FCC ID 2AHU6-EW1200
Wireless Router
by Shenzhen Afoundry Electronic Co.,Ltd.
Grantee Code: 2AHU6 Product Code: EW1200
Latest application date: 2016-05-20
Device Images
FCC ID Device Details
| FCC ID | 2AHU6-EW1200 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AHU6 |
| Product Code | EW1200 |
| Applicant Business | Shenzhen Afoundry Electronic Co.,Ltd. 🇨🇳 |
| Related Domains |  afoundry.com.cn |
| Equipment Class | Wireless Router |
| Test Firm | Shenzhen LCS Compliance Testing Laboratory Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-05-20 |
| 2412-2462 MHz | Original Equipment | 2016-05-20 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-05-20 | PDF 4.3 MB |
| Int photo | Internal Photos | 2016-05-20 | PDF 268.9 KB |
| Ext photo | External Photos | 2016-05-20 | PDF 561.2 KB |
| ID label | ID Label/Location Info | 2016-05-20 | PDF 114.2 KB |
| Test setup photo | Test Setup Photos | 2016-05-20 | PDF 482.9 KB |
| Test report | Test Report | 2016-05-20 | PDF 3.7 MB |
| Test report_15.407-5150-5250 | Test Report | 2016-05-20 | PDF 4.7 MB |
| Test report_15.407-5725-5850 | Test Report | 2016-05-20 | PDF 4.5 MB |
| DoC Attestation Letter | Cover Letter(s) | 2016-05-20 | PDF 110.1 KB |
| Confidential request letter | Cover Letter(s) | 2016-05-20 | PDF 154.5 KB |
| POA | Cover Letter(s) | 2016-05-20 | PDF 178.5 KB |
| WiFi ch 12-13 letter | Cover Letter(s) | 2016-05-20 | PDF 341.1 KB |
| RF exposure | RF Exposure Info | 2016-05-20 | PDF 504.9 KB |
| Block diagram Metadata only | Block Diagram | PDF 14.3 KB | |
| SCH Metadata only | Schematics | PDF 477.7 KB | |
| OpDes Metadata only | Operational Description | PDF 109.7 KB | |
| SW security cover Letter Metadata only | Operational Description | PDF 256.6 KB |
Application Information
| Application ID | Np/bVAmrFUNlUk/giwR7gQ== |
|---|---|
| Final Action Date | 2016-05-20 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025445784 |
| Model | EW1200 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless Router |
| Responsible Party | Jiao Chen, Administrative Manager, chenjiao@afoundry.com.cn , 0755-82910479 |
| Test Firm | Gavin Liang, Shenzhen LCS Compliance Testing Laboratory Ltd., Gavin.liang@lcs-cert.com  , 86-0755-82591330 |
| TCB Email | TCB@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum combined conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Device is 2X2 MIMO. Device contains 20MHz , 40MHz and 80 MHz signal bandwidth. |
