FCC ID 2AHLA-576253
WiFi/BT Module Card
by Bosch Automotive Service Solutions Inc
Grantee Code: 2AHLA Product Code: 576253
Latest application date: 2016-09-25
Device Images
FCC ID Device Details
| FCC ID | 2AHLA-576253 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AHLA |
| Product Code | 576253 |
| Applicant Business | Bosch Automotive Service Solutions Inc 🇺🇸 |
| Related Domains |  us.bosch.com |
| Equipment Class | WiFi/BT Module Card |
| Test Firm | Intertek Testing Services NA, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-09-25 |
| 2402-2480 MHz | Original Equipment | 2016-09-24 |
| 2402-2480 MHz | Original Equipment | 2016-09-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Antenna List for Module Integration and antennas spec | Users Manual | 2016-09-25 | PDF 2 MB |
| Users manual | Users Manual | 2016-09-25 | PDF 89.1 KB |
| Antenna list for Module Integration and antenna spec | Users Manual | 2016-09-24 | PDF 2 MB |
| User Manual | Users Manual | 2016-09-24 | PDF 130.3 KB |
| User manual | Users Manual | 2016-09-24 | PDF 130.3 KB |
| User manual | Users Manual | 2016-09-24 | PDF 89.1 KB |
| Internal photos | Internal Photos | 2016-09-25 | PDF 437.4 KB |
| External photos | External Photos | 2016-09-25 | PDF 268.5 KB |
| Label artwork and location info | ID Label/Location Info | 2016-09-25 | PDF 147.6 KB |
| Test setup photos | Test Setup Photos | 2016-09-25 | PDF 618.6 KB |
| Test report U-NII- 2A | Test Report | 2016-09-25 | PDF 5.1 MB |
| Test report U-NII-1 | Test Report | 2016-09-25 | PDF 4.8 MB |
| Test report U-NII-2C | Test Report | 2016-09-25 | PDF 5.5 MB |
| Test report U-NII-3 | Test Report | 2016-09-25 | PDF 4.8 MB |
| Test Report Wi-Fi part 1 | Test Report | 2016-09-24 | PDF 3.8 MB |
| Test Report Wi-Fi part 2 | Test Report | 2016-09-24 | PDF 3.8 MB |
| Test report | Test Report | 2016-09-24 | PDF 4.7 MB |
| Test report BBLE | Test Report | 2016-09-24 | PDF 3.3 MB |
| 5.6 - 5.65 GHz band restriction | Attestation Statements | 2016-09-25 | PDF 112.3 KB |
| Modular Approval Justification | Attestation Statements | 2016-09-25 | PDF 41.6 KB |
| Confidentiality request | Cover Letter(s) | 2016-09-25 | PDF 187.3 KB |
| Letter of agency | Cover Letter(s) | 2016-09-25 | PDF 199.5 KB |
| Module Integration Instructions for Module 576253_ 9-16-16 | Cover Letter(s) | 2016-09-25 | PDF 25.8 KB |
| Confidentiality letter | Cover Letter(s) | 2016-09-24 | PDF 187.3 KB |
| Confidentiality_Request | Cover Letter(s) | 2016-09-24 | PDF 187.3 KB |
| Letter of egensy | Cover Letter(s) | 2016-09-24 | PDF 199.5 KB |
| Module Integration Instructions | Cover Letter(s) | 2016-09-24 | PDF 40.6 KB |
| Module integration instruction | Cover Letter(s) | 2016-09-24 | PDF 25.8 KB |
| RF Exposure evaluation | RF Exposure Info | 2016-09-25 | PDF 7.5 KB |
| RF exposure evaluation | RF Exposure Info | 2016-09-24 | PDF 7.5 KB |
| Block diagram Metadata only | Block Diagram | PDF 19.1 KB | |
| Schematics Metadata only | Schematics | PDF 105.3 KB | |
| Operational description Metadata only | Operational Description | PDF 78.1 KB |
Application Information
| Application ID | G6yRcpdSIHayCpPTgqsUWw== |
|---|---|
| Final Action Date | 2016-09-25 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025315045 |
| Model | 576253 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | WiFi/BT Module Card |
| Responsible Party | Eric Vande Zande, Senior Electrical Engineer, eric.vandezande@us.bosch.com , 507-455-7000 |
| Agent | Krishna Krishna Krishna, Intertek Testing Services, krishna.vemuri@intertek.com  , 6504632900 |
| Technical Contact | Eric Vande Zande, Bosch Automotive Service Solutions Inc, eric.vandezande@us.bosch.com , (507) 455-7000 |
| Non-Technical Contact | Eric Vande Zande, Bosch Automotive Service Solutions Inc, eric.vandezande@us.bosch.com , (507) 455-7000 |
| Test Firm | Charles Parker, Intertek Testing Services NA, Inc., charles.parker@intertek.com , 949-448-4100 |
| TCB Email | TCB_Admin@intertek.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Output power listed is conducted. The antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines.. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end users must be provided with specific information required to satisfy RF exposure compliance for the final host device. Only those antennas tested with the device or similar antennas with equal or lesser gain may be used with this transmitter. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and KDB 905462 D01 as a Client only without Radar Detection. The device has a 20 MHz, 40 MHz and 80 MHz bandwidth modes. |
