FCC ID 2AI4Y-TYD2496B1RF
2.4G Wireless module
by Shenzhen TaiYuan star technology Co., Ltd.
Grantee Code: 2AI4Y Product Code: TYD2496B1RF
Latest application date: 2016-08-03
Device Images
FCC ID Device Details
| FCC ID | 2AI4Y-TYD2496B1RF |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AI4Y |
| Product Code | TYD2496B1RF |
| Applicant Business | Shenzhen TaiYuan star technology Co., Ltd. 🇨🇳 |
| Related Domains |  yxrobot.com |
| Equipment Class | 2.4G Wireless module |
| Test Firm | Waltek Services(Shenzhen) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2444 MHz | Original Equipment | 2016-08-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-08-03 | PDF 300.6 KB |
| Host Internal Photos | Internal Photos | 2016-08-03 | PDF 166.6 KB |
| RF EUT Internal Photos | Internal Photos | 2016-08-03 | PDF 1.5 MB |
| RF Module Internal Photos | Internal Photos | 2016-08-03 | PDF 263.2 KB |
| Host External Photos | External Photos | 2016-08-03 | PDF 145.9 KB |
| RF EUT External Photos | External Photos | 2016-08-03 | PDF 1.5 MB |
| Label Sample and Label Location | ID Label/Location Info | 2016-08-03 | PDF 52.4 KB |
| Host Test Setup Photos | Test Setup Photos | 2016-08-03 | PDF 226.2 KB |
| Test Report | Test Report | 2016-08-03 | PDF 1.1 MB |
| Confidentiality Letter | Cover Letter(s) | 2016-08-03 | PDF 31.3 KB |
| Modular Approval Letter | Cover Letter(s) | 2016-08-03 | PDF 193 KB |
| POA Letter | Cover Letter(s) | 2016-08-03 | PDF 13.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 39.7 KB | |
| Schematics Metadata only | Schematics | PDF 7.3 KB | |
| Circuit Description Operational Description Metadata only | Operational Description | PDF 29 KB |
Application Information
| Application ID | 9eMtsm37KxhD75ZxV7Nc5A== |
|---|---|
| Final Action Date | 2016-08-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025735655 |
| Model | TYD2496B1RF |
| Frequency Range | 2444 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | 2.4G Wireless module |
| Responsible Party | yongxi Xie, Engineer, xieyongxi@yxrobot.com , (86) 18688169880 |
| Test Firm | philo zhong, Waltek Services(Shenzhen) Co., Ltd., philo@waltek.com.cn  , 8675527553488 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Single Modular Approval. This module is only approved for use when installed in the host (Brand: TYD, Name: Controller, Model: B). Approval is limited to OEM installation only. Compliance of this device is the responsibility of the Grantee. OEM integrators and end-users must be provided with device operating conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
