FCC ID 2AHHEDIABTSPKPRM
Bluetooth Diamond Speaker
by THUMBS UP(UK)LTD
Grantee Code: 2AHHE Product Code: DIABTSPKPRM
Latest application date: 2017-04-28
Device Images
FCC ID Device Details
| FCC ID | 2AHHEDIABTSPKPRM |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AHHE |
| Product Code | DIABTSPKPRM |
| Applicant Business | THUMBS UP(UK)LTD 🇬🇧 |
| Related Domains |  thumbsupuk.com |
| Equipment Class | Bluetooth Diamond Speaker |
| Test Firm | Accurate Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2017-04-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-07-27 | PDF 1.9 MB |
| Internal Photos | Internal Photos | 2017-04-28 | PDF 699.1 KB |
| External Photos | External Photos | 2017-04-28 | PDF 567.2 KB |
| ID Label and Location Info | ID Label/Location Info | 2017-04-28 | PDF 632.5 KB |
| Test Setup photos | Test Setup Photos | 2017-04-28 | PDF 939.5 KB |
| Test Report_part 1 | Test Report | 2017-04-28 | PDF 2.7 MB |
| Test Report_part 2 | Test Report | 2017-04-28 | PDF 4 MB |
| Agency Letter | Cover Letter(s) | 2017-04-28 | PDF 112.7 KB |
| Confidentiality Letter | Cover Letter(s) | 2017-04-28 | PDF 513.2 KB |
| RF Exposure Info | RF Exposure Info | 2017-04-28 | PDF 97.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 56 KB | |
| Schematics Metadata only | Schematics | PDF 97.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 97 KB |
Application Information
| Application ID | uNbJ3Bje1cEZbYDKUHjMSA== |
|---|---|
| Final Action Date | 2017-04-28 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025317140 |
| Model | DIABTSPKPRM |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Bluetooth Diamond Speaker |
| Responsible Party | Lai Summer, summer@thumbsupuk.com , 0845 466 8880 |
| Test Firm | Sean Liu, Accurate Technology Co., Ltd., sean@atc-lab.com  , 86-75526503291 |
| TCB Email | fcc@us.tuv.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 07/27/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| uNbJ3Bje1cEZbYDKUHjMSA== | 2017-04-28 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0004000 | 15C |
Grants
TCB Grant - Application uNbJ3Bje1cEZbYDKUHjMSA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV Rheinland of North America, Inc. 1279 Quarry Lane Suite A Pleasanton, CA 94566 |
Date of Grant: 04/28/2017 Application Dated: 04/28/2017 |
| THUMBS UP(UK)LTD |
| Unit L,Braintree Industrial Estate,Braintree Road |
| HA4 0EJ,Ruislip |
| LONDON, United Kingdom |
| Attention: Lai Summer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHHEDIABTSPKPRM |
| Name of Grantee: | THUMBS UP(UK)LTD |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Bluetooth Diamond Speaker |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0004 |
| Power output listed is conducted. |
EAS Grant - Application uNbJ3Bje1cEZbYDKUHjMSA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
THUMBS UP(UK)LTD Unit L,Braintree Industrial Estate,Braintree Road HA4 0EJ,Ruislip LONDON, United Kingdom |
Date of Grant: 04/28/2017 Application Dated: 04/28/2017 |
| Attention: Lai Summer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHHEDIABTSPKPRM |
| Name of Grantee: | THUMBS UP(UK)LTD |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Bluetooth Diamond Speaker |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0004 |
| Power output listed is conducted. |
| Mail To: |
