FCC ID 2AHMP-PILL
Pill Speaker
by Da Tong Electronic Headset Co., Ltd
Grantee Code: 2AHMP Product Code: PILL
Latest application date: 2016-03-18
Device Images
FCC ID Device Details
| FCC ID | 2AHMP-PILL |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AHMP |
| Product Code | PILL |
| Applicant Business | Da Tong Electronic Headset Co., Ltd 🇨🇳 |
| Equipment Class | Pill Speaker |
| Test Firm | Shenzhen Anbotek Compliance Laboratory Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-03-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-03-18 | PDF 75.5 KB |
| Internal Photos | Internal Photos | 2016-03-18 | PDF 284.4 KB |
| External Photos | External Photos | 2016-03-18 | PDF 277.2 KB |
| Label | ID Label/Location Info | 2016-03-18 | PDF 9.5 KB |
| Label Location | ID Label/Location Info | 2016-03-18 | PDF 43.7 KB |
| RF Test Set-Up Photos | Test Setup Photos | 2016-03-18 | PDF 106.5 KB |
| RF Test Report | Test Report | 2016-03-18 | PDF 2.8 MB |
| Authorization Letter | Cover Letter(s) | 2016-03-18 | PDF 24.1 KB |
| LTC Letter | Cover Letter(s) | 2016-03-18 | PDF 25.3 KB |
| RF Exposure Report | RF Exposure Info | 2016-03-18 | PDF 164.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 56 KB | |
| Schematics Metadata only | Schematics | PDF 615.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 39.1 KB |
Application Information
| Application ID | sLL3A6UqyjqYWGv9kOjeVQ== |
|---|---|
| Final Action Date | 2016-03-18 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013268917 |
| Model | PILL |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Pill Speaker |
| Responsible Party | Minjian Hu, General Manager, jyxiaobao@me.com  , 010 67228488 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum conducted output power. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| sLL3A6UqyjqYWGv9kOjeVQ== | 2016-03-18 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0017700 | 15C |
Grants
TCB Grant - Application sLL3A6UqyjqYWGv9kOjeVQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 03/18/2016 Application Dated: 03/18/2016 |
| Da Tong Electronic Headset Co., Ltd |
| G3-17866, Yiwu International Trade Town, |
| Yiwu, Zhejiang Province, China |
| Attention: Minjian Hu , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHMP-PILL |
| Name of Grantee: | Da Tong Electronic Headset Co., Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Pill Speaker |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00177 |
| Power listed is the maximum conducted output power. |
EAS Grant - Application sLL3A6UqyjqYWGv9kOjeVQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Da Tong Electronic Headset Co., Ltd G3-17866, Yiwu International Trade Town, Yiwu, Zhejiang Province, China |
Date of Grant: 03/18/2016 Application Dated: 03/18/2016 |
| Attention: Minjian Hu , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHMP-PILL |
| Name of Grantee: | Da Tong Electronic Headset Co., Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Pill Speaker |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00177 |
| Power listed is the maximum conducted output power. |
| Mail To: |
