FCC ID 2AIER-TERFZB
ZigBee RF transceiver
by TYCO ELECTRONICS CORPORATION
Grantee Code: 2AIER Product Code: TERFZB
Latest application date: 2016-09-06
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2475 MHz | Original Equipment | 2016-09-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Installation instructions | Users Manual | 2017-03-05 | PDF 196.1 KB |
| User manual | Users Manual | 2017-03-05 | PDF 255.2 KB |
| Internal Photos | Internal Photos | 2017-03-05 | PDF 277.3 KB |
| External Photos | External Photos | 2017-03-05 | PDF 277.3 KB |
| Label & Location | ID Label/Location Info | 2016-09-06 | PDF 207.2 KB |
| block diagram | Block Diagram | 2016-09-06 | PDF 170.5 KB |
| Schematics | Schematics | 2016-09-06 | PDF 253.8 KB |
| operational description | Operational Description | 2016-09-06 | PDF 578 KB |
| Test Setup Photos | Test Setup Photos | 2017-03-05 | PDF 468.5 KB |
| test report | Test Report | 2016-09-06 | PDF 1 MB |
| Modular Approval Letter | Cover Letter(s) | 2016-09-06 | PDF 82.5 KB |
| Short term confidentiality | Cover Letter(s) | 2016-09-06 | PDF 73 KB |
| Antenna Datasheet | RF Exposure Info | 2016-09-06 | PDF 137.5 KB |
| MPE | RF Exposure Info | 2016-09-06 | PDF 90.7 KB |
Application Information
| Application ID | jGMdCYn1fxp+L1PtjAr0zA== |
|---|---|
| Final Action Date | 2016-09-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025578162 |
| Model | TERFZB |
| Frequency Range | 2405-2475 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | ZigBee RF transceiver |
| Responsible Party | SRIKRISHNA SITARAMAN, s.sitaraman@te.com  , 6503612127 |
| Technical Contact | Ganesh Bhatt, Tyco Electronics Corporation, Ganesh.bhatt@te.com , 717-986-7449 |
| Test Firm | Greg Kovolenko, EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC, greg.kovolenko@metlabs.com  , 4108444071 |
| TCB Email | tcbinfo@metlabs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 03/05/2017 |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Modular Approval. Output power listed is conducted. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. Integration of this module into a host system will require reassessment of radiated field strength for fundamental and spurious emissions due to the lack of shielding on the module. Host will be added through Class II permissive change. |
