HSA15 OBD II Sensor Test Report - FCC ID 2AHPN-HSA-15

FCC ID 2AHPN-HSA-15

Test Report - Part 2

OBD II Sensor

by Harman International Industries, Inc.

Document preview loads when visible.

Document Details

FCC ID2AHPN-HSA-15
Document ID3915666
Document TypeTest Report
DescriptionTest Report - Part 2
Document Title2018-05-29_FCC_Part_22_24_27_RF_Report-31851514.001x
ApplicantHarman International Industries, Inc.
Equipment ClassOBD II Sensor
Product CodeHSA15
Application ID5oxr3MkvVI21kHLxMUp7Cw==
Application PurposeOriginal Equipment
Application Date2018-07-13
Frequency Range1710-1755 MHz
FRN0026894154
Test FirmTUV Rheinland of North America Inc.
Certified BySireesha Mallipeddi Senior Product Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2018-07-06
Available2018-07-13
Created2018-07-06
Modified2018-07-06
Pages81
File TypeAdobe Acrobat PDF
File Size4253060
File SHA-256f86ab65a1601b88339e035ef5d55ae30082fb614094e5e01ebf3379403639d47
PDF Metadata Authoriaguilar
PDF Metadata Produceriaguilar Acrobat Distiller 10.1.5 (Windows)
FCC.gov SourcesFCC.gov 3915666
