FCC ID 2AHXS-A28188E
WLAN 11n USB 1T1R Module
by TATUNG COMPANY OF AMERICA, INC.
Grantee Code: 2AHXS Product Code: A28188E
Latest application date: 2016-12-26
Device Images
FCC ID Device Details
| FCC ID | 2AHXS-A28188E |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AHXS |
| Product Code | A28188E |
| Applicant Business | TATUNG COMPANY OF AMERICA, INC. 🇺🇸 |
| Related Domains |  tatungusa.com |
| Equipment Class | WLAN 11n USB 1T1R Module |
| Test Firm | Shenzhen GTI Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-12-26 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_A28188E UserMan,r2 | Users Manual | 2016-12-26 | PDF 836.6 KB |
| 09_A28188E IntPho | Internal Photos | 2016-12-26 | PDF 912.3 KB |
| 08_A28188E ExtPho | External Photos | 2016-12-26 | PDF 912.3 KB |
| 06-07_A28188E LabelSmpl-Loc | ID Label/Location Info | 2016-12-26 | PDF 443.4 KB |
| 17_A28188E AntSpec | Operational Description | 2016-12-26 | PDF 69.2 KB |
| 10_A28188E TSup | Test Setup Photos | 2016-12-26 | PDF 375.8 KB |
| 14_A28188E TestRpt | Test Report | 2016-12-26 | PDF 2.5 MB |
| 18_A28188E RFExp | RF Exposure Info | 2016-12-26 | PDF 176 KB |
| 12_A28188E BlkDia Metadata only | Block Diagram | PDF 126.7 KB | |
| 13_A28188E Schem Metadata only | Schematics | PDF 45.8 KB | |
| 11_A28188E OpDes Metadata only | Operational Description | PDF 75.3 KB |
Application Information
| Application ID | SvdmWD5maUTI1GcR3f2Ibg== |
|---|---|
| Final Action Date | 2016-12-26 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025473364 |
| Model | A28188E |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WLAN 11n USB 1T1R Module |
| Responsible Party | MIKE LEE, vice president, MLee@tatungusa.com , 310 637 2105 |
| Test Firm | Walter Chen, Shenzhen GTI Technology Co., Ltd., ctc@sz-ctc.com.cn  , 0755-27521059 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. Limited Singular Modular Approval due to the lack of an RF shielding. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. SAR evaluation is valid for mobile only applications (distance minimum 20cm to human bodies). |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| SvdmWD5maUTI1GcR3f2Ibg== | 2016-12-26 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Rules |
|---|---|---|---|
| 2412-2462 MHz | 0.0263000 | ppm | 15C |
Grants
TCB Grant - Application SvdmWD5maUTI1GcR3f2Ibg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 12/26/2016 Application Dated: 12/26/2016 |
| TATUNG COMPANY OF AMERICA, INC. |
| 2850 EI PRESIDIO STREET, |
| LONG BEACH, CA 90810 |
| Attention: MIKE LEE , vice president |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHXS-A28188E |
| Name of Grantee: | TATUNG COMPANY OF AMERICA, INC. |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN 11n USB 1T1R Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0263 |
| Power listed is conducted. Limited Singular Modular Approval due to the lack of an RF shielding. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. SAR evaluation is valid for mobile only applications (distance minimum 20cm to human bodies). |
EAS Grant - Application SvdmWD5maUTI1GcR3f2Ibg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TATUNG COMPANY OF AMERICA, INC. 2850 EI PRESIDIO STREET, LONG BEACH, CA 90810 United States |
Date of Grant: 12/26/2016 Application Dated: 12/26/2016 |
| Attention: MIKE LEE , vice president |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AHXS-A28188E |
| Name of Grantee: | TATUNG COMPANY OF AMERICA, INC. |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN 11n USB 1T1R Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0263 |
| Power listed is conducted. Limited Singular Modular Approval due to the lack of an RF shielding. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. SAR evaluation is valid for mobile only applications (distance minimum 20cm to human bodies). |
| Mail To: |
