FCC ID 2AI3D-SS0001
Transmitter
by Shen zhen shen s Tongchuang Aeronautic Model Co.,Ltd.
Grantee Code: 2AI3D Product Code: SS0001
Latest application date: 2016-08-04
Device Images
FCC ID Device Details
| FCC ID | 2AI3D-SS0001 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AI3D |
| Product Code | SS0001 |
| Applicant Business | Shen zhen shen s Tongchuang Aeronautic Model Co.,Ltd. 🇨🇳 |
| Related Domains |  sstc-sz.com |
| Equipment Class | Transmitter |
| Test Firm | Centre of Testing service Co., Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2406-2475 MHz | Original Equipment | 2016-08-04 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-08-04 | PDF 217.9 KB |
| Internal Photos | Internal Photos | 2016-08-04 | PDF 280.9 KB |
| External Photos | External Photos | 2016-08-04 | PDF 155.8 KB |
| Label | ID Label/Location Info | 2016-08-04 | PDF 84.1 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-04 | PDF 141.6 KB |
| Test Report | Test Report | 2016-08-04 | PDF 405.9 KB |
| Authorization Letter | Cover Letter(s) | 2016-08-04 | PDF 15 KB |
| Confidentiality Request | Cover Letter(s) | 2016-08-04 | PDF 19.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 10 KB | |
| Schematics Metadata only | Schematics | PDF 96.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 6.8 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 45 KB |
Application Information
| Application ID | Tp8LajcvH74q6owK6E8Pmw== |
|---|---|
| Final Action Date | 2016-08-04 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025720103 |
| Model | SS0001 |
| Frequency Range | 2406-2475 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Transmitter |
| Responsible Party | Jin Ma, company@sstc-sz.com , +86-755-29751888 |
| Technical Contact | Susan, CENTRE OF TESTING SERVICE CO., LTD., ctszjy@cts-lab.com  , 86-20-22138571 |
| Test Firm | Vincent Yao, Centre of Testing service Co., Ltd, vincent.yao@cts-lab.com.cn  , 86-20-22138530 |
| TCB Email | certification@micomlabs.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| Tp8LajcvH74q6owK6E8Pmw== | 2016-08-04 | Original Equipment |
Grants
TCB Grant - Application Tp8LajcvH74q6owK6E8Pmw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
MiCOM Labs 575 Boulder Court Pleasanton, CA 94566 |
Date of Grant: 08/04/2016 Application Dated: 08/04/2016 |
| Shen zhen shen s Tongchuang Aeronautic Model Co.,Ltd. |
| Opposite of Xingjiang Community Office |
| Education Base, Guanming New district |
| Shenzhen, China |
| Attention: Jin Ma |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AI3D-SS0001 |
| Name of Grantee: | Shen zhen shen s Tongchuang Aeronautic Model Co.,Ltd. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Transmitter |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 20 | 15C | 2406.0 - 2475.0 |
| 20: | All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed. |
EAS Grant - Application Tp8LajcvH74q6owK6E8Pmw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shen zhen shen s Tongchuang Aeronautic Model Co.,Ltd. Opposite of Xingjiang Community Office Education Base, Guanming New district Shenzhen, China |
Date of Grant: 08/04/2016 Application Dated: 08/04/2016 |
| Attention: Jin Ma |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AI3D-SS0001 |
| Name of Grantee: | Shen zhen shen s Tongchuang Aeronautic Model Co.,Ltd. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Transmitter |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 20 | 15C | 2406.0 - 2475.0 |
| 20: | All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed. |
| Mail To: |
