Shenzhen Zhongjian Nanfang Testing Co., Ltd.
Report No: CCISE160600402
Cover Page
FCC REPORT
(Bluetooth)
Applicant:
NEXUS TELECOM SERVICES (HK) LIMITED
Address of Applicant:
R112, 11/F Hollywood Plaza, Mangkok, Kowloon, Hong Kong
Equipment Under Test (EUT)
Product Name:
Mobile Phone
Model No.:
GO182
Trade mark:
GOMOBILE
FCC ID:
2AHDFGO182
Applicable standards:
FCC CFR Title 47 Part 15 Subpart C Section 15.247
Date of sample receipt:
01 Jun., 2016
Date of Test:
01 Jun., to 12 Jun., 2016
Date of report issued:
13 Jun., 2016
Test Result:
PASS*
In the configuration tested, the EUT complied with the standards specified above.
Authorized Signature:
Bruce Zhang
Laboratory Manager
This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other
samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all
products in series production are in conformity with the product sample detailed in this report.
This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in
the report, the manufacturer must ensure the new system complies with all relevant standards.
This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or
falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law.
Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days
only.
Report No: CCISE160600402
Version
Version No.
Date
Description
00
13 Jun., 2016
Original
Tested by:
Date:
13 Jun., 2016
Date:
13 Jun., 2016
Test Engineer
Reviewed by:
Project Engineer
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 2 of 63
Report No: CCISE160600402
Contents
Page
COVER PAGE ....................................................................................................................................................... 1
VERSION ............................................................................................................................................................... 2
CONTENTS ........................................................................................................................................................... 3
TEST SUMMARY .................................................................................................................................................. 4
GENERAL INFORMATION .................................................................................................................................. 5
5.1
5.2
5.3
5.4
5.5
5.6
5.7
CLIENT INFORMATION ...................................................................................................................................................... 5
GENERAL DESCRIPTION OF E.U.T. ...................................................................................................................................... 5
TEST MODE .................................................................................................................................................................... 7
MEASUREMENT UNCERTAINTY ........................................................................................................................................... 7
LABORATORY FACILITY ...................................................................................................................................................... 7
LABORATORY LOCATION ................................................................................................................................................... 7
TEST INSTRUMENTS LIST.................................................................................................................................................... 8
TEST RESULTS AND MEASUREMENT DATA ................................................................................................ 9
6.1 ANTENNA REQUIREMENT .................................................................................................................................................. 9
6.2 CONDUCTED EMISSIONS ................................................................................................................................................. 10
6.3 CONDUCTED OUTPUT POWER.......................................................................................................................................... 13
6.4 20DB OCCUPY BANDWIDTH ............................................................................................................................................ 17
6.5 CARRIER FREQUENCIES SEPARATION.................................................................................................................................. 21
6.6 HOPPING CHANNEL NUMBER .......................................................................................................................................... 26
6.7 DWELL TIME................................................................................................................................................................. 28
6.8 PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ............................................................................................................. 32
6.9 BAND EDGE.................................................................................................................................................................. 33
6.9.1 Conducted Emission Method...................................................................................................................... 33
6.9.2 Radiated Emission Method ......................................................................................................................... 37
6.10
SPURIOUS EMISSION ................................................................................................................................................. 50
6.10.1
Conducted Emission Method ................................................................................................................. 50
6.10.2
Radiated Emission Method .................................................................................................................... 57
TEST SETUP PHOTO ........................................................................................................................................ 62
EUT CONSTRUCTIONAL DETAILS................................................................................................................. 63
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 3 of 63
Report No: CCISE160600402
Test Summary
Test Item
Section in CFR 47
Result
Antenna Requirement
15.203/15.247 (c)
Pass
AC Power Line Conducted Emission
15.207
Pass
Conducted Peak Output Power
15.247 (b)(1)
Pass
20dB Occupied Bandwidth
15.247 (a)(1)
Pass
Carrier Frequencies Separation
15.247 (a)(1)
Pass
Hopping Channel Number
15.247 (a)(1)
Pass
Dwell Time
15.247 (a)(1)
Pass
Radiated Emission
15.205/15.209
Pass
Band Edge
15.247(d)
Pass
Pass: The EUT complies with the essential requirements in the standard.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 4 of 63
Report No: CCISE160600402
General Information
5.1 Client Information
Applicant:
NEXUS TELECOM SERVICES (HK) LIMITED
Address of Applicant:
R112, 11/F Hollywood Plaza, Mangkok, Kowloon, Hong Kong
Manufacturer:
UTIME TECHNOLOGY (HK) COMPANY LIMITED
Address of Manufacturer:
RM 604 KAI WONG COMM BLDG 222 QUEEN'S RD CENTRAL HONG
KONG
5.2 General Description of E.U.T.
Product Name:
Mobile Phone
Model No.:
GO182
Operation Frequency:
2402MHz~2480MHz
Transfer rate:
1/2/3 Mbits/s
Number of channel:
79
Modulation type:
GFSK, π/4-DQPSK, 8DPSK
Modulation technology:
FHSS
Antenna Type:
Internal Antenna
Antenna gain:
-3.83 dBi
Power supply:
Rechargeable Li-ion Battery DC3.7V-600mAh
AC adapter:
Input: AC100-240V 50/60Hz 0.1A
Output: DC 5.0V, 0.5A
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 5 of 63
Report No: CCISE160600402
Operation Frequency each of channel for GFSK, π/4-DQPSK, 8DPSK
Channel
Frequency
Channel
Frequency
Channel
Frequency
Channel
Frequency
2402MHz
20
2422MHz
40
2442MHz
60
2462MHz
2403MHz
21
2423MHz
41
2443MHz
61
2463MHz
2404MHz
22
2424MHz
42
2444MHz
62
2464MHz
2405MHz
23
2425MHz
43
2445MHz
63
2465MHz
2406MHz
24
2426MHz
44
2446MHz
64
2466MHz
2407MHz
25
2427MHz
45
2447MHz
65
2467MHz
2408MHz
26
2428MHz
46
2448MHz
66
2468MHz
2409MHz
27
2429MHz
47
2449MHz
67
2469MHz
2410MHz
28
2430MHz
48
2450MHz
68
2470MHz
2411MHz
29
2431MHz
49
2451MHz
69
2471MHz
10
2412MHz
30
2432MHz
50
2452MHz
70
2472MHz
11
2413MHz
31
2433MHz
51
2453MHz
71
2473MHz
12
2414MHz
32
2434MHz
52
2454MHz
72
2474MHz
13
2415MHz
33
2435MHz
53
2455MHz
73
2475MHz
14
2416MHz
34
2436MHz
54
2456MHz
74
2476MHz
15
2417MHz
35
2437MHz
55
2457MHz
75
2477MHz
16
2418MHz
36
2438MHz
56
2458MHz
76
2478MHz
17
2419MHz
37
2439MHz
57
2459MHz
77
2479MHz
18
2420MHz
38
2440MHz
58
2460MHz
78
2480MHz
19
2421MHz
39
2441MHz
59
2461MHz
Remark: Channel 0, 39 &78 selected for GFSK, π/4-DQPSK and 8DPSK.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 6 of 63
Report No: CCISE160600402
5.3 Test mode
Transmitting mode:
Keep the EUT in transmitting mode with worst case data rate.
Remark
GFSK (1 Mbps) is the worst case mode.
The sample was placed 0.8m(below 1GHz)/1.5m(above 1GHz) above the ground plane of 3m chamber*.
Measurements in both horizontal and vertical polarities were performed. During the test, each emission was
maximized by: having the EUT continuously working with a fresh battery, investigated all operating modes,
rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating
interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in both horizontal and
vertical polarizations. The emissions worst-case are shown in Test Results of the following pages.
5.4 Measurement Uncertainty
Items
Conducted Emission (9kHz ~ 30MHz)
Radiated Emission (9kHz ~ 30MHz)
Radiated Emission (30MHz ~ 1000MHz)
Radiated Emission (1GHz ~ 18GHz)
Radiated Emission (18GHz ~ 26.5GHz)
Expanded Uncertainty (Confidence of 95%)
2.14 dB (k=2)
4.24 dB (k=2)
4.35 dB (k=2)
4.44 dB (k=2)
4.56 dB (k=2)
5.5 Laboratory Facility
The test facility is recognized, certified, or accredited by the following organizations:
● FCC - Registration No.: 817957
Shenzhen Zhongjian Nanfang Testing Co., Ltd. EMC Laboratory has been registered and fully
described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter
from the FCC is maintained in out files. Registration 817957, February 27, 2012.
● IC - Registration No.: 10106A-1
The 3m Semi-anechoic chamber of Shenzhen Zhongjian Nanfang Testing Co., Ltd. has been
Registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing
with Registration No.: 10106A-1.
● CNAS - Registration No.: CNAS L6048
Shenzhen Zhongjian Nanfang Testing Co., Ltd. is accredited to ISO/IEC 17025:2005 General
Requirements for the Competence of Testing and Calibration laboratories for the competence of
testing. The Registration No. is CNAS L6048.
5.6 Laboratory Location
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
Address: No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Tel: +86-755-23118282
Fax: +86-755-23116366
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 7 of 63
Report No: CCISE160600402
5.7 Test Instruments list
Radiated Emission:
Item
Test Equipment
Manufacturer
3m SAC
SAEMC
BiConiLog Antenna
Horn Antenna
Pre-amplifier
(10kHz-1.3GHz)
Cal. Due date
(mm-dd-yy)
(mm-dd-yy)
08-23-2014
08-22-2017
SCHWARZBECK
VULB9163
CCIS0005
03-25-2016
03-25-2017
SCHWARZBECK
BBHA9120D
CCIS0006
03-25-2016
03-25-2017
HP
8447D
CCIS0003
04-01-2016
03-31-2017
PAP-1G18
CCIS0011
04-01-2016
03-31-2017
GTS218
04-01-2016
03-31-2017
Compliance Direction
Systems Inc.
Rohde & Schwarz
AFS33-18002
650-30-8P-44
ETS-LINDGREN
3160
GTS217
04-01-2016
03-31-2017
Rohde & Schwarz
FSP30
CCIS0023
03-28-2016
03-28-2017
EMI Test Receiver
Rohde & Schwarz
ESRP7
CCIS0167
03-28-2016
03-28-2017
10
Loop antenna
Laplace instrument
RF300
EMC0701
04-01-2016
03-31-2017
11
EMI Test Software
AUDIX
E3
N/A
N/A
N/A
Horn Antenna
Cal. Date
No.
CCIS0001
Pre-amplifier
(18-26GHz)
Inventory
9(L)*6(W)* 6(H)
(1GHz-18GHz)
Pre-amplifier
Model No.
Spectrum analyzer
9k-30GHz
Conducted Emission:
Item
Test Equipment
Manufacturer
Inventory
No.
Cal. Date
(mm-dd-yy)
11.0(L)x4.0(W)x3.0(H)
CCIS0061
08-23-2014
08-22-2017
Model No.
Cal. Due date
(mm-dd-yy)
Shielding Room
ZhongShuo Electron
EMI Test Receiver
Rohde & Schwarz
ESCI
CCIS0002
03-24-2016
03-24-2017
LISN
CHASE
MN2050D
CCIS0074
03-26-2016
03-26-2017
Coaxial Cable
CCIS
N/A
CCIS0086
04-01-2016
03-31-2017
EMI Test Software
AUDIX
E3
N/A
N/A
N/A
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 8 of 63
Report No: CCISE160600402
Test results and Measurement Data
6.1 Antenna requirement
Standard requirement:
FCC Part 15 C Section 15.203 /247(c)
15.203 requirement:
An intentional radiator shall be designed to ensure that no antenna other than that furnished by the
responsible party shall be used with the device. The use of a permanently attached antenna or of an
antenna that uses a unique coupling to the intentional radiator, the manufacturer may design the unit
so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or
electrical connector is prohibited.
15.247(c) (1)(i) requirement:
(i) Systems operating in the 2400-2483.5 MHz band that is used exclusively for fixed. Point-to-point
operations may employ transmitting antennas with directional gain greater than 6dBi provided the
maximum conducted output power of the intentional radiator is reduced by 1 dB for every 3 dB that the
directional gain of the antenna exceeds 6dBi.
E.U.T Antenna:
The Bluetooth antenna is an integral antenna which permanently attached, and the best case gain of
the antenna is -3.83 dBi.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 9 of 63
Report No: CCISE160600402
6.2 Conducted Emissions
Test Requirement:
FCC Part 15 C Section 15.207
Test Method:
ANSI C63.4:2014
Test Frequency Range:
150 kHz to 30 MHz
Class / Severity:
Class B
Receiver setup:
RBW=9 kHz, VBW=30 kHz, Sweep time=auto
Frequency range
Limit (dBuV)
(MHz)
Quasi-peak
Average
0.15-0.5
66 to 56*
56 to 46*
0.5-5
56
46
5-30
60
50
* Decreases with the logarithm of the frequency.
Limit:
Class B
Test setup:
Test procedure:
1. The E.U.T and simulators are connected to the main power through a
line impedance stabilization network (L.I.S.N.). This provides a
50ohm/50uH coupling impedance for the measuring equipment.
2. The peripheral devices are also connected to the main power through a
LISN that provides a 50ohm/50uH coupling impedance with 50ohm
termination. (Please refer to the block diagram of the test setup and
photographs).
3. Both sides of A.C. line are checked for maximum conducted
interference. In order to find the maximum emission, the relative
positions of equipment and all of the interface cables must be changed
according to ANSI C63.4: 2014 on conducted measurement.
Test Instruments:
Refer to section 5.7 for details
Test mode:
Bluetooth (Continuous transmitting) mode
Test results:
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 10 of 63
Report No: CCISE160600402
Measurement Data:
Line:
Notes:
1. An initial pre-scan was performed on the line and neutral lines with peak detector.
2. Quasi-Peak and Average measurement were performed at the frequencies with maximized peak emission.
3. Final Level =Receiver Read level + LISN Factor + Cable Loss.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 11 of 63
Report No: CCISE160600402
Neutral:
Notes:
1. An initial pre-scan was performed on the line and neutral lines with peak detector.
2. Quasi-Peak and Average measurement were performed at the frequencies with maximized peak emission.
3. Final Level =Receiver Read level + LISN Factor + Cable Loss.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 12 of 63
Report No: CCISE160600402
6.3 Conducted Output Power
Test Requirement:
FCC Part 15 C Section 15.247 (b)(1)
Test Method:
ANSI C63.10:2013 and DA00-705
RBW=1MHz, VBW=3MHz, Detector=Peak (If 20dB BW ≤1 MHz)
RBW=3MHz, VBW=10MHz, Detector=Peak (If 20dB BW > 1 MHz and <
3MHz)
125 mW(21 dBm)
Receiver setup:
Limit:
Test setup:
Test Instruments:
Refer to section 5.7 for details
Test mode:
Non-hopping mode
Test results:
Pass
Measurement Data:
Test channel
Lowest
Middle
Highest
Test channel
Lowest
Middle
Highest
Test channel
Lowest
Middle
Highest
GFSK mode
Peak Output Power (dBm)
Limit (dBm)
2.67
21.00
3.00
21.00
3.33
21.00
π/4-DQPSK mode
Peak Output Power (dBm)
Limit (dBm)
1.26
21.00
1.87
21.00
2.05
21.00
8DPSK mode
Peak Output Power (dBm)
Limit (dBm)
1.23
21.00
1.87
21.00
2.15
21.00
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Result
Pass
Pass
Pass
Result
Pass
Pass
Pass
Result
Pass
Pass
Pass
Project No.: CCISE1606004
Page 13 of 63
Report No: CCISE160600402
Test plot as follows:
Modulation mode: GFSK
Ref
20
20 dBm
Offset
* Att
* RBW
1 MHz
* VBW
3 MHz
30 dB
Marker 1 [T1 ]
2.67 dBm
SWT 2.5 ms
2.401820000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.402 GHz
Date: 2.JUN.2016
500 kHz/
Span 5 MHz
11:35:33
Lowest channel
Ref
20
20 dBm
Offset
* Att
* RBW
1 MHz
* VBW
3 MHz
30 dB
Marker 1 [T1 ]
3.00 dBm
SWT 2.5 ms
2.441080000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
500 kHz/
Span 5 MHz
11:36:15
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
SWT 2.5 ms
3.33 dBm
2.480010000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.48 GHz
Date: 2.JUN.2016
500 kHz/
Span 5 MHz
11:36:46
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 14 of 63
Report No: CCISE160600402
Modulation mode: π/4-DQPSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
3 MHz
* VBW
10 MHz
1.26 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.401900000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.402 GHz
Date: 2.JUN.2016
1 MHz/
Span 10 MHz
11:38:03
Lowest channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
3 MHz
* VBW
10 MHz
1.87 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.440740000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
1 MHz/
Span 10 MHz
11:38:49
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
3 MHz
* VBW
10 MHz
2.05 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.479760000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.48 GHz
Date: 2.JUN.2016
1 MHz/
Span 10 MHz
11:39:37
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 15 of 63
Report No: CCISE160600402
Modulation mode: 8DPSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
3 MHz
* VBW
10 MHz
1.23 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.401820000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.402 GHz
Date: 2.JUN.2016
1 MHz/
Span 10 MHz
11:41:06
Lowest channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
3 MHz
* VBW
10 MHz
1.87 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.441000000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
1 MHz/
Span 10 MHz
11:40:34
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
3 MHz
* VBW
10 MHz
2.15 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.479920000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.48 GHz
Date: 2.JUN.2016
1 MHz/
Span 10 MHz
11:40:07
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 16 of 63
Report No: CCISE160600402
6.4 20dB Occupy Bandwidth
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1)
Test Method:
ANSI C63.10:2013 and DA00-705
Receiver setup:
RBW=30 kHz, VBW=100 kHz, detector=Peak
Limit:
NA
Test setup:
Test Instruments:
Refer to section 5.7 for details
Test mode:
Non-hopping mode
Test results:
Pass
Measurement Data:
Test channel
20dB Occupy Bandwidth (kHz)
GFSK
π/4-DQPSK
8DPSK
Lowest
852
1124
1172
Middle
844
1120
1172
Highest
760
1120
1172
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 17 of 63
Report No: CCISE160600402
Test plot as follows:
Modulation mode: GFSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
0.07 dB
SWT 2.5 ms
852.000000000 kHz
6.5 dB
Marker 1 [T1 ]
-18.32 dBm
2.401548000 GHz
10
1 PK
MAXH
D1 2.45 dBm
LVL
-10
D2 -17.55 dBm
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.402 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:03:10
Lowest channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-0.37 dB
SWT 2.5 ms
844.000000000 kHz
6.5 dB
Marker 1 [T1 ]
-17.88 dBm
2.440556000 GHz
10
1 PK
MAXH
D1 2.97 dBm
LVL
-10
D2 -17.03 dBm
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:06:32
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-0.06 dB
SWT 2.5 ms
760.000000000 kHz
6.5 dB
Marker 1 [T1 ]
-17.28 dBm
2.479636000 GHz
10
1 PK
MAXH
D1 3.37 dBm
LVL
-10
D2 -16.63 dBm
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.48 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:10:28
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 18 of 63
Report No: CCISE160600402
Modulation mode: π/4-DQPSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
0.08 dB
SWT 2.5 ms
6.5 dB
1.124000000 MHz
Marker 1 [T1 ]
-21.76 dBm
2.401424000 GHz
10
1 PK
MAXH
D1 -0.96 dBm
LVL
-10
D2 -20.96 dBm
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.402 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:15:14
Lowest channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-0.41 dB
SWT 2.5 ms
6.5 dB
1.120000000 MHz
Marker 1 [T1 ]
-20.85 dBm
2.440428000 GHz
10
1 PK
MAXH
D1 -0.3 dBm
LVL
-10
D2 -20.3 dBm
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:13:48
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-0.39 dB
SWT 2.5 ms
6.5 dB
1.120000000 MHz
Marker 1 [T1 ]
-20.02 dBm
2.479428000 GHz
10
1 PK
MAXH
D1 0.15 dBm
LVL
-10
-20
D2 -19.85 dBm
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.48 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:12:36
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 19 of 63
Report No: CCISE160600402
Modulation mode: 8DPSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-1.31 dB
SWT 2.5 ms
6.5 dB
1.172000000 MHz
Marker 1 [T1 ]
-21.56 dBm
2.401412000 GHz
10
1 PK
MAXH
D1 -0.96 dBm
LVL
-10
D2 -20.96 dBm
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.402 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:16:42
Lowest channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
1.25 dB
SWT 2.5 ms
6.5 dB
1.172000000 MHz
Marker 1 [T1 ]
-21.97 dBm
2.440408000 GHz
10
1 PK
MAXH
D1 -0.32 dBm
LVL
-10
D2 -20.32 dBm
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:18:06
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-0.40 dB
SWT 2.5 ms
6.5 dB
1.172000000 MHz
Marker 1 [T1 ]
-20.30 dBm
2.479412000 GHz
10
1 PK
MAXH
D1 0.03 dBm
LVL
-10
-20
D2 -19.97 dBm
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.48 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:19:10
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 20 of 63
Report No: CCISE160600402
6.5 Carrier Frequencies Separation
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1)
Test Method:
ANSI C63.10:2013 and DA00-705
Receiver setup:
RBW=100 kHz, VBW=300 kHz, detector=Peak
Limit:
0.025MHz or 2/3 of the 20dB bandwidth (whichever is greater)
Test setup:
Test Instruments:
Refer to section 5.7 for details
Test mode:
Hopping mode
Test results:
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 21 of 63
Report No: CCISE160600402
Measurement Data:
GFSK mode
Test channel
Carrier Frequencies Separation
(kHz)
Limit (kHz)
Result
Lowest
1004
568.00
Pass
Middle
1004
568.00
Pass
Highest
1004
568.00
Pass
π/4-DQPSK mode
Test channel
Carrier Frequencies Separation
(kHz)
Limit (kHz)
Result
Lowest
1004
749.33
Pass
Middle
1008
749.33
Pass
Highest
1008
749.33
Pass
8DPSK mode
Test channel
Carrier Frequencies Separation
(kHz)
Limit (kHz)
Result
Lowest
1004
781.33
Pass
Middle
1008
781.33
Pass
Highest
1004
781.33
Pass
Note: According to section 6.4
Mode
GFSK
π/4-DQPSK
8DPSK
20dB bandwidth (kHz)
(worse case)
852
1124
1172
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Limit (kHz)
(Carrier Frequencies Separation)
568.00
749.33
781.33
Project No.: CCISE1606004
Page 22 of 63
Report No: CCISE160600402
Test plot as follows:
Modulation mode: GFSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
-0.03 dB
SWT 2.5 ms
6.5 dB
1.004000000 MHz
Marker 1 [T1 ]
2.26 dBm
2.401836000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4025 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:22:28
Lowest channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.06 dB
SWT 2.5 ms
6.5 dB
1.004000000 MHz
Marker 1 [T1 ]
2.85 dBm
2.440836000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4415 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:29:00
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.03 dB
SWT 2.5 ms
6.5 dB
1.004000000 MHz
Marker 1 [T1 ]
3.22 dBm
2.478836000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4795 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:30:06
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 23 of 63
Report No: CCISE160600402
Modulation mode: π/4-DQPSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.04 dB
SWT 2.5 ms
6.5 dB
1.004000000 MHz
Marker 1 [T1 ]
0.44 dBm
2.401836000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4025 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:23:44
Lowest channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.06 dB
SWT 2.5 ms
6.5 dB
1.008000000 MHz
Marker 1 [T1 ]
1.05 dBm
2.440832000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4415 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:27:21
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
-0.02 dB
SWT 2.5 ms
6.5 dB
1.008000000 MHz
Marker 1 [T1 ]
1.50 dBm
2.478828000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4795 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:31:24
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 24 of 63
Report No: CCISE160600402
Modulation mode: 8DPSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.02 dB
SWT 2.5 ms
6.5 dB
1.004000000 MHz
Marker 1 [T1 ]
0.45 dBm
2.401840000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4025 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:24:48
Lowest channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.01 dB
SWT 2.5 ms
6.5 dB
1.008000000 MHz
Marker 1 [T1 ]
1.11 dBm
2.440836000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4415 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:26:10
Middle channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.02 dB
SWT 2.5 ms
6.5 dB
1.004000000 MHz
Marker 1 [T1 ]
1.46 dBm
2.478840000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.4795 GHz
Date: 2.JUN.2016
200 kHz/
Span 2 MHz
14:32:30
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 25 of 63
Report No: CCISE160600402
6.6 Hopping Channel Number
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1)
Test Method:
ANSI C63.10:2013 and DA00-705
RBW=100 kHz, VBW=300 kHz, Frequency range=2400MHz-2483.5MHz,
Detector=Peak
15 channels
Receiver setup:
Limit:
Test setup:
Test Instruments:
Refer to section 5.7 for details
Test mode:
Hopping mode
Test results:
Pass
Measurement Data:
Mode
GFSK, π/4-DQPSK, 8DPSK
Hopping channel numbers
Limit
Result
79
15
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 26 of 63
Report No: CCISE160600402
Test plot as follows:
GFSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.99 dB
SWT 10 ms
6.5 dB
78.200000000 MHz
Marker 1 [T1 ]
2.21 dBm
2.401800000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
10 MHz/
Span 100 MHz
14:35:08
π/4-DQPSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
2.02 dB
SWT 10 ms
6.5 dB
78.000000000 MHz
Marker 1 [T1 ]
-0.95 dBm
2.402000000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
10 MHz/
Span 100 MHz
14:36:47
8DPSK
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
1.17 dB
SWT 10 ms
6.5 dB
78.000000000 MHz
Marker 1 [T1 ]
0.55 dBm
2.402000000 GHz
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
10 MHz/
Span 100 MHz
14:38:48
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 27 of 63
Report No: CCISE160600402
6.7 Dwell Time
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1)
Test Method:
ANSI C63.10:2013 and KDB DA00-705
Receiver setup:
RBW=1 MHz, VBW=1 MHz, Span=0 Hz, Detector=Peak
Limit:
0.4 Second
Test setup:
Test Instruments:
Refer to section 5.7 for details
Test mode:
Hopping mode
Test results:
Pass
Measurement Data (Worse case):
Mode
GFSK
π/4-DQPSK
8DPSK
Packet
Dwell time (second)
DH1
0.12416
DH3
0.26592
DH5
0.31125
2-DH1
0.12608
2-DH3
0.26592
2-DH5
0.31211
3-DH1
0.12864
3-DH3
0.26592
3-DH5
0.31125
Limit (second)
Result
0.4
Pass
0.4
Pass
0.4
Pass
For GFSK, π/4-DQPSK and 8DPSK:
The test period: T= 0.4 Second/Channel x 79 Channel = 31.6 s
DH1 time slot=0.388*(1600/ (2*79))*31.6=124.16ms
DH3 time slot=1.662*(1600/ (4*79))*31.6=265.92ms
DH5 time slot=2.918*(1600/ (6*79))*31.6=311.25ms
2-DH1 time slot=0.394*(1600/ (2*79))*31.6=126.08ms
2-DH3 time slot=1.662*(1600/ (4*79))*31.6=265.92ms
2-DH5 time slot=2.926*(1600/ (6*79))*31.6=312.11ms
3-DH1 time slot=0.402*(1600/ (2*79))*31.6=128.64ms
3-DH3 time slot=1.662*(1600/ (4*79))*31.6=265.92ms
3-DH5 time slot=2.918*(1600/ (6*79))*31.6=311.25ms
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 28 of 63
Report No: CCISE160600402
Test plot as follows:
Modulation mode: GFSK
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
-1.09 dB
SWT 1 ms
6.5 dB
388.000000 µs
Marker 1 [T1 ]
-55.05 dBm
244.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
100 µs/
13:41:31
DH1
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
0.03 dB
SWT 3 ms
6.5 dB
1.662000 ms
Marker 1 [T1 ]
-50.65 dBm
846.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
300 µs/
13:46:02
DH3
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
-0.12 dB
SWT 4 ms
6.5 dB
2.918000 ms
Marker 1 [T1 ]
-51.28 dBm
622.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
400 µs/
13:46:59
DH5
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 29 of 63
Report No: CCISE160600402
Modulation mode: π/4-DQPSK
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
1.16 dB
SWT 1 ms
6.5 dB
394.000000 µs
Marker 1 [T1 ]
-56.29 dBm
326.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
100 µs/
13:42:32
2-DH1
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
-1.57 dB
SWT 3 ms
6.5 dB
1.662000 ms
Marker 1 [T1 ]
-49.80 dBm
522.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
300 µs/
13:45:21
2-DH3
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
1.99 dB
SWT 4 ms
6.5 dB
2.926000 ms
Marker 1 [T1 ]
-50.54 dBm
590.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
400 µs/
13:47:30
2-DH5
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 30 of 63
Report No: CCISE160600402
Modulation mode: 8DPSK
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
-2.50 dB
SWT 1 ms
6.5 dB
402.000000 µs
Marker 1 [T1 ]
-51.94 dBm
174.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
100 µs/
13:43:18
3-DH1
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
2.17 dB
SWT 3 ms
6.5 dB
1.662000 ms
Marker 1 [T1 ]
-53.27 dBm
858.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
300 µs/
13:44:36
3-DH3
RBW 1 MHz
* VBW
Ref
20
20 dBm
Offset
* Att
30 dB
Delta 1 [T1 ]
3 MHz
3.90 dB
SWT 4 ms
6.5 dB
2.918000 ms
Marker 1 [T1 ]
-51.85 dBm
718.000000 µs
10
SGL
1 PK *
CLRWR
LVL
-10
-20
-30
3DB
AC
-40
-50
-60
-70
-80
Center 2.441 GHz
Date: 2.JUN.2016
400 µs/
13:48:13
3-DH5
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 31 of 63
Report No: CCISE160600402
6.8 Pseudorandom Frequency Hopping Sequence
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1) requirement:
Frequency hopping systems shall have hopping channel carrier frequencies separated by a minimum of
25 kHz or the 20 dB bandwidth of the hopping channel, whichever is greater.
Alternatively. Frequency hopping systems operating in the 2400-2483.5 MHz band may have hopping
channel carrier frequencies that are separated by 25 kHz or two-thirds of the 20 dB bandwidth of the
hopping channel, whichever is greater, provided the systems operate with an output power no greater
than 125 mW. The system shall hop to channel frequencies that are selected at the system hopping rate
from a Pseudorandom ordered list of hopping frequencies. Each frequency must be used equally on the
average by each transmitter. The system receivers shall have input bandwidths that match the hopping
channel bandwidths of their corresponding transmitters and shall shift frequencies in synchronization
with the transmitted signals.
EUT Pseudorandom Frequency Hopping Sequence
The pseudorandom sequence may be generated in a nine-stage shift register whose 5th and 9th stage
outputs are added in a modulo-two addition stage. And the result is fed back to the input of the first
stage. The sequence begins with the first ONE of 9 consecutive ONEs; i.e. the shift register is initialized
with nine ones.
• Number of shift register stages: 9
• Length of pseudo-random sequence: 2 -1 = 511 bits
• Longest sequence of zeros: 8 (non-inverted signal)
An example of Pseudorandom Frequency Hopping Sequence as follow:
Each frequency used equally on the average by each transmitter.
The system receivers have input bandwidths that match the hopping channel bandwidths of their
corresponding transmitters and shift frequencies in synchronization with the transmitted signals.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 32 of 63
Report No: CCISE160600402
6.9 Band Edge
6.9.1 Conducted Emission Method
Test Requirement:
FCC Part 15 C Section 15.247 (d)
Test Method:
ANSI C63.10:2013 and DA00-705
Receiver setup:
RBW=100 kHz, VBW=300 kHz, Detector=Peak
Limit:
In any 100 kHz bandwidth outside the frequency band in which the spread
spectrum intentional radiator is operating, the radio frequency power that
is produced by the intentional radiator shall be at least 20 dB below that in
the 100 kHz bandwidth within the band that contains the highest level of
the desired power, based on either an RF conducted or a radiated
measurement.
Test setup:
Test Instruments:
Refer to section 5.7 for details
Test mode:
Non-hopping mode and hopping mode
Test results:
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 33 of 63
Report No: CCISE160600402
Test plot as follows:
GFSK
Lowest Channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-36.40 dBm
SWT 2.5 ms
2.399802000 GHz
6.5 dB
20
10
1 PK
MAXH
Ref
20 dBm
Offset
MAXH
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-39.26 dBm
SWT 2.5 ms
2.399698000 GHz
6.5 dB
10
1 PK
D1 2.07 dBm
* Att
LVL
-10
D1 2.01 dBm
LVL
-10
D2 -17.93 dBm
D2 -17.99 dBm
-20
-20
-30
-30
3DB
AC
-40
3DB
AC
-40
-50
-50
-60
-60
-70
-70
F1
F1
-80
-80
Start 2.39 GHz
Date: 2.JUN.2016
1.3 MHz/
Stop 2.403 GHz
Start 2.39 GHz
11:45:57
Date: 2.JUN.2016
1.3 MHz/
Stop 2.403 GHz
11:47:30
No-hopping mode
Hopping mode
Highest Channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-41.28 dBm
2.484072000 GHz
6.5 dB
20
10
1 PK
MAXH
Ref
20 dBm
Offset
MAXH
LVL
-10
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 ms
Marker 1 [T1 ]
-45.52 dBm
2.485040000 GHz
6.5 dB
10
1 PK
D1 2.86 dBm
* Att
D1 2.86 dBm
LVL
-10
D2 -17.14 dBm
D2 -17.14 dBm
-20
-20
-30
-30
3DB
-40
AC
3DB
AC
-40
-50
-50
-60
-60
-70
-70
F1
F1
-80
-80
Start 2.478 GHz
Date: 2.JUN.2016
2.2 MHz/
12:03:34
Stop 2.5 GHz
Start 2.478 GHz
Date: 2.JUN.2016
No-hopping mode
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
2.2 MHz/
Stop 2.5 GHz
12:02:22
Hopping mode
Project No.: CCISE1606004
Page 34 of 63
Report No: CCISE160600402
π/4-DQPSK
Lowest Channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-36.76 dBm
SWT 2.5 ms
2.399672000 GHz
Ref
6.5 dB
20
10
1 PK
MAXH
MAXH
D1 0.11 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-37.63 dBm
SWT 2.5 ms
2.399698000 GHz
6.5 dB
10
1 PK
20 dBm
LVL
-10
D1 0.36 dBm
LVL
-10
D2 -19.89 dBm
-20
D2 -19.64 dBm
-20
-30
-30
3DB
AC
-40
3DB
AC
-40
-50
-50
-60
-60
-70
-70
F1
F1
-80
-80
Start 2.39 GHz
Date: 2.JUN.2016
1.3 MHz/
Stop 2.403 GHz
Start 2.39 GHz
11:51:11
Date: 2.JUN.2016
1.3 MHz/
Stop 2.403 GHz
11:49:10
No-hopping mode
Hopping mode
Highest Channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-41.59 dBm
2.483500000 GHz
Ref
6.5 dB
20
10
1 PK
MAXH
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 ms
Marker 1 [T1 ]
-43.87 dBm
2.484776000 GHz
6.5 dB
10
1 PK
D1 1.21 dBm
MAXH
LVL
-10
-20
D1 -0.28 dBm
LVL
-10
D2 -18.79 dBm
-20
-30
-40
D2 -20.28 dBm
-30
3DB
AC
3DB
-40
-50
-50
-60
-60
-70
-70
F1
F1
-80
-80
Start 2.478 GHz
Date: 2.JUN.2016
AC
2.2 MHz/
12:08:58
Stop 2.5 GHz
Start 2.478 GHz
Date: 2.JUN.2016
No-hopping mode
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
2.2 MHz/
Stop 2.5 GHz
12:01:24
Hopping mode
Project No.: CCISE1606004
Page 35 of 63
Report No: CCISE160600402
8DPSK
Lowest Channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-36.67 dBm
SWT 2.5 ms
2.399698000 GHz
Ref
6.5 dB
20
10
1 PK
MAXH
MAXH
D1 0.21 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-39.38 dBm
SWT 2.5 ms
2.399854000 GHz
6.5 dB
10
1 PK
20 dBm
LVL
-10
D1 0.19 dBm
LVL
-10
D2 -19.79 dBm
-20
D2 -19.81 dBm
-20
-30
-30
3DB
AC
-40
3DB
AC
-40
-50
-50
-60
-60
-70
-70
F1
F1
-80
-80
Start 2.39 GHz
Date: 2.JUN.2016
1.3 MHz/
Stop 2.403 GHz
Start 2.39 GHz
11:52:30
Date: 2.JUN.2016
1.3 MHz/
Stop 2.403 GHz
11:54:34
No-hopping mode
Hopping mode
Highest Channel
Ref
20
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-42.04 dBm
2.483588000 GHz
Ref
6.5 dB
20
10
1 PK
MAXH
20 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 ms
Marker 1 [T1 ]
-45.83 dBm
2.485392000 GHz
6.5 dB
10
1 PK
D1 1.2 dBm
MAXH
LVL
-10
-20
D1 1.13 dBm
LVL
-10
D2 -18.8 dBm
-20
-30
D2 -18.87 dBm
-30
3DB
-40
AC
3DB
AC
-40
-50
-50
-60
-60
-70
-70
F1
F1
-80
-80
Start 2.478 GHz
Date: 2.JUN.2016
2.2 MHz/
11:58:45
Stop 2.5 GHz
Start 2.478 GHz
Date: 2.JUN.2016
No-hopping mode
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
2.2 MHz/
Stop 2.5 GHz
11:56:51
Hopping mode
Project No.: CCISE1606004
Page 36 of 63
Report No: CCISE160600402
6.9.2 Radiated Emission Method
Test Requirement:
FCC Part 15 C Section 15.209 and 15.205
Test Method:
ANSI C63.10: 2013
Test Frequency Range:
2.3GHz to 2.5GHz
Test site:
Measurement Distance: 3m
Frequency
Detector
RBW
VBW
Remark
Peak
1MHz
3MHz
Peak Value
Above 1GHz
RMS
1MHz
3MHz
Average Value
Frequency
Limit (dBuV/m @3m)
Remark
54.00
Average Value
Above 1GHz
74.00
Peak Value
Receiver setup:
Limit:
Test setup:
Test Procedure:
1. The EUT was placed on the top of a rotating table 1.5meters above the
ground at a 3 meter camber. The table was rotated 360 degrees to
determine the position of the highest radiation.
2. The EUT was set 3 meters away from the interference-receiving
antenna, which was mounted on the top of a variable-height antenna
tower.
3. The antenna height is varied from one meter to four meters above the
ground to determine the maximum value of the field strength. Both
horizontal and vertical polarizations of the antenna are set to make the
measurement.
4. For each suspected emission, the EUT was arranged to its worst case
and then the antenna was tuned to heights from 1 meter to 4 meters
and the rota table was turned from 0 degrees to 360 degrees to find the
maximum reading.
5. The test-receiver system was set to Peak Detect Function and
Specified Bandwidth with Maximum Hold Mode.
6. If the emission level of the EUT in peak mode was 10dB lower than the
limit specified, then testing could be stopped and the peak values of the
EUT would be reported. Otherwise the emissions that did not have
10dB margin would be re-tested one by one using peak, quasi-peak or
average method as specified and then reported in a data sheet.
Test Instruments:
Refer to section 5.7 for details
Test mode:
Non-hopping mode
Test results:
Passed
Remark:
1. During the test, pre-scan the GFSK, π/4-DQPSK, 8DPSK, and all data were shown in report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 37 of 63
Report No: CCISE160600402
2. Pre-scan all kind of the place mode (X-axis, Y-axis, Z-axis), and found the Y-axis is the worst case.
GFSK mode
Test channel: Lowest
Horizontal:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 38 of 63
Report No: CCISE160600402
Vertical:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 39 of 63
Report No: CCISE160600402
Test channel: Highest
Horizontal:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 40 of 63
Report No: CCISE160600402
Vertical:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 41 of 63
Report No: CCISE160600402
π/4-DQPSK mode
Test channel: Lowest
Horizontal:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 42 of 63
Report No: CCISE160600402
Vertical:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 43 of 63
Report No: CCISE160600402
Test channel: Highest
Horizontal:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 44 of 63
Report No: CCISE160600402
Vertical:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 45 of 63
Report No: CCISE160600402
8DPSK mode
Test channel: Lowest
Horizontal:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 46 of 63
Report No: CCISE160600402
Vertical:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 47 of 63
Report No: CCISE160600402
Test channel: Highest
Horizontal:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 48 of 63
Report No: CCISE160600402
Vertical:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 49 of 63
Report No: CCISE160600402
6.10
6.10.1
Spurious Emission
Conducted Emission Method
Test Requirement:
FCC Part 15 C Section 15.247 (d)
Test Method:
ANSI C63.10:2013 and DA00-705
Limit:
In any 100 kHz bandwidth outside the frequency band in which the spread
spectrum intentional radiator is operating, the radio frequency power that
is produced by the intentional radiator shall be at least 20 dB below that in
the 100 kHz bandwidth within the band that contains the highest level of
the desired power, based on either an RF conducted or a radiated
measurement.
Test setup:
Test Instruments:
Refer to section 5.7 for details
Test mode:
Non-hopping mode
Test results:
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 50 of 63
Report No: CCISE160600402
Test plot as follows:
GFSK
Lowest channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-29.43 dBm
4.874180000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 3.85 dBm
-10
D2 -16.15 dBm
-20
3DB
-30
-40
-50
-60
-70
Start 30 MHz
Date: 2.JUN.2016
2.497 GHz/
Stop 25 GHz
14:42:21
30MHz~25GHz
Middle channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-34.04 dBm
13.613680000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 0.79 dBm
-10
-20
D2 -19.21 dBm
-30
3DB
-40
-50
-60
-70
Start 30 MHz
Date: 2.JUN.2016
2.497 GHz/
Stop 25 GHz
14:43:37
30MHz~25GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 51 of 63
Report No: CCISE160600402
Highest channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-28.77 dBm
4.824240000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 3.35 dBm
-10
D2 -16.65 dBm
-20
3DB
-30
-40
-50
-60
-70
Start 30 MHz
Date: 2.JUN.2016
2.497 GHz/
Stop 25 GHz
14:44:33
30MHz~25GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 52 of 63
Report No: CCISE160600402
π/4-DQPSK
Lowest channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-34.15 dBm
14.962060000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 0.48 dBm
-10
D2 -19.52 dBm
-20
-30
3DB
-40
-50
-60
-70
Start 30 MHz
2.497 GHz/
Date: 2.JUN.2016
Stop 25 GHz
14:47:57
30MHz~25GHz
Middle channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-30.91 dBm
4.824240000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 0.39 dBm
-10
-20
D2 -19.61 dBm
3DB
-30
-40
-50
-60
-70
Start 30 MHz
Date: 2.JUN.2016
2.497 GHz/
Stop 25 GHz
14:47:04
30MHz~25GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 53 of 63
Report No: CCISE160600402
Highest channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-34.31 dBm
4.874180000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 0.63 dBm
-10
-20
D2 -19.37 dBm
-30
3DB
-40
-50
-60
-70
Start 30 MHz
Date: 2.JUN.2016
2.497 GHz/
Stop 25 GHz
14:45:43
30MHz~25GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 54 of 63
Report No: CCISE160600402
8DPSK
Lowest channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-33.89 dBm
13.613680000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 0.34 dBm
-10
D2 -19.66 dBm
-20
-30
3DB
-40
-50
-60
-70
Start 30 MHz
Date: 2.JUN.2016
2.497 GHz/
Stop 25 GHz
14:49:08
30MHz~25GHz
Middle channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-34.84 dBm
15.012000000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 1.33 dBm
-10
-20
D2 -18.67 dBm
-30
3DB
-40
-50
-60
-70
Start 30 MHz
Date: 2.JUN.2016
2.497 GHz/
Stop 25 GHz
14:50:13
30MHz~25GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 55 of 63
Report No: CCISE160600402
Highest channel
Ref
26.5 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-34.47 dBm
13.713560000 GHz
6.5 dB
20
1 PK
10
MAXH
LVL
D1 0.34 dBm
-10
-20
D2 -19.66 dBm
-30
3DB
-40
-50
-60
-70
Start 30 MHz
Date: 2.JUN.2016
2.497 GHz/
Stop 25 GHz
14:51:36
30MHz~25GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 56 of 63
Report No: CCISE160600402
6.10.2
Radiated Emission Method
Test Requirement:
FCC Part 15 C Section 15.209
Test Method:
ANSI C63.10: 2013
Test Frequency Range:
9 kHz to 25 GHz
Test site:
Measurement Distance: 3m
Receiver setup:
Frequency
Detector
RBW
VBW
Remark
30MHz-1GHz
Quasi-peak
120kHz
300kHz
Quasi-peak Value
Peak
1MHz
3MHz
Peak Value
RMS
1MHz
3MHz
Average Value
Above 1GHz
Limit:
Frequency
Limit (dBuV/m @3m)
Remark
30MHz-88MHz
40.0
Quasi-peak Value
88MHz-216MHz
43.5
Quasi-peak Value
216MHz-960MHz
46.0
Quasi-peak Value
960MHz-1GHz
54.0
Quasi-peak Value
54.0
Average Value
74.0
Peak Value
Above 1GHz
Test setup:
Below 1GHz
Above 1GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 57 of 63
Report No: CCISE160600402
Test Procedure:
1. The EUT was placed on the top of a rotating table 0.8m(below 1GHz)
/1.5m(above 1GHz) above the ground at a 3 meter chamber. The table
was rotated 360 degrees to determine the position of the highest
radiation.
2. The EUT was set 3 meters away from the interference-receiving
antenna, which was mounted on the top of a variable-height antenna
tower.
3. The antenna height is varied from one meter to four meters above the
ground to determine the maximum value of the field strength. Both
horizontal and vertical polarizations of the antenna are set to make the
measurement.
4. For each suspected emission, the EUT was arranged to its worst case
and then the antenna was tuned to heights from 1 meter to 4 meters
and the rota table was turned from 0 degrees to 360 degrees to find the
maximum reading.
5. The test-receiver system was set to Peak Detect Function and
Specified Bandwidth with Maximum Hold Mode.
6. If the emission level of the EUT in peak mode was 10dB lower than the
limit specified, then testing could be stopped and the peak values of the
EUT would be reported. Otherwise the emissions that did not have
10dB margin would be re-tested one by one using peak, quasi-peak or
average method as specified and then reported in a data sheet.
Test Instruments:
Refer to section 5.7 for details
Test mode:
Non-hopping mode
Test results:
Pass
Remark:
1. During the test, pre-scan the GFSK, π/4-DQPSK, 8DPSK modulation, and found the GFSK modulation is
the worst case.
2. Pre-scan all kind of the place mode (X-axis, Y-axis, Z-axis), and found the Y-axis is the worst case.
3. 9 kHz to 30 MHz is noise floor, so only shows the data of above 30MHz in this report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 58 of 63
Report No: CCISE160600402
Measurement data:
Below 1GHz
Vertical:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 59 of 63
Report No: CCISE160600402
Horizontal:
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 60 of 63
Report No: CCISE160600402
Above 1GHz:
Test channel:
Read
Frequency
Level
(MHz)
(dBuV)
4804.00
55.14
4804.00
46.86
Test channel:
Read
Frequency
Level
(MHz)
(dBuV)
4804.00
35.20
4804.00
34.85
Test channel:
Read
Frequency
Level
(MHz)
(dBuV)
4882.00
57.21
4882.00
47.64
Test channel:
Read
Frequency
Level
(MHz)
(dBuV)
4882.00
36.50
4882.00
35.35
Test channel:
Read
Frequency
Level
(MHz)
(dBuV)
4960.00
59.13
4960.00
49.26
Test channel:
Read
Frequency
Level
(MHz)
(dBuV)
4960.00
37.29
4960.00
36.51
Antenna
Factor
(dB/m)
31.53
31.53
Antenna
Factor
(dB/m)
31.53
31.53
Antenna
Factor
(dB/m)
31.58
31.58
Antenna
Factor
(dB/m)
31.58
31.58
Antenna
Factor
(dB/m)
31.69
31.69
Antenna
Factor
(dB/m)
31.69
31.69
Lowest
Preamp
Cable
Factor
Loss (dB)
(dB)
10.57
40.24
10.57
40.24
Lowest
Preamp
Cable
Factor
Loss (dB)
(dB)
10.57
40.24
10.57
40.24
Middle
Preamp
Cable
Factor
Loss (dB)
(dB)
10.66
40.15
10.66
40.15
Middle
Preamp
Cable
Factor
Loss (dB)
(dB)
10.66
40.15
10.66
40.15
Highest
Preamp
Cable
Factor
Loss (dB)
(dB)
10.73
40.03
10.73
40.03
Highest
Preamp
Cable
Factor
Loss (dB)
(dB)
10.73
40.03
10.73
40.03
Level:
Peak
Level
(dBuV/m)
Limit Line
(dBuV/m)
Over Limit
(dB)
57.00
48.72
74.00
74.00
-17.00
-25.28
Level
(dBuV/m)
Limit Line
(dBuV/m)
Over Limit
(dB)
Polarization
37.06
36.71
54.00
54.00
-16.94
-17.29
Vertical
Horizontal
Level:
Level:
Polarization
Vertical
Horizontal
Average
Peak
Level
(dBuV/m)
Limit Line
(dBuV/m)
Over Limit
(dB)
59.30
49.73
74.00
74.00
-14.70
-24.27
Level
(dBuV/m)
Limit Line
(dBuV/m)
Over Limit
(dB)
Polarization
38.59
37.44
54.00
54.00
-15.41
-16.56
Vertical
Horizontal
Level:
Level:
Polarization
Vertical
Horizontal
Average
Peak
Level
(dBuV/m)
Limit Line
(dBuV/m)
Over Limit
(dB)
61.52
51.65
74.00
74.00
-12.48
-22.35
Level
(dBuV/m)
Limit Line
(dBuV/m)
Over Limit
(dB)
Polarization
39.68
38.90
54.00
54.00
-14.32
-15.10
Vertical
Horizontal
Level:
Polarization
Vertical
Horizontal
Average
Remark:
1. Final Level =Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1606004
Page 61 of 63
Download: GO182 Mobile Phone Test Report 1 NEXUS TELECOM SERVICES (HK) LIMITED
Mirror Download [FCC.gov]GO182 Mobile Phone Test Report 1 NEXUS TELECOM SERVICES (HK) LIMITED
Document ID3033299
Application IDfJXxZrok3+fPE/AF7PoEoQ==
Document DescriptionTest report
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize298.3kB (3728784 bits)
Date Submitted2016-06-20 00:00:00
Date Available2016-06-20 00:00:00
Creation Date2016-06-14 13:43:39
Producing SoftwareMicrosoft® Word 2010
Document Lastmod2016-06-14 14:52:03
Document TitleTest Report 1
Document CreatorMicrosoft® Word 2010
Document Author: 张永岗

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
XMP Toolkit                     : Adobe XMP Core 4.0-c316 44.253921, Sun Oct 01 2006 17:14:39
Create Date                     : 2016:06:14 13:43:39+08:00
Creator Tool                    : Microsoft® Word 2010
Modify Date                     : 2016:06:14 14:52:03+08:00
Metadata Date                   : 2016:06:14 14:52:03+08:00
Format                          : application/pdf
Creator                         : 张永岗
Title                           : 1
Producer                        : Microsoft® Word 2010
Document ID                     : uuid:00195a4d-c0e9-4c78-8915-fe067b1eeef6
Instance ID                     : uuid:8a7641c6-a65f-4166-8ae3-9f60626201d2
Has XFA                         : No
Page Count                      : 61
Language                        : zh-CN
Author                          : 张永岗
