 2AH3X-M001
IEEE 802.11 b/g/n WLAN Microcontroller Module
by Aigale Corporation
Grantee Code: 2AH3X Product Code: M001
Latest application date: 2016-06-01
Device Images
FCC ID Device Details
| FCC ID | 2AH3X-M001 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AH3X |
| Product Code | M001 |
| Applicant Business | Aigale Corporation 🇨🇳 |
| Related Domains |  aigale.com |
| Equipment Class | IEEE 802.11 b/g/n WLAN Microcontroller Module |
| Test Firm | Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-06-01 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-08-30 | PDF 903.9 KB |
| Internal Photos | Internal Photos | 2016-08-30 | PDF 148.6 KB |
| External Photos | External Photos | 2016-08-30 | PDF 2 MB |
| ID Label Location Information | ID Label/Location Info | 2016-06-01 | PDF 32.6 KB |
| Test Setup Photo | Test Setup Photos | 2016-08-30 | PDF 1.4 MB |
| Test Report | Test Report | 2016-06-01 | PDF 1.4 MB |
| Attestation - Channel and Mode Declaration | Attestation Statements | 2016-06-01 | PDF 147.3 KB |
| Cover Letter - Agent Authorization | Cover Letter(s) | 2016-06-01 | PDF 193 KB |
| Cover Letter - Confidentiality Request - Long Term rev | Cover Letter(s) | 2016-06-01 | PDF 224.6 KB |
| Cover Letter - Confidentiality Request - Short Term (90 DAYS).pdf | Cover Letter(s) | 2016-06-01 | PDF 179.8 KB |
| Modular Approval Request | Cover Letter(s) | 2016-06-01 | PDF 18.2 KB |
| RF Exposure Information (MPE) | RF Exposure Info | 2016-06-01 | PDF 190.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 205.6 KB | |
| Schematics Metadata only | Schematics | PDF 68.6 KB | |
| Technical Description Metadata only | Operational Description | PDF 61.6 KB |
Application Information
| Application ID | Jxs9x/i1N+8hzQ7tvVDYOA== |
|---|---|
| Final Action Date | 2016-06-01 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025509001 |
| Model | M001 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | IEEE 802.11 b/g/n WLAN Microcontroller Module |
| Responsible Party | Patrick Lin, Director, Patrick.Lin@aigale.com , +86-21-51916666 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-(0)3-260-0884 |
| TCB Email | certification@curtis-straus.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 08/30/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
