FCC ID 2AHC7OEH01
OCCUPEYE OEH01 - OCCUPANCY MONITORING SYSTEM HOST
by CAD-CAPTURE GROUP LIMITED
Grantee Code: 2AHC7 Product Code: OEH01
Latest application date: 2016-03-10
Device Images
FCC ID Device Details
| FCC ID | 2AHC7OEH01 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AHC7 |
| Product Code | OEH01 |
| Applicant Business | CAD-CAPTURE GROUP LIMITED 🇬🇧 |
| Related Domains |  cadcap.co.uk |
| Equipment Class | OCCUPEYE OEH01 - OCCUPANCY MONITORING SYSTEM HOST |
| Test Firm | Element Materials Technology Warwick Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 910.5-918.1 MHz | Original Equipment | 2016-03-10 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-03-10 | PDF 165.9 KB |
| Internal Photos | Internal Photos | 2016-03-10 | PDF 1.9 MB |
| External Photos | External Photos | 2016-03-10 | PDF 84.4 KB |
| ID Label and Location | ID Label/Location Info | 2016-03-10 | PDF 79.8 KB |
| Test Setup Photos | Test Setup Photos | 2016-03-10 | PDF 363.1 KB |
| Test Report | Test Report | 2016-03-10 | PDF 987.5 KB |
| Letter of Agency | Attestation Statements | 2016-03-10 | PDF 60.7 KB |
| Cover Letter | Cover Letter(s) | 2016-03-10 | PDF 60.4 KB |
| RF Exposure | RF Exposure Info | 2016-03-10 | PDF 55.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 36.2 KB | |
| Schematics Metadata only | Schematics | PDF 86.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 33.3 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 26.8 KB |
Application Information
| Application ID | LUBckZMbaDrphzCVrkPyug== |
|---|---|
| Final Action Date | 2016-03-10 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025097635 |
| Model | OEH01 |
| Frequency Range | 910.5-918.1 MHz |
| Equipment Class | DXT - Part 15 Low Power Transceiver, Rx Verified |
| Device Description | OCCUPEYE OEH01 - OCCUPANCY MONITORING SYSTEM HOST |
| Responsible Party | Simon Watts, Chief Executive, simon.watts@cadcap.co.uk , 01254 504400 |
| Test Firm | Stewart Barrowclough, Element Materials Technology Warwick Ltd, stewart.barrowclough@element.com  , 01695556666 |
| TCB Email | roy.ediss@element.com |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | RF Output power is conducted. This transmitter and antenna(s) must be installed to provide a separation distance of at least 20 cm from all persons. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| LUBckZMbaDrphzCVrkPyug== | 2016-03-10 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 910.5-918.1 MHz | 0.0030300 | 15C |
Grants
TCB Grant - Application LUBckZMbaDrphzCVrkPyug==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Element Materials Technology Warwick Ltd Rothwell Road Warwick Warwick, CV34 5JX United Kingdom |
Date of Grant: 03/10/2016 Application Dated: 03/10/2016 |
| CAD-CAPTURE GROUP LIMITED |
| Barnfield House |
| Accrington Road |
| Blackburn, BB1 3NY United Kingdom |
| Attention: Simon Watts , Chief Executive |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHC7OEH01 |
| Name of Grantee: | CAD-CAPTURE GROUP LIMITED |
| Equipment Class: | Part 15 Low Power Transceiver, Rx Verified |
| Notes: | OCCUPEYE OEH01 - OCCUPANCY MONITORING SYSTEM HOST |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 910.5 - 918.1 | 0.00303 |
| RF Output power is conducted. This transmitter and antenna(s) must be installed to provide a separation distance of at least 20 cm from all persons. |
EAS Grant - Application LUBckZMbaDrphzCVrkPyug==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
CAD-CAPTURE GROUP LIMITED Barnfield House Accrington Road Blackburn, BB1 3NY United Kingdom |
Date of Grant: 03/10/2016 Application Dated: 03/10/2016 |
| Attention: Simon Watts , Chief Executive |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHC7OEH01 |
| Name of Grantee: | CAD-CAPTURE GROUP LIMITED |
| Equipment Class: | Part 15 Low Power Transceiver, Rx Verified |
| Notes: | OCCUPEYE OEH01 - OCCUPANCY MONITORING SYSTEM HOST |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 910.5 - 918.1 | 0.00303 |
| RF Output power is conducted. This transmitter and antenna(s) must be installed to provide a separation distance of at least 20 cm from all persons. |
