FCC ID 2AI3QAI-IP008
AC adapter Wi-Fi camera
by Shenzhen Aishine Electronics Co., LTD
Grantee Code: 2AI3Q Product Code: AIIP008
Latest application date: 2016-08-07
Device Images
FCC ID Device Details
| FCC ID | 2AI3QAI-IP008 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AI3Q |
| Product Code | AIIP008 |
| Applicant Business | Shenzhen Aishine Electronics Co., LTD 🇨🇳 |
| Related Domains |  aishine.com |
| Equipment Class | AC adapter Wi-Fi camera |
| Test Firm | Shenzhen Timeway Testing Laboratories |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-08-07 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-08-07 | PDF 715.6 KB |
| Internal photos | Internal Photos | 2016-08-07 | PDF 1.7 MB |
| External photos | External Photos | 2016-08-07 | PDF 835.6 KB |
| Label | ID Label/Location Info | 2016-08-07 | PDF 69.5 KB |
| Label location | ID Label/Location Info | 2016-08-07 | PDF 38.1 KB |
| Test setup | Test Setup Photos | 2016-08-07 | PDF 146.2 KB |
| Test report | Test Report | 2016-08-07 | PDF 5.4 MB |
| Cover letter | Cover Letter(s) | 2016-08-07 | PDF 90.2 KB |
| RF Exposure | RF Exposure Info | 2016-08-07 | PDF 72.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 138.3 KB | |
| Schematics Metadata only | Schematics | PDF 176.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 120.8 KB |
Application Information
| Application ID | IwPyRnrpvKpf4Rdv4z3IZQ== |
|---|---|
| Final Action Date | 2016-08-07 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025726837 |
| Model | AI-IP008 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | AC adapter Wi-Fi camera |
| Responsible Party | Owen Huang, Manager, aishine@aishine.com , +86-755-33132805 |
| Test Firm | Jack Chung, Shenzhen Timeway Testing Laboratories, jack72@126.com  , 0755-83448688 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| IwPyRnrpvKpf4Rdv4z3IZQ== | 2016-08-07 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0914100 | 15C |
Grants
TCB Grant - Application IwPyRnrpvKpf4Rdv4z3IZQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 08/07/2016 Application Dated: 08/07/2016 |
| Shenzhen Aishine Electronics Co., LTD |
| Room 1512, Floor 15th, DongFangTianDe |
| Building, Minzhi, Bao'an District, |
| Shenzhen, China |
| Attention: Owen Huang , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AI3QAI-IP008 |
| Name of Grantee: | Shenzhen Aishine Electronics Co., LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | AC adapter Wi-Fi camera |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.09141 |
| Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application IwPyRnrpvKpf4Rdv4z3IZQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shenzhen Aishine Electronics Co., LTD Room 1512, Floor 15th, DongFangTianDe Building, Minzhi, Bao'an District, Shenzhen, China |
Date of Grant: 08/07/2016 Application Dated: 08/07/2016 |
| Attention: Owen Huang , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AI3QAI-IP008 |
| Name of Grantee: | Shenzhen Aishine Electronics Co., LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | AC adapter Wi-Fi camera |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.09141 |
| Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
