08202120160719 R/C CAR ( REMOTE... - FCC ID 2AI5408202120160719
FCC ID 2AI5408202120160719
Schematics
R/C CAR ( REMOTE CONTROL )
Document preview loads when visible.
Document Details
| FCC ID | 2AI5408202120160719 |
|---|---|
| Document ID | 3079743 |
| Document Type | Schematics |
| Description | Schematics |
| Applicant | PLAY TEK LIMITED |
| Equipment Class | R/C CAR ( REMOTE CONTROL ) |
| Product Code | 08202120160719 |
| Application ID | pDjnGWgh3yrcLDpK8EqZKA== |
| Application Purpose | Original Equipment |
| Application Date | 2016-07-28 |
| Frequency Range | 49.86 MHz |
| FRN | 0028892305 |
| Test Firm | Bay Area Compliance Laboratory Corp. (Shenzhen) |
| Certified By | CHRIS KWAN |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Submitted | 2016-07-28 |
| Available | 2016-07-28 |
| Created | 2016-07-13 |
| Modified | 2016-07-28 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 78351 |
| File SHA-256 | b33e2d4de34ebfc01125d9898b682edc3bdd3f5bd6ba8f0a75dbf4483623a444 |
| PDF Metadata Producer | iTextSharp 4.1.6 by 1T3XT |
| FCC.gov Sources | FCC.gov 3079743 |
