FCC ID 2AHVHLG8864
Wifi Module
by Shen Zhen MTC Co., LTD
Grantee Code: 2AHVH Product Code: LG8864
Latest application date: 2016-09-12
Device Images
FCC ID Device Details
| FCC ID | 2AHVHLG8864 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AHVH |
| Product Code | LG8864 |
| Applicant Business | Shen Zhen MTC Co., LTD 🇨🇳 |
| Related Domains |  szmtc.com.cn  intertek.com |
| Equipment Class | Wifi Module |
| Test Firm | Intertek Testing Services Shenzhen Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-09-12 |
| 2412-2462 MHz | Original Equipment | 2016-09-12 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-09-12 | PDF 727.2 KB |
| Internal Photos | Internal Photos | 2016-09-12 | PDF 289.6 KB |
| External Photos | External Photos | 2016-09-12 | PDF 267.7 KB |
| Label Artwork an Location | ID Label/Location Info | 2016-09-12 | PDF 442.3 KB |
| Conducted Emission | Test Setup Photos | 2016-09-12 | PDF 92.5 KB |
| Conducted emission | Test Setup Photos | 2016-09-12 | PDF 2 MB |
| Radiated Emission | Test Setup Photos | 2016-09-12 | PDF 242.4 KB |
| conducted photos | Test Setup Photos | 2016-09-12 | PDF 92.5 KB |
| radiated photos | Test Setup Photos | 2016-09-12 | PDF 242.4 KB |
| 26dB EBW | Test Report | 2016-09-12 | PDF 2.5 MB |
| 6dB Bandwidth | Test Report | 2016-09-12 | PDF 132.5 KB |
| 6dB bw | Test Report | 2016-09-12 | PDF 268 KB |
| 99 percent OBW | Test Report | 2016-09-12 | PDF 2.3 MB |
| PSD | Test Report | 2016-09-12 | PDF 2.3 MB |
| PSD | Test Report | 2016-09-12 | PDF 750.6 KB |
| report-DTS | Test Report | 2016-09-12 | PDF 309.5 KB |
| report-NII | Test Report | 2016-09-12 | PDF 388.3 KB |
| Confidentiality Request | Cover Letter(s) | 2016-09-12 | PDF 158.4 KB |
| Declaration | Cover Letter(s) | 2016-09-12 | PDF 438.9 KB |
| KDB 594280D02 | Cover Letter(s) | 2016-09-12 | PDF 556 KB |
| Letter of Agency | Cover Letter(s) | 2016-09-12 | PDF 169.6 KB |
| Modular Approval Justification | Cover Letter(s) | 2016-09-12 | PDF 289.6 KB |
| RF Exposure | RF Exposure Info | 2016-09-12 | PDF 109 KB |
| RF Exposure Info | RF Exposure Info | 2016-09-12 | PDF 109 KB |
| Block Diagram Metadata only | Block Diagram | PDF 246.1 KB | |
| Circuit Diagram Metadata only | Schematics | PDF 460.2 KB | |
| Technical Description Metadata only | Operational Description | PDF 20.1 KB |
Application Information
| Application ID | g2fffybjvFxyacpD+QYghA== |
|---|---|
| Final Action Date | 2016-09-12 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025449661 |
| Model | LG8864 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wifi Module |
| Responsible Party | Feng Pu, Certification Manager, kilterpu@szmtc.com.cn , 86-755-32901695 |
| Agent | Stella Stella Stella, Intertek Testing Services Shenzhen Ltd. Kejiyuan B, Stella.xh.yang@intertek.com , (86-755)86140712 |
| Technical Contact | Stella Yang, Intertek Testing Services Shenzhen Ltd. Kejiyuan B, Stella.xh.yang@intertek.com , (86-755) 8614 0712 |
| Non-Technical Contact | Stella Yang, Intertek Testing Services Shenzhen Ltd. Kejiyuan B, Stella.xh.yang@intertek.com , (86-755) 8614 0712 |
| Test Firm | Shawn Xing, Intertek Testing Services Shenzhen Ltd., Shawn.xing@intertek.com , 86-75586140603 |
| TCB Email | tcb_admin@intertek.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. Approval is limited to OEM installation only in mobile RF exposure configurations. Installation of this device in Portable RF exposure configurations requires a permissive change application or new filing. Compliance of this device in all final product configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Only those antennas tested with the device or similar type antennas with same or lesser gain may be used with this transmitter. This device has 20/40/80 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| g2fffybjvFxyacpD+QYghA== | 2016-09-12 | Original Equipment |
| HS5DpiQcAENIsy68COniXg== | 2016-09-12 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application HS5DpiQcAENIsy68COniXg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Intertek Testing Services NA, Inc. 70 Codman Hill Road Boxborough, MA 01719 |
Date of Grant: 09/12/2016 Application Dated: 09/12/2016 |
| Shen Zhen MTC Co., LTD |
| MTC Industry Park, 1st Lilang Road, Xialilang |
| community, Nanwan street, Longgang district, |
| Shenzhen, China |
| Attention: Feng Pu , Certification Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHVHLG8864 |
| Name of Grantee: | Shen Zhen MTC Co., LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | Wifi Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.3548 |
| Power output listed is conducted. Approval is limited to OEM installation only in mobile RF exposure configurations. Installation of this device in portable RF exposure configuration requires a permissive change application or new filing. Compliance of this device in all final product configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter product procedures. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Only those antennas tested with the device or similar type antennas with same or lesser gain may be used with this transmitter. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application HS5DpiQcAENIsy68COniXg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shen Zhen MTC Co., LTD MTC Industry Park, 1st Lilang Road, Xialilang community, Nanwan street, Longgang district, Shenzhen, China |
Date of Grant: 09/12/2016 Application Dated: 09/12/2016 |
| Attention: Feng Pu , Certification Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHVHLG8864 |
| Name of Grantee: | Shen Zhen MTC Co., LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | Wifi Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.3548 |
| Power output listed is conducted. Approval is limited to OEM installation only in mobile RF exposure configurations. Installation of this device in portable RF exposure configuration requires a permissive change application or new filing. Compliance of this device in all final product configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter product procedures. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Only those antennas tested with the device or similar type antennas with same or lesser gain may be used with this transmitter. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
