FCC ID 2AH7N-SNES30
GamePad
by 8BITDO TECHNOLOGY HK LIMITED
Grantee Code: 2AH7N Product Code: SNES30
Latest application date: 2016-05-09
Device Images
FCC ID Device Details
| FCC ID | 2AH7N-SNES30 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AH7N |
| Product Code | SNES30 |
| Applicant Business | 8BITDO TECHNOLOGY HK LIMITED |
| Related Domains |  8bitdo.com |
| Equipment Class | GamePad |
| Test Firm | Shenzhen Anbotek Compliance Laboratory Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-05-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-05-09 | PDF 75.1 KB |
| Internal Photos | Internal Photos | 2016-05-09 | PDF 325.6 KB |
| External Photos | External Photos | 2016-05-09 | PDF 445.9 KB |
| Label | ID Label/Location Info | 2016-05-09 | PDF 9.5 KB |
| Label Location | ID Label/Location Info | 2016-05-09 | PDF 51.2 KB |
| RF Test Set-Up Photos | Test Setup Photos | 2016-05-09 | PDF 815.7 KB |
| RF Test Report | Test Report | 2016-05-09 | PDF 3.7 MB |
| Authorization Letter | Cover Letter(s) | 2016-05-09 | PDF 1.3 MB |
| Family Models Letter | Cover Letter(s) | 2016-05-09 | PDF 14.8 KB |
| LTC Letter | Cover Letter(s) | 2016-05-09 | PDF 21.6 KB |
| RF Exposure Report | RF Exposure Info | 2016-05-09 | PDF 164.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 9.8 KB | |
| Schematics Metadata only | Schematics | PDF 154.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 25.3 KB |
Application Information
| Application ID | 7m/RN9p/v8MKEPZXeG4UyQ== |
|---|---|
| Final Action Date | 2016-05-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025527268 |
| Model | SNES30 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | GamePad |
| Responsible Party | Huijiang Tan, Project Manager, romman@8bitdo.com , 852-60665744 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum conducted output power. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 7m/RN9p/v8MKEPZXeG4UyQ== | 2016-05-09 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0014500 | 15C |
Grants
TCB Grant - Application 7m/RN9p/v8MKEPZXeG4UyQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 05/09/2016 Application Dated: 05/09/2016 |
| 8BITDO TECHNOLOGY HK LIMITED |
| Rooms 1318-19, 13/F, Hollywood Plaza, |
| 610 Nathan Road, Mongkok, |
| Kowloon, Hong Kong |
| Attention: Huijiang Tan , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AH7N-SNES30 |
| Name of Grantee: | 8BITDO TECHNOLOGY HK LIMITED |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | GamePad |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00145 |
| Power listed is the maximum conducted output power. |
EAS Grant - Application 7m/RN9p/v8MKEPZXeG4UyQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
8BITDO TECHNOLOGY HK LIMITED Rooms 1318-19, 13/F, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong |
Date of Grant: 05/09/2016 Application Dated: 05/09/2016 |
| Attention: Huijiang Tan , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AH7N-SNES30 |
| Name of Grantee: | 8BITDO TECHNOLOGY HK LIMITED |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | GamePad |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00145 |
| Power listed is the maximum conducted output power. |
