EPAC1651 Wireless Adapter Test Setup Photos - FCC ID 2AHRDEP-AC1651

FCC ID 2AHRDEP-AC1651

Test setup photo

Wireless Adapter

by Shenzhen EDUP Electronics Technology Co.,Ltd.

Document preview loads when visible.

Document Details

FCC ID2AHRDEP-AC1651
Document ID5283141
Document TypeTest Setup Photos
DescriptionTest setup photo
Document TitleTest Setup photos WIFI
ApplicantShenzhen EDUP Electronics Technology Co.,Ltd.
Equipment ClassWireless Adapter
Product CodeEPAC1651
Application ID+mT2eBwrUpc64tgSJGC4aw==
Application PurposeOriginal Equipment
Application Date2021-06-08
Frequency Range2412-2462 MHz
FRN0025412040
Test FirmBay Area Compliance Laboratories Corp.(Dongguan)
Certified ByZhou Chunping
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-06-08
Available2021-06-08
Created2021-05-17
Modified2021-05-17
Pages3
File TypeAdobe Acrobat PDF
File Size457417
File SHA-2567d0ec036832ff7cadce34d951f6be3c2a55d9f77bcb14790867bd2c1a2e0672b
PDF Metadata AuthorCNAS07
PDF Metadata ProducerCNAS07 Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 5283141
