FCC ID 2AHNW-3010

GPS tracker

by WayRay SA

Grantee Code: 2AHNW Product Code: 3010

Latest application date: 2017-05-18

Device Images

FCC ID 2AHNW-3010 Users Manual — Users Manual

FCC ID Device Details

FCC ID	2AHNW-3010
Mirrors	fcc.id \| gov \| fccid.ai
Grantee Code	2AHNW
Product Code	3010
Applicant Business	WayRay SA 🇨🇭
Related Domains	wayray.com baluntek.com
Equipment Class	GPS tracker
Test Firm	Shenzhen BALUN Technology Co.,Ltd.

Linked Records

Barcode records decoded from published FCC label exhibits or linked by an explicit FCC ID reference on a product page.

UPC / GTIN	Linked product
1232354365460 EAN-13 · GTIN-14 01232354365460	GPS tracker 3010 Brand: WayRay SA · Model: 3010 Source: FCC label

Operating Frequencies

Frequency Range	Application Purpose	Final Action Date
824.2-848.8 MHz	Original Equipment	2017-05-18
2402-2480 MHz	Original Equipment	2017-05-18
2402-2480 MHz	Original Equipment	2017-05-18

Exhibits

Document	Type	Available	File
Users Manual	Users Manual	2017-05-18	PDF 204.5 KB
Internal Photos	Internal Photos	2017-05-18	PDF 1.3 MB
External Photos	External Photos	2017-05-18	PDF 731 KB
ID Label/Location Info	ID Label/Location Info	2017-05-18	PDF 65.8 KB
ID Label/Location Info	ID Label/Location Info	2017-05-18	PDF 956.3 KB
Test Setup Photos	Test Setup Photos	2017-05-18	PDF 356.7 KB
Test Setup Photos	Test Setup Photos	2017-05-18	PDF 1.2 MB
Data Part 1	Test Report	2017-05-18	PDF 387 KB
Data Part 2	Test Report	2017-05-18	PDF 147.4 KB
Data Part 3	Test Report	2017-05-18	PDF 174.8 KB
Data Part 4	Test Report	2017-05-18	PDF 91.9 KB
Data Part 5	Test Report	2017-05-18	PDF 632.5 KB
Test Report	Test Report	2017-05-18	PDF 2 MB
Test Report	Test Report	2017-05-18	PDF 2.5 MB
Test Report	Test Report	2017-05-18	PDF 1.2 MB
Test report for 4G Random-access Memory	Test Report	2017-05-18	PDF 4.4 MB
Test report for 8G Random-access Memory	Test Report	2017-05-18	PDF 951 KB
Authorization Letter	Cover Letter(s)	2017-05-18	PDF 1.7 MB
Confidentiality	Cover Letter(s)	2017-05-18	PDF 67.9 KB
MPE	RF Exposure Info	2017-05-18	PDF 240.9 KB
Block Diagram Metadata only	Block Diagram		PDF 1.7 MB
Schematics Metadata only	Schematics		PDF 2.6 MB
Operation Desription Metadata only	Operational Description		PDF 921.7 KB
Operational Description Metadata only	Operational Description		PDF 921.7 KB
BOM Metadata only	Parts List/Tune Up Info		PDF 86.1 KB
Tune up Procedure Metadata only	Parts List/Tune Up Info		PDF 931.7 KB
Tune-up procedure Metadata only	Parts List/Tune Up Info		PDF 931.7 KB

Application Information

Application ID	f5ISS5Td9dxsEnCoe3a+3g==
Final Action Date	2017-05-18
Application Purpose	Original Equipment
Applicant FRN	0024214330
Model	3010
Equipment Class	JBP - Part 15 Class B Computing Device Peripheral
Device Description	GPS tracker
Responsible Party	Alexander Bobryshev, Chief Design Engineer, aleksandr@wayray.com , +79160446205
Agent	Wu Wu Wu, Shenzhen BALUN Technology Co., Ltd., xuewen.wu@baluntek.com , 86-755-66833404
Technical Contact	xuewen wu, Shenzhen BALUN Technology Co., Ltd., xuewen.wu@baluntek.com , 86-755-66833404
Non-Technical Contact	Tiffany Zhang, Shenzhen BALUN Technology Co., Ltd., yanfei.zhang@baluntek.com , 86-755-66850100
Test Firm	Xuewen Wu, Shenzhen BALUN Technology Co.,Ltd., xuewen.wu@baluntek.com , 86-755-66833404
TCB Email	certification@telefication.com
TCB Scope	A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices
Short-Term Confidentiality	No
Long-Term Confidentiality	Yes
Grant Deferral	No
Modular Equipment	Does not apply
Composite Device	Yes
Composite Part	No
Cognitive Radio	No
Authorization Waiver	No
Authorization Waiver Approved	No
Section 5301 Certification	Yes
Related OET Knowledge DataBase Inquiry	No

Applications

Application ID	Date	Purpose
f5ISS5Td9dxsEnCoe3a+3g==	2017-05-18	Original Equipment
eAeFEto02n46tx3wh2FCSA==	2017-05-18	Original Equipment
XR3+jroU+DZQN3FOWYNKqQ==	2017-05-18	Original Equipment
60GxOOyPeYxoujZAVxEanA==	2017-05-18	Original Equipment

Equipment Authorization

Frequency	Output	Tolerance	Emission	Rules	Grant Notes
				15B	CC
824.2-848.8 MHz	1.39	9.18Hz	250MGXW	22H
826.4-846.6 MHz	0.33	9.25Hz	4M16F9W	22H
1850.2-1909.8 MHz	1.58	9.52Hz	250MGXW	24E
1852.4-1907.6 MHz	0.29	8.61Hz	4M15F9W	24E
2402-2480 MHz	0.0001400			15C	CC
2402-2480 MHz	0.0008000			15C	CC

Grants

TCB Grant - Application XR3+jroU+DZQN3FOWYNKqQ==

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Telefication B.V.
Wilmersdorf 50
Apeldoorn, NL-7300 AC
Netherlands

Date of Grant: 05/18/2017

Application Dated: 05/18/2017

WayRay SA

Avenue de Gratta-Paille 1-2, CH - 1018

Lausanne, 1003
Switzerland

Attention: Alexander Bobryshev , Chief Design Engineer

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2AHNW-3010

Name of Grantee:	WayRay SA

Equipment Class:	Part 15 Spread Spectrum Transmitter
Notes:	GPS tracker

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
CC	15C	2402.0 - 2480.0	0.0008

Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.

CC:	This device is certified pursuant to two different Part 15 rules sections.
