FCC ID 2AHMHHD766

FCC ID 2AHMHHD766 ID-Label-Location-Info, 2AHMH HD766, 2AHMHHD766

ShenZhen Hiyunton Digital Communication CO., LTD. Two-Way Radio (FM and DMR) HD766

An FCC ID is the product ID assigned by the FCC to identify wireless products in the market. The FCC chooses 3 or 5 character "Grantee" codes to identify the business that created the product. For example, the grantee code for FCC ID: 2AHMHHD766 is 2AHMH. The remaining characters of the FCC ID, HD766, are often associated with the product model, but they can be random. These letters are chosen by the applicant. In addition to the application, the FCC also publishes internal images, external images, user manuals, and test results for wireless devices. They can be under the "exhibits" tab below.

Purchase on Amazon: Two-Way Radio (FM and DMR)

FCC ID 2AHMHHD766 ID-Label-Location-Info

*Please Check Individual Documents for more images

Application: Two-Way Radio (FM and DMR)
Equipment Class: TNF - Licensed Non-Broadcast Transmitter Held to Face
Short Link: fcc.id/2AHMHHD766
Sources: FCC.gov | FCC.report
Registered By: ShenZhen Hiyunton Digital Communication CO., LTD. - 2AHMH (China)

App #	Purpose	Date	Unique ID
1	Original Equipment	2016-03-25	UVeEijxeagLT61xexbCpiQ==

Operating Frequencies

Frequency Range	Power Output	Tolerance	Emission Designator	Rule Parts	Grant Notes	Line Entry
406.1125-419.9875 MHz	4.12 Watts	77Hz	7K34FXW	9	EF, ES	2
406.1125-419.9875 MHz	4.12 Watts	77Hz	7K34FXD	9	EF, ES	3
406.1125-419.9875 MHz	1.16 Watts	93Hz	9K89F3E	9	EF, ES	7
406.1125-419.9875 MHz	1.17 Watts	146Hz	7K71FXW	9	EF, ES	8
406.1125-419.9875 MHz	1.25 Watts	146Hz	7K71FXD	9	EF, ES	9
421.0125-469.9875 MHz	1.25 Watts	114Hz	9K90F3E	9	EF, ES	1
421.0125-469.9875 MHz	1.24 Watts	215Hz	7K67FXW	9	EF, ES	11
421.0125-469.9875 MHz	1.24 Watts	215Hz	7K67FXD	9	EF, ES	12
421.0125-469.9875 MHz	4.31 Watts	110Hz	9K88F3E	9	EF, ES	4
421.0125-469.9875 MHz	4.39 Watts	223Hz	7K13FXW	9	EF, ES	5
421.0125-469.9875 MHz	4.39 Watts	223Hz	7K13FXD	9	EF, ES	6

Exhibits

Document	Type	Submitted Available
Confidentiality Letter	Cover Letter(s) Adobe Acrobat PDF (14 kB)	2016-03-25 2016-03-25
Agents Letter	Cover Letter(s) Adobe Acrobat PDF (13 kB)	2016-03-25 2016-03-25
SAR Report	RF Exposure Info Adobe Acrobat PDF (2051 kB)	2016-03-25 2016-03-25
Internal Photos	Internal Photos Adobe Acrobat PDF (448 kB)	2016-03-25 2016-09-20
User Manual	Users Manual Adobe Acrobat PDF (311 kB)	2016-03-25 2016-09-20
Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (174 kB)	2016-03-25 2016-09-20
Test Report	Test Report Adobe Acrobat PDF (5499 kB)	2016-03-25 2016-03-25
External Photos	External Photos Adobe Acrobat PDF (334 kB)	2016-03-25 2016-09-20
Part 90 Operations Attestation	Attestation Statements Adobe Acrobat PDF (12 kB)	2016-03-25 2016-03-25
Model Attestation	Attestation Statements Adobe Acrobat PDF (203 kB)	2016-03-25 2016-03-25
Radio Attestation	Attestation Statements Adobe Acrobat PDF (46 kB)	2016-03-25 2016-03-25
Label	ID Label/Location Info Adobe Acrobat PDF (159 kB)	2016-03-25 2016-03-25
Tune Up	Parts List/Tune Up Info Adobe Acrobat PDF (60 kB)	2016-03-25
Block Diagram	Block Diagram Adobe Acrobat PDF (93 kB)	2016-03-25
Schematics	Schematics Adobe Acrobat PDF (383 kB)	2016-03-25
Operating Description	Operational Description Adobe Acrobat PDF (113 kB)	2016-03-25
Parts List	Parts List/Tune Up Info Adobe Acrobat PDF (81 kB)	2016-03-25

App #	Document	Date
1	[Re-Sent]Short-Term Confidential Expiration Email generated [Sep 12 2016]	2016-09-12 14:06:03
1	[Re-Sent]Short-Term Confidential Expiration Email generated [Sep 12 2016]	2016-09-12 14:15:45

App #

Document

Date

[Re-Sent]Short-Term Confidential Expiration Email generated [Sep 12 2016]

2016-09-12 14:06:03

[Re-Sent]Short-Term Confidential Expiration Email generated [Sep 12 2016]

2016-09-12 14:15:45

Application Forms

Application for Equipment Authorization FCC Form 731 TCB Version

Applicant Information

Applicant's complete, legal business name:	ShenZhen Hiyunton Digital Communication CO., LTD.
FCC Registration Number (FRN):	0025157322
Alphanumeric FCC ID:	2AHMHHD766
Unique Application Identifier:	UVeEijxeagLT61xexbCpiQ==
Line one:	4F,3building,LiMing Industrial Park,
Line two:	YuQuan road,Nanshan District,
City:	Shenzhen
State:	N/A
Country:	China
Zip Code:	518000

TCB Information

TCB Application Email Address:	VKerai@tuvam.com
TCB Scope:	B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95 & 97

FCC ID

Grantee Code:	2AHMH
Product Code:	HD766

Person at the applicant's address to receive grant or for contact

Name:

Richell Min

Telephone Number:

+86-755-88861168

Extension:

Fax Number:	+86-755-88861168
Email:	minsh@hiyunton.com

Long-Term Confidentiality

Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules?: Yes

Short-Term Confidentiality

Does short-term confidentiality apply to this application?: Yes

If so, specify the short-term confidentiality release date (MM/DD/YYYY format): 09/20/2016
Note: If no date is supplied, the release date will be set to 45 calendar days past the date of grant.

Software Defined/Cognitive Radio

Is this application for software defined/cognitive radio authorization? No

Equipment Class

Equipment Class: TNF - Licensed Non-Broadcast Transmitter Held to Face
Description of product as it is marketed: (NOTE: This text will appear below the equipment class on the grant):	Two-Way Radio (FM and DMR)

Related OET KnowledgeDataBase Inquiry

Is there a KDB inquiry associated with this application? No

Modular Equipment

Modular Type: Does not apply

Application Purpose

Application is for: Original Equipment

Composite/Related Equipment

Is the equipment in this application a composite device subject to an additional equipment authorization? No

Is the equipment in this application part of a system that operates with, or is marketed with, another device that requires an equipment authorization? No

Test Firm Information

Name of test firm and contact person on file with the FCC:

Firm Name: Shenzhen Huatongwei International Insp. Co., Ltd

First Name: Moffy

Last Name: Yu

Telephone Number:

86-755-26748078

Extension:

Fax Number: 86-755-26748089

E-mail: moffy.yu@szhtw.com.cn

Grant Comments

Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization:
Power listed is conducted. This device must be restricted to work related operations in an Occupational/Controlled RF exposure Environment, not exceeding a maximum transmitting duty factor of 50%. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration to comply with the Occupational/Controlled MPE limit and requirements. A label, as described in this filing, must be displayed on the device to direct users to specific training information for meeting Occupational Exposure Requirements. SAR compliance for body-worn operating configurations is limited to the specific belt-clip/holster/accessories tested for this filing. SAR compliance for front-of-face operating configurations requires a minimum separation distance of 25 mm to be maintained. End-users must be informed of the front-of-face operating requirements for satisfying RF exposure compliance.. The highest reported SAR for front-of-face and body-worn transmission are 3.47 W/Kg, and 5.51 W/kg respectively with 50% duty cycle.

Set the grant of this application to be deferred to a specified date:
No

Equipment Authorization Waiver

Is there an equipment authorization waiver associated with this application? No

If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded?: No

WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503).

SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION:

The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes.

Does the applicant or authorized agent so certify? Yes

Applicant/Agent Certification:

I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements.

Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application.

If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time.

Signature of Authorized Person Filing: Richell Min

Title of authorized signature:

Grants

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

TUV SUD BABT
Octagon House, Concorde Way, Segensworth North,
Fareham, PO15 5RL
United Kingdom

Date of Grant: 03/25/2016

Application Dated: 03/25/2016

ShenZhen Hiyunton Digital Communication CO., LTD.

4F,3building,LiMing Industrial Park,

YuQuan road,Nanshan District,

Shenzhen, 518000
China

Attention: Richell Min

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2AHMHHD766

Name of Grantee:	ShenZhen Hiyunton Digital Communication CO., LTD.

Equipment Class:	Licensed Non-Broadcast Transmitter Held to Face
Notes:	Two-Way Radio (FM and DMR)

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
EF ES	90	406.1125 - 419.9875	3.59	81.0 Hz	9K89F3E
EF ES	90	406.1125 - 419.9875	4.12	77.0 Hz	7K34FXW
EF ES	90	406.1125 - 419.9875	4.12	77.0 Hz	7K34FXD
EF ES	90	421.0125 - 469.9875	4.31	110.0 Hz	9K88F3E
EF ES	90	421.0125 - 469.9875	4.39	223.0 Hz	7K13FXW
EF ES	90	421.0125 - 469.9875	4.39	223.0 Hz	7K13FXD
EF ES	90	406.1125 - 419.9875	1.16	93.0 Hz	9K89F3E
EF ES	90	406.1125 - 419.9875	1.17	146.0 Hz	7K71FXW
EF ES	90	406.1125 - 419.9875	1.25	146.0 Hz	7K71FXD
EF ES	90	421.0125 - 469.9875	1.25	114.0 Hz	9K90F3E
EF ES	90	421.0125 - 469.9875	1.24	215.0 Hz	7K67FXW
EF ES	90	421.0125 - 469.9875	1.24	215.0 Hz	7K67FXD

Power listed is conducted. This device must be restricted to work related operations in an Occupational/Controlled RF exposure Environment, not exceeding a maximum transmitting duty factor of 50%. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration to comply with the Occupational/Controlled MPE limit and requirements. A label, as described in this filing, must be displayed on the device to direct users to specific training information for meeting Occupational Exposure Requirements. SAR compliance for body-worn operating configurations is limited to the specific belt-clip/holster/accessories tested for this filing. SAR compliance for front-of-face operating configurations requires a minimum separation distance of 25 mm to be maintained. End-users must be informed of the front-of-face operating requirements for satisfying RF exposure compliance..

The highest reported SAR for front-of-face and body-worn transmission are 3.47 W/Kg, and 5.51 W/kg respectively with 50% duty cycle.

EF:	This device may contain functions that are not operational in U.S Territories except as noted in the filing. This grant has extended frequencies as noted in the filing and Section 2.927(b) applies to this authorization.
ES:	This equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

ShenZhen Hiyunton Digital Communication CO., LTD.
4F,3building,LiMing Industrial Park, YuQuan road,Nanshan District,
Shenzhen, 518000
China
