CC2530 Zigbee module Teardown Internal Photos - FCC ID 2AHI9CC2530

FCC ID 2AHI9CC2530

Internal Photos

Zigbee module

by Zero Energy Solutions LTD.

Document preview loads when visible.

Document Details

FCC ID2AHI9CC2530
Document ID2933534
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleInternal Photos
ApplicantZero Energy Solutions LTD.
Equipment ClassZigbee module
Product CodeCC2530
Application IDZFS8bNx6MoM2R4ep3p08IQ==
Application PurposeOriginal Equipment
Application Date2016-03-17
Frequency Range2405-2480 MHz
FRN0025337668
Test FirmShenzhen BCTC Technology Co., Ltd.
Certified ByYang Xiaojie Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2016-03-17
Available2016-03-17
Created2016-03-09
Modified2016-03-09
Pages1
File TypeAdobe Acrobat PDF
File Size153161
File SHA-256afca8e5a3c1099f2d839c6218b3c8fb5bbc9b910acfb170e4f63c53c3d366c5b
PDF Metadata Authorjade
PDF Metadata ProducerAcrobat Distiller 10.1.0 (Windows) jade
FCC.gov SourcesFCC.gov 2933534
